Connection to your Personal Computer
The MultiSync LCD
PC compatible computers. Your system has one of two configurations:
– the video controller is built into the computer.
– the video controller is in the form of a display card (sometimes
referred to as graphics card, video adapter or graphics board).
Both configurations have a video connector (or a CRT PORT on laptop
computers). If you are not sure which connector is the video connector,
refer to your computer or display card manual.
To attach the monitor to your system, follow these instructions:
1. Turn off the power to the monitor and computer.
2. If necessary, install the display card. For more information about
installing your card, refer to the display card manual.
3. Connect the 15-pin mini D-SUB of the appropriate signal
cable to the connector of the display card in your computer.
Tighten all screws (Figure A.1).
4. Connect the 15-pin mini D-SUB of the video signal cable and
the AC Adapter cable to the appropriate connectors on the back
of the monitor (Figure C.1). Place the AC adapter cable under
Clip A ( Figure C.1A).
NOTE: Incorrect cable connections may result in irregular operation,
damage display quality/components of LCD module and/or shorten the
module's life.
5. Connect one end of the power cord to the AC Adapter and the
other end to the power outlet (Figure E.1).
6. Turn on the monitor (Figure F.1) and the computer.
