FG7C CONTROLLER
MAPPING ENERGIZER ALARM(S) TO IO CARD
A text file, etoimapplus.txt, i.e. energizer to io card mapping file is used to map each energizer
address to a relay card address.
This file can be made in notepad and has to be uploaded to the FG7 with the use of the web
interface.
The notation used is that Energizer#4 corresponds to Energizer with address 4
Table 1: How the etoimap.txt file is structured
Line
Number
1 The IO Card Address that Energizer#1 will
communicate with
2 The combination of any alarm condition(note 1)
that will activate relay 1
3 The combination of any alarm condition(note 1)
that will activate relay 2
4 The combination of any alarm condition(note 1)
that will activate relay 3
5 The combination of any alarm condition(note 1)
that will activate relay 4
6 The combination of any alarm condition(note 1)
that will activate relay 5
7 The combination of any alarm condition(note 1)
that will activate relay 6
8 The combination of any alarm condition(note 1)
that will activate relay 7
9 The combination of any alarm condition(note 1)
that will activate relay 8
10 Latching or not latching of relays with alarm
condition
11 The IO Card Address that Energizer#2 will
communicate with
12 The above sequence repeated etc. etc.
Notes:
1) Table 2 has a number associated with each alarm condition on an energizer. Select the
desired alarm condition(s) that can activate any relay and add the numbers together.
Function associated with the line

Mapping

Lines of Explanation
etoimap.txt
file
33 Energizer#1 alarms via IO
Card 33
2 Only Fence 1 Alarm
activates relay 1
6 Fence 1 or Fence 2 alarm
activates relay 2 (2+4)
Fence 1 or Fence 2 or Gate
14 Alarm activates relay3
(2+4+8)
32 Only Tamper Alarm
activates relay 4
4 Only Fence 2 Alarm
activates relay 5
2048 Mains present activates
relay 6
65 Comms fail or Sync fail
activates relay 7 (1+64)
4096 Panic alarm activates relay 8
Fence 1, Fence 2 and
38 Tamper Alarm conditions
are not latched (2+4+32)
Energizer#1 alarms via IO
34 Card 34
