Endress+Hauser Proline Prowirl 200 Safety Instructions page 18

XA01148D
Position Basic specification,
position 1, 2:
Approval
1 Cable entry for BC, BK, IC, IK,TC
output 1 B3, I5
2 Cable entry for BC, BK, IC, IK,TC
output 2 B3, I5
3 Cable entry of BC, BK, IC, IK,TC
the remote B3, I5
display and
operating
module
FHX50
Position
4 Pressure compensation plug
 Potential equalization
1) The labeling changes in connection with "Display; Operation" = "L" or "M": Ex tb[ia Da] IIIC Txx °C Db.
18
Type of protection Description
used
for cable entry
Ex d In the case of device versions with a plastic
Ex d/Ex tb transport sealing plug, this plug does not meet
the explosion protection requirements and must
be replaced during installation by a suitable
entry that meets the approval specifications.
Ex d In the case of device versions with a metal
Ex d/Ex tb sealing plug, this plug is part of the device
approval and meets the requirements of the
explosion protection indicated on the
nameplate.
Ex ia The following applies for devices with basic
1)
Ex ia/Ex tb specification, position 1, 2 (Approval) = B3, I5:
In the case of device versions with a metal
sealing plug, this plug is part of the device
approval and meets the requirements of the
explosion protection indicated on the
nameplate.
In the case of device versions with a cable entry,
this entry has a separate component approval
and meets the requirements of the explosion
protection indicated on the nameplate.
Description
WARNING
L
Housing degree of protection voided due to insufficient sealing of the
housing.
‣
Do not open - not a cable entry.
NOTICE
Terminal for connection to potential equalization.
‣
Pay attention to the grounding concept of the facility.
Proline Prowirl 200
Endress+Hauser
