- Page 1 LED Pixel Rail 40 RGB MKII LED strip user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 12.02.2019, ID: 449739 (V2)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................4 1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 6 Safety instructions............................. 9 Features............................... 14 Installation and starting up........................ 15 Connections and controls........................18 Technical specifications........................20 Cleaning............................... -
Page 4: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. LED strip... -
Page 5: Further Information
General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly. -
Page 6: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. - Page 7 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
- Page 8 General information Warning signs Type of danger Warning – danger zone. LED strip...
-
Page 9: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended for use as a lighting effect in connection with a Pixel Rail Drive 640 con‐ troller (item no.: 449740). Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in per‐... - Page 10 Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
- Page 11 Safety instructions NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. LED Pixel Rail 40 RGB MKII...
- Page 12 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specified in the chapter ‘Technical specifications’...
- Page 13 Safety instructions NOTICE! Compatible devices The device may only be used with Stairville Pixel Rail Drive 640 MKII (item no. 449740). LED Pixel Rail 40 RGB MKII...
-
Page 14: Features
Features Features Pixel effects strip with 40 tri-colour SMD LEDs (RGB) Control via Pixel Rail Drive 640 (item no.: 449740) Voltage supply via LAN cable (Cat) Robust aluminium die-cast housing For technological reasons, the light output of LEDs decreases over their lifetime. This effect increases with higher operating temperature. -
Page 15: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 16 Installation and starting up NOTICE! Risk of overheating The distance between light output and the illuminated surface must be more than 1.5 m (19.7in). Provide sufficient ventilation. The ambient temperature must always be below 40 °C (104 °F). Mounting options You can install the unit in hanging or standing position.
- Page 17 Installation and starting up Connect the device via a suitable RJ45 data cable (Cat) with the Pixel Rail Drive 640. A max‐ imum of four pixel strips may be connected in series to each serial interface of the controller, thus a maximum of 16 pixels Rail 40 RGB MKII per controller. Please note that this device must not be connected to a dimmer.
-
Page 18: Connections And Controls
Connections and controls Connections and controls Front panel LED strip... - Page 19 Connections and controls 1 Mounting rail for the mechanical connection of the pixel rails using fastening elements (6). 2 RJ45 input for power supply and control of the device by means of Pixel Rail Drive 640. 3 Locking screw for fixing the mounting bracket. 4 Mounting bracket for attaching the device to a suitable cross bar.
-
Page 20: Technical Specifications
Technical specifications Technical specifications Light source 40 × 5050 SMD, RGB Optical properties Beam angle 120° Pixel pitch 25 mm Luminance 1050 Nit Refresh rate 3000 Hz Control Via Stairville Pixel Rail Drive 640 MKII Input connections Voltage supply RJ45 Control via Stairville Pixel Rail Drive 640 MKII RJ45 Output connections... - Page 21 Technical specifications Dimensions (W × H × D) 1000 mm × 95 mm × 40 mm Weight 1.3 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 50 %, non-condensing LED Pixel Rail 40 RGB MKII...
- Page 22 Technical specifications Further information Outdoor-ready Power of the individual LEDs 10 mm Colour mixture LEDs individually controllable LED type Unicoloured Fanless Remote control Not possible Wireless DMX Housing colour Black LED strip...
-
Page 23: Cleaning
Cleaning Cleaning Device components Clean the device components that are accessible from the outside regularly. The cleaning fre‐ quency depends on the operating environment: damp, smoky or particularly dirty environ‐ ments can cause greater accumulation of dirt on the device components. Clean with a dry soft cloth. -
Page 24: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 25 Notes LED Pixel Rail 40 RGB MKII...
- Page 26 Notes LED strip...
- Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
