Controls
Information
Indicates the current display resolution and frequency setting
of the monitor.
NOTE: Mode Change should only be used if a resolution is
not recognized by the monitor. The user can change to the
appropriate resolution by selecting the Mode information
and selecting (increase or decrease) the corresponding option
(LCD1510V+ only).
Type of Sync : If the
is highlighted, then Sync Type is switched between Separate
Sync and Sync On Green (LCD1510V+ only).
EdgeLock control : Operating your monitor at a non-
standard timing may cause images to appear darker than
normal or have color distortion. Use of the EdgeLock control
will adjust images to their normal state (LCD1510+ only).
Resolution Notifier: While the display is capable of other resolutions,
as with all flat panel displays, it is a fixed matrix of pixels and thus best
used at its native resolution (1024x768). For further information, please
refer to your display card or system manual.
OSM LOCK OUT
The OSM LOCK OUT control completely locks out access
to all OSM control functions. When attempting to activate
OSM controls while in the LOCK OUT mode, a screen will
appear indicating that OSM controls are locked out.
• To enter the LOCK OUT mode, simultaneously press
• To activate the LOCK OUT function, simultaneously
• To deactivate the LOCK OUT mode, simultaneously
78134712
or
the PROCEED and button. The LOCK OUT window
will appear.
press and hold down the PROCEED and
OSM window will disappear within seconds and the
LOCK OUT function will be activated.
press the PROCEED and
33
button is pressed while TYPE
button. The
button.
