CHIEF PAC502 Installation Instructions Manual

In-wall enclosure

Advertisement

I N S T A L L A T I O N I N S T R U C T I O N S
IN-WALL ENCLOSURE
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
PAC502

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAC502 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHIEF PAC502

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S IN-WALL ENCLOSURE Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PAC502...
  • Page 2: Important Safety Instructions

    ACCESSORY: AN ACCESSORY is the secondary Chief cables may be required. product which is attached to a primary Chief product, and may have a component attached or setting on it. • This Cabinet System accessory is for use with Listed wall mounting systems.
  • Page 3: Installation Instructions

    Installation Instructions PAC502 DIMENSIONS 1.75 44.5 6.00 6.00 152. 4 152. 4 1.75 44.5 3.63 .136 20X 5/16"-18 THREAD S 92.1 19.4 1.63 41.3 3.94 GRO UN DING 12.00 20.00 S CR EWS 304.8 NOTES: 1.26 ELECTRICAL CUTOUTS: • SINGLE GANG RACO 590,...
  • Page 4: Tools Required For Installation

    PAC502 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16" PARTS Grounding screw and washer installed at factory Earthing symbol IEC 60417 No. 5019 affixed adjacent to grounding terminal. B (4) [Mounting spacers] A (1) [PAC502] E (6) 08 x 1/2" C (8)
  • Page 5 16" codes. on center. Installation of PAC502 in 2 x 4 wall results in nearly direct contact with vertical studs and back wall. Remove exposed portion of center wood stud flush with upper and lower drywall edges.
  • Page 6 UL Recognized No. 12AWG Green and Yellow grounding wire connected to Attach the PAC502 (A) to side studs using four M7 x 50mm grounding lug on mount. Allen head connector screws (D) and mounting spacers (B) using an M4 Allen head drill bit (F).
  • Page 7: Cable Management

    Figure 7 Installing Mount Assembly Install mount assembly following instructions included with the mount. OPTIONAL: Cover unused mounting holes in PAC502 with 9/16" caps (L). Cable Management Attach all cables to display. If necessary, use cable tie mounts (H) and cable ties (J) to...
