Sunsea AIoT SIMCom SIM5800 Hardware Design page 15

LCD_RST 49
LCD_TE 50
MIPI_DSI_CLKN 52
MIPI_DSI_CLKP 53
MIPI_DSI_LANE0N 54
MIPI_DSI_LANE0P 55
MIPI_DSI_LANE1N 56
MIPI_DSI_LANE1P 57
MIPI_DSI_LANE2N 58
MIPI_DSI_LANE2P 59
Camera interface
MIPI_CSI0_CLKN 63
MIPI_CSI0_CLKP 64
MIPI_CSI0_LN0N 65
MIPI_CSI0_LN0P 66
MIPI_CSI0_LN1N 67
MIPI_CSI0_LN1P 68
MIPI_CSI1_CLKN 70
MIPI_CSI1_CLKP 71
MIPI_CSI1_LN0N 72
MIPI_CSI1_LN0P 73
CAM0_MCLK 74
CAM1_MCLK 75
CAM0_RST 79
CAM0_PWDN 80
CAM1_RST 81
CAM1_PWDN 82
CAM_I2C_SCL 83
SIM5800_Hardware Design_V1.01
Smart Machine Smart Decision
O LCM reset
I
LCM frame alignment signal
O
O
O
O
LCM MIPI
O
O
O
O
I
I
I
MIPI signal
I
I
I
I
I
MIPI signal
I
I
O Primary Camera master clock
O Secondary Camera master clock
O Primary Camera reset
O Primary Camera power down
O Secondary Camera reset
O Secondary Camera power down
O Dedicated Camera I2C clock
15
Open drain output
2018-10-08
VIO18_PMU
