G703/V.35 and X.21 Microconverter
Get the performance of 2.048 Mbps E1 lines without the expense of a top-end router.
Key Features:
G.703 to X.21
G.703 to V.35
G.703 to EIA-530/RS-449
Simple configuration
Unbalanced (coax) G.703
Balanced (twisted-pair) G.703
81043
Overview
:
The Black Box MicroConverter
G.703 enables the connection of
data communication to carrier
services, or private services,
such as microwave links, that
are presented as G.703 at
2Mbit/s.
Many low-end routers currently
on the market are able to handle
2 Mbit/s throughput, but are
only available with conventional
DTE interfaces, X.21 or EIA530.
By combining one of these
routers with the MicroConverter
G.703 users gain the high-
performance of 2 Mbit/s
without the expense of a high-
end router.
The standard model, the
MicroConverter G.703/X.21,
supports X.21 DTE. The
enhanced version, the
MicroConverter G.703/V.35,
can support both X.21 and
V.35 DTE. Both versions
support 75-ohm un-balanced
and 120-ohm balanced
termination of a G.703
network. For RS-449 or
EIA-530 operation the relevant
adaptor cable most be used
with the MicroConverter
G.703/X.21.
1.
Advertisement
Related Manuals for Black Box G.703/V.35
Summary of Contents for Black Box G.703/V.35
- Page 1 G703/V.35 and X.21 Microconverter Get the performance of 2.048 Mbps E1 lines without the expense of a top-end router. Key Features: G.703 to X.21 G.703 to V.35 G.703 to EIA-530/RS-449 Simple configuration Unbalanced (coax) G.703 Balanced (twisted-pair) G.703 81043 Overview The Black Box MicroConverter G.703 enables the connection of...
-
Page 2: Typical Application
Typical Application: Connect your Cisco routers’ X.21 interface to your 2 Meg leased line. Technically Speaking: The MicroConverter G.703 comes pre-configured for 75-ohm unbalanced operation. Connection to the 75-ohm unbalanced G.703/E1 network is achieved through connection using the two BNC connectors on the rear panel of the unit. -
Page 3: Ordering Information
Ordering Information Product Name: MicroConverter G.703/X.21 MicroConverter G.703/V.35 For V.35 order the MicroConverter G.703/V.35 and the following adaptor cable: V.35 DCE (F) Adaptor Cable 2-m For RS-449 and EIA-530 order the MicroConverter G.703/X.21 and one of the following adaptor cables: RS-449 DCE (F) Adaptor Cable 2-m EIA-530 DCE (F) Adaptor Cable 2-m ………………………………………...
