  • Page 1 PDF provided by Conference Room AV Chief CMA170 In-Ceiling CPU Storage Enclosure - Black...
  • Page 2 I N S T A L L A T I O N I N S T R U C T I O N S CPU Enclosure - Pipe Mount Accessory CMA170...

  • Page 3: Important Warnings And Cautions

    CMA170 Installation Instructions DISCLAIMER WARNING: Failure to read, thoroughly understand, and CSAV, Inc., and its affiliated corporations and subsidiaries follow all instructions can result in serious personal injury, (collectively, "CSAV"), intend to make this manual accurate and damage to equipment, or voiding of factory warranty! It is the complete.
  • Page 4 Installation Instructions CMA170 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...

  • Page 5: Tools Required For Installation

    CMA170 Installation Instructions TOOLS REQUIRED FOR INSTALLATION PARTS A (1) B (1) D (1) E (1) C (2) 5/32" 3/16" Security G (2) H (2) J (4) K (4) F (2) L (4) 1/4-20 x 3/8" 1/4-20 x 7/8" 5/16-18 x 7/8"...
  • Page 6 Installation Instructions CMA170 Assembling CMA-170 Swing open the CMA-170 end door. (See Figure 1) Lift end door up and out of top tab. (See Figure 1) Optional CMA-152 (N) x 4 [or (M) x 4] (C) x 2 (K) x 4...
  • Page 7 CMA170 Installation Instructions Installing CMA-170 to Display NOTE: A PCS/MCS bracket must be used to attach a display to the CMA-170. Attach bracket (B) to CMA-170 using two 1/4-20 x 7/8" button head cap screws (H) from INSIDE CMA-170. (See...
  • Page 8 Installation Instructions CMA170 NOTE: NOTE: In a sample installation, install components into the Phillips head screws (L) are provided if security screws CMA-170 in the following order (See Figure 8): are not required. Security screws can also be removed from the other CMA-170 door and replaced with the CPU;...
  • Page 9 F +31 (0)40 2668615 Asia Pacific A Room 30I, Block D, Lily YinDu International Building LuoGang, BuJi Town, Shenzhen, CHINA. Post Code: 518112 8803-000081 2007 Chief Manufacturing www.chiefmfg.com P +86-755-8996 9226 ; 8996 9236 ; 8996 9220 03/07 F +86-755-8996 9217...
