Table 2-4 Commander SK2, 400V drive, 3 phase, 380 to 480VAC ±10%, 48 to 65Hz units
Normal Duty
Nominal 100% RMS
Model
motor output
Number
power current
kW hp A
SK2401 7.5 10 15.3
SK2402 11 15 21
SK2403 15 20 29
SK2404
Table 2-5 Commander SK3, 200V drive, 3 phase, 200 to 240VAC ±10%, 48 to 65Hz units
Normal Duty
Nominal 100% RMS
Model
motor output
Number
power current
kW hp A
SK3201 11 15 42
SK3202 15 20 54
Table 2-6 Commander SK3, 400V drive, 3 phase, 380 to 480VAC ±10%, 48 to 65Hz units
Normal Duty
Nominal 100% RMS
Model
motor output
Number
power current
kW hp A
SK3401 18.5 25 35
SK3402 22 30 43
SK3403 30 40 56
Table 2-7 Commander SK3, 575V drive, 3 phase, 500 to 575VAC ±10%, 48 to 65Hz units
Normal Duty
Nominal 100% RMS
Model
motor output
Number
power current
kW hp A
SK3501 3.0 3.0 5.4
SK3502 4.0 5.0 6.1
SK3503 5.5 7.5 8.4
SK3504 7.5 10 11
SK3505 11 15 16
SK3506 15 20 22
SK3507 18.5 25 27
Table 2-8 Commander SK4, 200V drive, 3 phase, 200 to 240VAC ±10%, 48 to 65Hz units
Normal Duty
100%
Nominal
Model RMS
motor
number output
power
current
kW hp A
SK4201 18.5 25 68
SK4202 22 30 80
SK4203 30 40 104
Commander SK Size 2 to 6 Getting Started Guide
Issue Number: 2
Electrical Keypad and
Installation Display
Heavy Duty
Nominal 100% RMS
150% overload
motor output
current for 60s
power current
kW hp A
5.5 10 13
7.5 10 16.5
11 20 25
15 20 29
Heavy Duty
Nominal 100% RMS
150% overload
motor output
current for 60s
power current
kW hp A
7.5 10 31
11 15 42
Heavy Duty
Nominal 100% RMS
150% overload
motor output
current for 60s
power current
kW hp A
15 25 32
18.5 30 40
22 30 46
Heavy Duty
Nominal 100% RMS
150% overload
motor output
current for 60s
power current
kW hp A
2.2 2.0 4.1
3.0 3.0 5.4
4.0 5.0 6.1
5.5 7.5 9.5
7.5 10 12
11 15 18
15 20 22
Heavy Duty
100% 150%
Nominal
RMS overload
motor
output current
power
current for 60s
kW hp A A
15 20 56 84
18.5 25 68 102
22 30 80 120
