GREAT PLANES Dynaflite Series Manual Addendum

GREAT PLANES Dynaflite Series Manual Addendum

Ep arf

Advertisement

Quick Links

This manual addendum provides additional instructions for assembling the power system onto the Bird of
Time. Please read through this addendum before you start the assembly of the Bird of Time as it contains
information regarding some steps in the manual booklet. Follow the steps in the manual booklet as printed
unless noted otherwise in this addendum.

SPECIFICATIONS

Wingspan: 118 in [2997 mm]
Length: 49 in [1245 mm]
Weight: 4.5 – 4.75 lb [2040 – 2150 g]

WARRANTY

Great Planes
®
Model Manufacturing Co. guarantees this kit to
be free from defects in both material and workmanship at the
date of purchase. This warranty does not cover any component
parts damaged by use or modification. In no case shall Great
Planes' liability exceed the original cost of the purchased kit.
Further, Great Planes reserves the right to change or modify this
warranty without notice.
In that Great Planes has no control over the final assembly or
material used for final assembly, no liability shall be assumed nor
READ THROUGH THIS MANUAL ADDENDUM BEFORE STARTING CONSTRUCTION. IT CONTAINS
IMPORTANT INSTRUCTIONS AND WARNINGS CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.
© 2017 Great Planes Model Mfg. A subsidiary of Hobbico,
Wing Area: 1050 in
Wing Loading: 10 oz/ft
[31 g /dm
®
Inc.
MANUAL ADDENDUM
Radio: 3 + channel radio
2
2
[67.7 dm
]
Motor: Great Planes RimFire .32
2
2
]
ESC: 60A w/BEC
Battery: 14.8V 3300 – 3600mAh
accepted for any damage resulting from the use by the user of
the final user-assembled product. By the act of using the
user-assembled product, the user accepts all resulting liability.
If the buyer is not prepared to accept the liability associated
with the use of this product, the buyer is advised to return
this kit immediately in new and unused condition to the
place of purchase.
To make a warranty claim, go to: greatplanes.com/support
GPMA1053

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dynaflite Series and is the answer not in the manual?

Questions and answers

Summary of Contents for GREAT PLANES Dynaflite Series

  • Page 1 In that Great Planes has no control over the final assembly or To make a warranty claim, go to: greatplanes.com/support material used for final assembly, no liability shall be assumed nor READ THROUGH THIS MANUAL ADDENDUM BEFORE STARTING CONSTRUCTION.
  • Page 2: Replacement Parts List

    GPMA5308 ...Spinner Set the battery, receiver, and ESC into the fuselage. GPMA5309 ...Decals Great Planes Hook & Loop 1x6" (2) (GPMQ4480) GPMA5310 ...Complete Folding Propeller Set NOTE: The high start and receiver battery listed in the FLZA6672 ..13.5x7 Propeller Blades Only (2) manual booklet are no longer needed.
  • Page 3 ADDENDUM INSTRUCTIONS 5. In the section Install the Receiver on page 12 of the manual booklet, the receiver has been moved from the nose of the fuselage to just in front of the rudder servo. Shown here, the receiver is secured to the tray using self-adhesive hook-and-loop material (not included, use GPMQ4480).
  • Page 4 8. Use a small drill bit to make pilot holes at the marks you made. Then, fi nish drilling the holes with a 1/8” [3.2mm] bit. 11. Connect your ESC to the motor leads. Use self-adhesive hook and loop material (not included) to affi x your ESC to the fuselage side.
  • Page 5 BALANCE THE MODEL (C.G.) The balancing instructions in the manual booklet on page 14 remain the same. Ideally, the recommended balance point can be achieved by shifting the fl ight battery (and/or ESC and receiver) forward or aft. Adding ballast to achieve the correct balance should be a last resort.
  • Page 6 NEVER charge the batteries in the plane. ELECTRIC MOTOR & BATTERY ALWAYS get help from an experienced pilot when learning SAFETY PRECAUTIONS to operate motors. ALWAYS use safety glasses when running motors. WARNING: Once the motor batteries are connected, the electric motor can start at any time.
