No Function
16 Analogue input 1 mode
Determines the input on terminal T2
0-20: Current input 0 to 20mA (20mA full scale)
20-0: Current input 20 to 0mA (0mA full scale)
4-20: Current input 4 to 20mA with current loop loss (cL1) trip (20mA full scale)
20-4: Current input 20 to 4mA with current loop loss (cL1) trip (4mA full scale)
4-.20: Current input 4 to 20mA with no current loop loss (cL1) trip (20mA full scale)
20-.4: Current input 20 to 4mA with no current loop loss (cL1) trip (4mA full scale)
VoLt: 0 to 10V input
NOTE NOTE
In the 4-20 or 20-4mA modes (with current loop loss) the drive will trip on cL1 if the input reference is below 3mA. Also, if the drive trips on cL1, the
voltage analogue input cannot be selected.
NOTE NOTE
If both analogue inputs (A1 and A2) are to be set-up as voltage inputs, and if the potentiometers are supplied from the drive's +10V rail (terminal T3),
they must have a resistance >4kΩ each.
No Function
17 Enable negative preset speeds
OFF: Direction of rotation controlled by run forward and run reverse terminals
On: Direction of rotation controlled by preset speed values (use run forward terminal)
No Function
18 Preset speed 1
19 Preset speed 2
20 Preset speed 3
21 Preset speed 4
Defines preset speeds 1 to 4.
No Function
22 Load display units
Ld: Active current as a % of motor rated active current
A: Drive output current per phase in A
No Function
23 Speed display units
Fr: Drive output frequency in Hz
SP: Motor speed in rpm
Cd: Machine speed in customer defined units (See Pr 24).
No Function
24 Customer defined scaling
Multiplying factor on motor speed (rpm) to give customer defined units.
No Function
25 User security code
Used to set-up a user security code. See section 5.6 Security codes on page 37.
No Function
26 Not used
No Function
27 Power up keypad reference
0: keypad reference is zero
LASt: keypad reference is last value selected before the drive was powered down
PrS1: keypad reference is copied from preset speed 1
44
Electrical Keypad and
Parameters
Installation Display
Range
0-20, 20-0, 4-20, 20-4,
4-.20, 20-.4, VoLt
Range
OFF or On
Range
±1500 Hz
(Limited by setting of Pr
02 Maximum set speed)
Range
Ld, A
Range
Fr, SP, Cd
Range
0 to 9.999
Range
0 to 999
Range
Range
0, LASt, PrS1
www.controltechniques.com
Quick Start
Diagnostics
Commissioning
Defaults Type
4-.20 RW
Defaults Type
OFF RW
Defaults Type
0.0 RW
Defaults Type
Ld RW
Defaults Type
Fr RW
Defaults Type
1.000 RW
Defaults Type
0 RW
Defaults Type
Defaults Type
0 RW
