Rockwell Automation Allen-Bradley 800G-XBx-EX Installation Instructions

Installation Instructions
Original Instructions
Bulletin 800G Base Mount Back-of-Panel Modules
Catalog Numbers 800G-XBx-EX; 800G-DBx-EX; 800G-DBxXx-EX
ATTENTION: To help prevent electrical shock, disconnect from
power source before installing or servicing. Follow NFPA 70E
requirements. Install in suitable enclosure. Keep free from
contaminants.
Only suitably trained personnel can install, adjust, commission,
use, assemble, disassemble, and maintain the product in
accordance with applicable code of practice. If a malfunction or
damage occurs, do not attempt to repair the product.
IMPORTANT When working in hazardous areas, the safety of personnel
and equipment depends on compliance with the relevant
safety regulations. The people in charge of installation and
maintenance bear a special responsibility. They must be
knowledgeable of the applicable rules and regulations.
These instructions provide a summary of the most important
installation measures. Everyone working with the product
must read these instructions so that they are familiar with the
correct handling of the product.
Keep these instructions for future reference as they must be
available throughout the expected life of the product.
Certifications
ATEX
IECEx
NEPSI
INMETRO
Gas protection type
Ambient Temperature Range
Service Temperature Range
Mechanical and Electrical Ratings
Rated Insulation Voltage
Power Consumption
Rated Voltage (U )
e
Illumination Colors (LED)
Contact Options
Utilization Category (AC)
Utilization Category (DC)
Conventional Thermal Current (I )
the
Conductor Size
Degree of Protection
Contact Block (Screw Termination)
CML 17 ATEX 1107 U
IECEx CML 17.0047U
GYJ17.1398U
UL-BR 14.0567U
II 2 G Ex db eb IIC Gb
-55...+40 °C (-67...+104 °F) @ 16 A
-55...+60 °C (-67...+140 °F) @ 11 A
-55...+85 °C (-67...+185 °F)
690V
—
AC 250V and 400V; DC 24V and 110V
—
1 N.O./1 N.C., 2 N.O., 2 N.C.
AC-12: 16 A, 400V; AC-15: 10 A, 400V
DC-13: 1 A, 24V; DC-13: 0.5 A, 110V
16 A/40 °C (104 °F)
11 A/60 °C (140 °F)
0.75...2.5 mm² (18...14 AWG)
• Module only: IP20
• Module and operator: IP64/IP66

Product Description

• Contact block (catalog number 800G-XBx-EX)
Contact blocks are used within hazardous areas where machine
functions are activated by pressing a button or actuating a
switch. These contact blocks are designed with self-cleaning
contacts and N.O. contacts feature positive break operation.
Contact blocks are compatible with all 800G non-illuminated
operators.
• Power module (catalog number 800G-DBx-EX)
Power modules are used within hazardous areas to indicate the
functional status of respective machines visually by lighting up
or turning off. Power modules are compatible with all 800G
pilot light operators.
• Power module with contact block (catalog number
800G­DBxXx-EX)
Power module with contact block combination units are used
within hazardous areas where machine functions are activated
by depressing a push button and the corresponding functional
status is visually indicated. These units are compatible with all
800G illuminated push button operators.
Power Module (Screw Termination)
CML 17 ATEX 1108 U
IECEx CML 17.0048U
GYJ17.1399U
UL-BR 14.0566U
-55...+50 °C (-67...+122 °F) or 60 °C (140 °F) if U
300V
≤1 W
• T <50 °C (122 °F): 12...250V AC, 12...60V DC
a
• T <60 °C (140 °F): 12...24V AC/DC
a
Red, green, blue, white, or yellow
—
—
—
—
Power Module with Contact Block
(Screw Termination)
≤26.4V
e
1 N.O., 1 N.C.
AC-15: 1 A, 230V
DC-13: 0.25 A, 24V
—
