In all of the settings below, the status relay is set up as a drive healthy relay:
T5
OK Fault
T6
Configuration
AI.AV Voltage and current input
AV.Pr Voltage input and 3 preset speeds
AI.Pr Current input and 3 preset speeds
Pr 4 preset speeds
PAd Keypad control
E.Pot Electronic motorised potentiometer control
tor Torque control operation
Pid PID control
HUAC Fan and pump control
Figure 6-1 Pr 05 = AI.AV
Eur
Remote speed
reference input
10k
(2kmin)
_
+
V
+24V
0V
Terminal B7 open: Local voltage speed reference (A2)
selected
Terminal B7 closed: Remote current speed reference
(A1) selected
Commander SK Size 2 to 6 Getting Started Guide
Issue Number: 2
Electrical Keypad and
Installation Display
Description
Figure 6-2 Pr 05 = AV.Pr
T1 0V
Remote current speed
T2
reference input (A1)
T3 +10V reference output
Local voltage speed
T4
reference input (A2)
Analogue output
B1
(motor speed)
B2 +24V output
+24V
Digital output
B3
(zero speed)
Drive Enable/Reset
B4
(USA: /Stop)
Run Forward
B5
(USA: Run)
Run Reverse
B6
(USA: Jog)
Local (A2)/Remote (A1)
B7
speed reference select
www.controltechniques.com
Quick Start
Parameters
Commissioning
Eur
10k
(2kmin)
_
+
V
B1
B2
B3
0V
B4
B5
B6
B7
T4 B7 Reference selected
0 0 A1
0 1 Preset 2
1 0 Preset 3
1 1 Preset 4
Diagnostics Options Parameter List
T1 0V
Local voltage speed
T2
reference input (A1)
T3 +10V reference output
T4 Reference select
Analogue output
(motor speed)
+24V output
Digital output
(zero speed)
Drive Enable/Reset
(USA: /Stop)
Run Forward
(USA: Run)
Run Reverse
(USA: Jog)
Reference select
