CYCLONE|DR
PP-5800BP Battery Pack for PP-500DR Portable Power Pack
User Manual

Advertisement

loading

Related Manuals for Bolt CYCLONE DR PP-5800BP

Summary of Contents for Bolt CYCLONE DR PP-5800BP

  • Page 1 CYCLONE|DR PP-5800BP Battery Pack for PP-500DR Portable Power Pack User Manual...
  • Page 2 Congratulations on the purchase of your Bolt PP-5800BP Battery Pack. This rechargeable large-capacity lithium-ion battery pack supplies power to Bolt’s PP-500DR and PP400DR power packs for on-camera flashes. When mounted on the PP-500DR, it will provide enough power for up to 2700 flashes (depending on flash unit and power setting) and offer fast recycling times for one or two portable flashes.
  • Page 3 • Do not disassemble or attempt to service this product full-power flashes. yourself. Doing so will void the warranty, and Bolt will not • Make sure the unit is powered off when plugging it into be responsible for any damage. There are high-voltage a power source.
  • Page 4 Charging the PP-5800BP The PP-5800BP can be charged as a freestanding unit or while mounted on the PP-500DR power pack. To charge the PP-5800BP: 1. Plug the charger unit into an AC outlet. 2. Plug the charging cable into the battery’s charging port. 3.
  • Page 5 120 V, 50 Hz (North American) plug. To use this fixture with other voltages, you must use a plug adapter (sold separately). Note: The PP-5800BP battery is compatible with Bolt’s PP-500DR and PP-400DR battery packs. Charging another device with the PP-5800BP The battery pack has an integrated USB port for charging a smartphone.

  • Page 6: Specifications

    Specifications Power Pack PP-5800BP AC Charger BO-1008 Battery type: Lithium-ion Input: 100 to 240 V AC, 50/60 Hz Voltage: 11.1 V DC Output: 12 V DC, 1500 mA Capacity: 5800 mAh Cable length: 5 ft. (1.5 m) Battery charging time: Approximately 4.5 hr.

  • Page 7: One-Year Limited Warranty

    To obtain warranty coverage, contact the BOLT Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to BOLT along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
