Installation Manual
WARNING: For your safety the information
in this manual must be followed to minimize
the risk of fire or explosion or to prevent
property damage, personal injury or death.
— Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Clear the room, building or area of all
occupants.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
051603JRB/mcronan
SL20
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la
mort.
— Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
•
Ne pas tenter d'allumer d'appareils.
•
Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant
dans le bâtiment.
•
Évacuez la pièce, le bâtiment ou la zone.
•
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
•
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
— L'installation et l'entretien doivent être assurés
par un installateur ou un service d'entretien
qualifié ou par le fournisseur de gaz.
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 U.S.A.
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 113191
Advertisement
Table of Contents
Related Manuals for ADC SL20
Summary of Contents for ADC SL20
- Page 1 American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 U.S.A. Telephone: (508) 678-9000 / Fax: (508) 678-9447 e-mail: techsupport@amdry.com www.amdry.com 051603JRB/mcronan ADC Part No. 113191...
- Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.
-
Page 3: Table Of Contents
Important Table of Contents You must disconnect and lock out the electric supply and the gas supply before any covers or SAFETY PRECAUTIONS ......2 panels are removed from the machine to allow access for cleaning, adjusting, installation, or SPECIFICATIONS ........3 testing of any equipment per OSHA INSTALLATION PROCEDURES .... -
Page 4: Safety Precautions
Administration) STANDARDS. sécheuse doit évacuer à l’extérieur.) Important Although ADC produces a very versatile dryer, there are some articles that, due to fabric composition or cleaning method, Dryer must be installed in a location/environment, should not be dried in it. -
Page 5: Specifications
25,255 6,364 230/240 18,430 4,644 230/240 27,644 6,966 5,848 23,208 6,450 25,597 6,966 27,644 Shaded areas are stated in metric equivalent 1/22/04 Note ADC reserves the right to make changes in specifications at any time without notice or obligation. 113191-2... -
Page 6: Installation Procedures
______ Important NSTALLATION ROCEDURES Dryer should be located where a minimum amount of exhaust duct will be necessary. Installation should be performed by competent technicians in accordance with local and state codes. In the absence of The dryer must be installed with adequate clearance for air these codes, the installation must conform to applicable openings into the combustion chamber. -
Page 7: Fresh Air Supply Requirements
Important Make-up air must be provided from a source free of dry cleaning solvent fumes. Make-up air that is contaminated by dry cleaning solvent fumes will result in irreparable damage to the motors and other dryer components. Note Component failure due to dry cleaning solvent fumes will void the warranty. -
Page 8: Electrical Information
Horizontal Single Dryer Venting Multiple Dryer (Common) Venting 4-inch (10.16 cm) Ducting If it is not feasible to provide separate exhaust ducts for each dryer, ducts from individual dryers may be channeled into a “common main duct.” The individual ducts should enter the bottom or side of the main duct at an angle not more than 45°... - Page 9 Note Electric Models The connecting wires must be properly sized to handle the Component failure due to improper installation will rated current. void the warranty. The use of aluminum wire will void the warranty. ELECTRIC Important ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER) Failure to comply with these codes or ordinances, NOTES: When fuses are used they must be dual element, time...
-
Page 10: Electrical Connections
Warning Electric Models Only Single-Phase (1ø) Wiring Connections/Hookup Electrical Grounding Instructions – This dryer is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. -
Page 11: Gas Information
Do not operate the dryer. Contact as supplied by the manufacturer, shall be used to convert the reseller who sold the dryer or contact the ADC factory. this dryer to the alternate fuel. The input ratings shown on the dryer data label are for Pour utilisation avec le gaz naturel ou le propane. -
Page 12: Preparation For Operation/Start-Up
Important • Gas Models – be sure that all gas shutoff valves are in the open position. The gas supply line to each dryer must be a minimum of 3/8-inch (9.5 mm). Do not reduce this pipe size • Check that the back guard panel and the electrical box requirement. -
Page 13: Shutdown Instructions
Shutdown Instructions _________________ The dryer will continue through the drying and cooling cycles, until the vended time has expired. If the dryer is to be shutdown (taken out of service) for a period of time, the following must be performed: Note Discontinue power to the dryer either at the external disconnect To stop dryer, open main door or pressing the pause... -
Page 14: Service/Parts Information
Important A separate warranty card must be completed and All returns should be shipped to the ADC factory in such a returned for each individual dryer. manner that they are insured and a proof of delivery can be obtained by the sender. -
Page 15: Routine Maintenance
Maximum operating efficiency is dependent upon proper air circulation. The accumulation of lint can restrict this airflow. If the guidelines in this section are met, an ADC dryer will provide many years of efficient, trouble free, and most importantly, safe operation. Warning Lint from most fabrics is highly combustible. -
Page 16: Sensor Activated Fire Extinguishing (S.a.f.e.) System
Important We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to Flexible supply line/coupling must be used. Solenoid make changes from time to time, without notice or obligation,... - Page 17 Typical Water Supply Optional Manual Bypass If the rear area of the dryer, or the water supply is located in an Provisions are made in the dryer S.A.F.E. system for the area where it will be exposed to cold/freezing temperatures, installation of an optional manual bypass.
-
Page 18: S.a.f.e. System Theory Of Operation
S.A.F.E. system is ADC factory. When ordering replacement parts from the inoperative!! factory, you can FAX your order to ADC at (508) 678-9447 or S.A.F.E. System Theory of Operation __ telephone your order directly to the ADC Parts Department at (508) 678-9000. - Page 19 S.A.F.E. Sensor Probe Assembly Notes ______________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ Illus. No. Part No. Qty. Description ___________________________________ 883821 S.A.F.E. System Temperature ___________________________________ Probe Assembly (includes illus. nos. 1 through 3 and 5) ___________________________________ 154007 Push On Fastener 318525 Sensor Bracket ONLY ___________________________________...
- Page 20 ADC Part No. 113191 2 - 03/08/05-0...
