1.5 Warranty IMPORTANT! A warranty claim can only be accepted by Schmalz if the Compact Terminal has been installed and used in accor- dance with the corresponding operating instructions. In the case of inappropriate handling or use of force, any warranty and liability claims shall be void.
Page 3
When replacing an ejector disc, a distinction is made between the following cases: • Identical ejector disc (same part no.) • Non-identical ejector disc • Control module To replace the control module, the SCTSi must be sent to Schmalz for repair. Available ejector discs: Part number Designation Description 10.02.02.04673 SCPSt-07-G02-NC Compact ejector for SCTSi;...
Page 4
With the SCTSi IO-Link (variant with IO-Link), the required IO link configuration file (IODD) depends on the number of ejector discs. Distribution of IO link configuration files (IODD): • SCTSi with up to 4 ejector discs • SCTSi with up to 8 ejector discs •...
Page 5
Connectors Electrical connector Compressed-air distributor 6 Detaching the SCTSi ü The Compact Terminal is disconnected from the compressed air supply and the power supply. ü The vacuum and compressed air system is subjected to atmospheric pressure. 1. Loosen and remove the threaded rods (2 pieces) with Allen key M4 and M5.
Page 6
2. To disconnect the disc elements and end plates, pull on the compressed-air distributors in the direc- tion shown. Both end plates contain sealing ele- ments inside. These should be handled with care and reused during mounting. 7 Preparing the Ejector Disk for Mounting The delivery of the new ejector disc includes: •...
Page 7
1. Insert the new or additional ejector disc and care- fully push the terminal together. Do not use force on the electrical interface. 2. Guide the threaded rods through the SCTSi and screw them from both sides, including the seals, to 2 Nm using a medium-strength thread locking compound.
Page 8
3. Mount the electrical connections. 4. Switch on the SCTSi via the control unit. The new configuration is automatically detected by the control unit. Following conversion, the type plate of the SCTSi is no longer correct.
