I N S T A L L A T I O N I N S T R U C T I O N S
Above-Tile Suspended Ceiling Storage Kit
CMA473

Advertisement

loading
Need help?

Need help?

Do you have a question about the CMA473 and is the answer not in the manual?

Questions and answers

Related Manuals for CHIEF CMA473

Summary of Contents for CHIEF CMA473

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Above-Tile Suspended Ceiling Storage Kit CMA473...

  • Page 2: Installation Instructions

    WARNING: Do not use this product outdoors. IMPORTANT ! : The CMA473 is compatible only with the CMA440 and CMS440 ceiling mounts. Do NOT attempt to install the CMA473 to any other mounting system! IMPORTANT ! : The CMA473 is not intended to support any weight.

  • Page 3: Tools Required For Installation

    Installation Instructions CMA473 LEGEND Tighten Fastener Phillips Screwdriver Apretar elemento de fijación Destornillador Phillips Befestigungsteil festziehen Kreuzschlitzschraubendreher Apertar fixador Chave de fendas Phillips Serrare il fissaggio Cacciavite a stella Bevestiging vastdraaien Kruiskopschroevendraaier Serrez les fixations Tournevis à pointe cruciforme Loosen Fastener Aflojar elemento de fijación...
  • Page 4 CMA473 Installation Instructions DIMENSIONS Measurements in: inches [millimeters] 10.44 265.1 1.970 KNOCKOUT 0.875 KNOCKOUT 50.04 22.23 4.80 122.0 23.24 590.3...
  • Page 5 OR DAMAGE TO EQUIPMENT! The equipment must be Screws assembled and installed by qualified service personnel. IMPORTANT ! : The CMA473 is compatible only with the CMA440 and CMS440 ceiling mounts. Do NOT attempt to install the CMA473 to any other mounting system! Install CMA-440 or CMS-440 (accessory not included).
  • Page 6 Top cover may be removed during installation process if desired. However, it must be reinstalled before installation is complete! Remove four screws holding top cover to CMA473 box (A). (See Figure 4) Lift top cover up from CMA473 box (A). (See Figure 4) Figure 4...
  • Page 7 Installation Instructions CMA473...
  • Page 8 A 6436 City West Parkway, Eden Prairie, MN 55344 P 800.582.6480 / 952.225.6000 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands Chief Manufacturing, a products division P +31 (0) 495 580 852 of Milestone AV Technologies F +31 (0) 495 580 845 Asia Pacific A Office No.
