E - 20
Specifications
MultiSync LCD
1510 +
Display 38 cm (15 inch) viewable image size; 1024 x 768
native resolution (Pixel Count); active matrix;
thin film transistor (TFT); liquid crystal display (LCD);
0.297 mm dot pitch; 200 cd/m
200:1 contrast ratio, typical
Input Signal Video
Sync
Display Colours Analog Input:
Synchronisation Horizontal
Range
Vertical
Resolutions Landscape
Supported
Portrait
Active Display Landscape
Area***
Portrait
Power supply
78134712
2 white luminance, typical;
Analog 0.7 Vp-p 75 Ω
Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative)
(TTL Level)
Sync on Green video (Positive) 0.7
Vp-p and sync. Negative 0.3 Vp-p
16,777,216 colours
(Depends on the graphics board)
24.8 kHz to 60.0 kHz (Automatically)
56.2 Hz to 75 Hz (Automatically)
720 x 400*: VGA text
640 x 480* at 60 Hz to 75 Hz
800 x 600* at 56 Hz to 75 Hz
832 x 624* at 75 Hz
1024 x 768** at 60 Hz to 75 Hz
480 x 640* at 60 Hz to 75 Hz
600 x 800* at 56 Hz to 75 Hz
624 x 832* at 75 Hz
768 x 1024** at 60 Hz to 75 Hz
Horizontal
Vertical
Horizontal
Vertical
AC 100-120 V / 220-240 V 50/60 Hz
34
Specifications
304 mm
228 mm
228 mm
304 mm
