Figure 3-11 Surface mounting the size 6 drive
310mm (12.205in)
20
Electrical Keypad and
Parameters
Installation Display
298mm (11.732in)
18.9mm (0.744in)
1131mm
(44.528in)
18.9mm (0.744in)
www.controltechniques.com
Quick Start
Diagnostics
Commissioning
25.7 0.5mm
(1.012 0.020in)
1168.8mm
(46.016in)
Commander SK Size 2 to 6 Getting Started Guide
UL Listing
Options Parameter List
Information
258.6 0.5mm ±
∅8.5mm
(10.181 0.020in) ±
(0.335in)
±
±
1150.8 ±0.5mm
(45.307 0.020in) ±
∅8.5mm
(0.335in)
