Control terminals I/O specification

The control circuits are isolated from the power circuits in the
drive by basic insulation (single insulation) only. The installer
must ensure that the external control circuits are insulated from
human contact by at least one layer of insulation (supplementary
WARNING
insulation) rated for use at the AC supply voltage.
If the control circuits are to be connected to other circuits
classified as Safety Extra Low Voltage (SELV) (e.g. to
personal computer), an additional isolating barrier must be
included in order to maintain the SELV classification.
WARNING
The above warnings also apply to the PCB edge connector
for the optional Solutions Modules. To allow a Solutions
Module to be fitted to Commander SK, a protective cover
must be removed to allow access to the PCB edge connector.
WARNING
See Figure 3-22 on page 27. This protective cover provides
protection from direct contact of the PCB edge connector by
the user. When this cover is removed and a Solutions Module
fitted, the Solutions Module provides the protection from
direct contact by the user. If the Solutions Module is then
removed, this PCB edge connector becomes exposed. The
user is required to provide protection in this case, to protect
against direct contact of this PCB edge connector.
NOTE
See Pr 05 on page 38 (Drive configuration) for terminal connection / set-
up diagrams and details.
NOTE
The digital inputs are positive logic only.
NOTE
The analogue inputs are unipolar. For information on a bipolar input, see
the Commander SK Advanced User Guide.
T1 0V common
T2 Analogue input 1 (A1), either voltage or current (see Pr 16)
Voltage: Current input
Parameter range
Scaling
Input impedance
Resolution
0-20: Current input 0 to 20mA (20mA full scale)
20-0: Current input 20 to 0mA (0mA full scale)
4-20: Current input 4 to 20mA with current loop loss (cL1) trip
(20mA full scale)
20-4: Current input 20 to 4mA with current loop loss (cL1) trip
(4mA full scale)
4-.20: Current input 4 to 20mA with no current loop loss (cL1) trip
(20mA full scale)
20-.4: Current input 20 to 4mA with no current loop loss (cL1) trip
(4mA full scale)
VoLt: 0 to 10V input
T3 +10V reference output
Maximum output current
34
Electrical Keypad and
Installation Display
0 to 10V: mA as parameter range
4-20, 20-4, 0-20, 20-0, 4-.20, 20-.4, VoLt
Input range automatically scaled to Pr
01 Minimum set speed / Pr 02 Maximum
set speed
200Ω (current): 100kΩ (voltage)
0.1%
5mA
www.controltechniques.com
Quick Start
Parameters Diagnostics
Commissioning
T4 Analogue input 2 (A2), either voltage or digital input
Voltage: Digital input
Scaling (as voltage input)
Resolution
Input impedance
Normal threshold voltage (as
digital input)
T5
Status relay - Drive healthy (Normally open)
T6
Contact voltage rating
Contact maximum current
rating
Contact minimum
recommended rating
Contact isolation
Operation of contact (drive
healthy - default condition)
Provide fuse or over-current protection in status relay circuit.
WARNING
B1 Analogue voltage output - Motor speed
Voltage output
Scaling
Maximum output current
Resolution
B2 +24V output
Maximum output current
B3 Digital output - Zero speed
Voltage range
Maximum output current
NOTE
The total available current from the digital output plus the +24V output is
100mA.
Commander SK Size 2 to 6 Getting Started Guide
UL Listing
Options Parameter List
Information
0 to +10V: 0 to +24V
Input range automatically scaled to Pr
01 Minimum set speed / Pr 02 Maximum
set speed
0.1%
100kΩ (voltage): 6k8 (digital input)
+10V (positive logic only)
240Vac
30Vdc
2Aac 240V
4Adc 30V resistive load (2A 35Vdc for
UL requirements).
0.3Adc 30V inductive load (L/R=40ms)
12V 100mA
1.5kVac (over voltage category II)
OPEN
AC supply removed from drive
AC supply applied to drive with drive in
tripped condition
CLOSED
AC supply applied to drive with drive in a
'ready to run' or 'running' condition (not
tripped)
0 to +10V
0V represents 0Hz/rpm output
+10V represents the value in Pr 02
Maximum set speed
5mA
0.1%
100mA
0 to +24V
50mA at +24V (current source)
Issue Number: 2
