Von Duprin StrikeForce 6224 Installation Instructions

Installation Instructions

Double Door Closed Back Mortise or Cylindrical Application

Notes: Deadbolt will not function with this strike.
Check with factory for retrofit applications.
1. For lock or device preparation, see their directions.
2. Prepare door for strike (see other side).
3. Wire strike (Figure 1). (Switches on 6224DS only.)

SOLENOID POWER REQUIREMENTS

Yellow solenoid wires = 12 VDC, 0.57 A
Black solenoid wires = 24 VDC, 0.29 A
(also shown on strike label)
{
NOTE
!

Wiring

for DC DC input is
supply nonpolarized.
12 VAC
{
Wiring
or
for AC
24 VAC
supply
P1 J1A
Use crimp
connectors to
splice field wiring
to P1 leads
Strike lip
Latch bolt
1/32"
Top view;
faceplate not
shown for clarity
Figure 2
931240_00(4) Copyright © 2004 Ingersoll-Rand. All rights reserved.
®
6224/6224DS Electric Strike
12 VDC
P1
or
24 VDC
J1
SO-12 12 VDC
SO-24 24 VDC
P1A
SO-12 or SO-24
Figure 1
A
Figure 3
4. Test strike: Apply solenoid power. Fail secure (FSE) lip unlocks.
Fail safe (FS) lip locks. Figure 1 shows status of switches.
5. Install strike with two #12-24 screws. Make sure clearance
between latch bolt and strike lip is 1/32" (Figure 2). If not,
uninstall strike, adjust (Figure 3), and reinstall.
6. If latch bolt does not extend far enough to actuate tripper,
install extension (Figure 4). (Tripper on 6224DS only.)
7. Test door: With strike unlocked, door opens
J2 P2
S1
S2
Fail safe (FS)
Switches shown with tripper
Solenoid
depressed, strike lip closed and locked
(switches and tripper on 6224DS only)
To adjust strike,
loosen screws A, B,
and C and move
backbox sideways
as necessary
B
C
931240-00
with latch bolt extended. When door closes,
latch bolt rides over strike lip.
Use crimp connectors to
splice field wiring to P2
leads; insulate unused leads
1 1
S1
2 2
3 3
4 4
S2
5 5
6 6
J2 J2 P2
Fail secure (FSE)
Standard: 5 A, 30 VDC
Gold: 0.25 A, 30 VDC
Extension
Tripper
Figure 4
89/336/EEC
Red (C)
}
S1
Blue (monitors
tripper)
Yellow
}
White (C)
S2
(monitors
Gray
strike lip)
Violet

SWITCH RATINGS
