Framery Q Working with PAL
English
Installation instructions
Version 2.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q Working with PAL and is the answer not in the manual?

Questions and answers

Related Manuals for Framery Q Working with PAL

Summary of Contents for Framery Q Working with PAL

  • Page 1 Framery Q Working with PAL English Installation instructions Version 2.1...

  • Page 3: Table Of Contents

    Contents 1 Warranty checklist..................5 2 Safety......................6 3 Installation requirements................8 3.1 Tools and accessories.................... 8 3.2 Main dimensions.....................9 3.3 Installation space....................9 3.4 Operating space....................10 4 Floor......................11 4.1 Connect the floor modules................... 11 4.2 Level the floor.......................16 5 Install the wall modules................
  • Page 4 10.5 Install the control unit..................64 10.6 Install the motion detector and light..............66 11 Install the seals..................71 12 Install the carpet..................72 13 Install the floor threshold............... 73 14 Install the ceiling threshold..............75 15 Install the door..................77 15.1 Install the door....................77 15.2 Install the door handle..................79 16 Install the interior..................

  • Page 5: Warranty Checklist

    For the product warranty to be valid: Fill this checklist and send it to Framery after pod installation. Take a photo or scan the filled list and send it to Framery at warranty@frameryacoustics.com. Leave the completed list inside the pod.

  • Page 6: Safety

    Note: Do not place heavy objects on the roof of the pod. Note: Do not attach or hang extra weight from the door. Warning: Always disconnect the pod from the power outlet before performing any maintenance. To disconnect, remove plug from outlet. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 7 Installation environment The pod is intended to be used in the following conditions. • Ambient temperature: +15°C ... +30°C (59°F ... 86°F) • Humidity: max. 50% Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 8: Installation Requirements

    Note: Use a white rubber mallet to prevent leaving marks on the body covers. Note: Use a plastic chisel to remove the body covers. Note: Use a draw wire in the electrical installations. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 9: Main Dimensions

    Make sure that you have enough installation space before you start the installation. The minimum operating width includes 50 mm (1.9 in) on both sides of the pod and 150 mm (5.9 in) above the pod to ensure sufficient ventilation. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 10: Operating Space

    Figure 3: Installation space measurements 3.4 Operating space Make sure that the pod has enough space for the air to circulate correctly. Figure 4: Operating space measurements Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 11: Floor

    ABS strips. Make sure that the scratched sides are on the intended front of the pod. Note: Make sure that the half-sized acoustic panel is at the intended back of the pod. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 12 Install guide pins (2 pcs) to the holes in one of the floor modules. Note: Make sure that the flat side of the guide pin goes into the mounting hole. Push the floor modules together. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 13 Install flanged M8x50 bolts (4 pcs) and M8 nuts (4 pcs). Unscrew the 4x30 screws (4 pcs) and remove the cover plates (4 pcs). Set the cover plates and screws aside. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 14 Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. Note: Make sure that you install the correct frame to the front. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 15 Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. Note: Make sure that you install the correct frame to the back. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 16: Level The Floor

    • On top of the walls on the right-hand and left-hand sides • On the ABS strips at the edges of the floor modules Measure opposite points repeatedly and adjust the feet of the leveling screws gradually. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 17: Install The Wall Modules

    Place the wall modules lengthwise against a wall. Unscrew the 4x30 screws (24 pcs) and remove the cover panels (4 pcs). Set the cover panels and screws aside. Note: Make sure that the wall modules do not fall over. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 18: Connect The Wall Modules To The Floor

    Lift one wall module into place so that the "This side up" -sticker is on the top edge of the wall. Note: Support the wall until it is secured with the bolts. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 19 Lift the other wall module into place so that the "This side up" -sticker is on the top edge of the wall. Note: Support the wall until it is secured with the bolts. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 20 Install M8x35 bolts (4 pcs) and M8 washers (4 pcs). Note: Support the wall until it is secured with the bolts. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 21: Roof

    Install the guide pins (2 pcs) to the mounting holes in one of the roof modules. Note: Make sure that the flat side of the guide pin goes into the mounting hole. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 22 Push the roof modules together. Install flanged M8x50 bolts (4 pcs) and flanged M8 nuts (4 pcs). Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 23 Note: Make sure that the flat side of the guide pin goes into the mounting hole. Push the back upper frame into place. Note: Make sure that you install the correct frame to the roof. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 24: Install The Roof

    Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. 6.2 Install the roof Warning: Heavy object, risk of injury. Lift carefully. Lifting requires a minimum of 2 people. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 25 Note: Make sure that the flat side of the guide pin goes into the mounting hole. Lift the roof onto the wall modules. Warning: Plan the lift beforehand. Make sure that the installation site is neat and tidy to prevent tripping while lifting the roof. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 26 Install M8x35 bolts (8 pcs) and M8 washers (8 pcs). Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 27: Front Frames

    Note: Leave the lower frame guide pins in place. Note: Press the acoustic panel aside to reach the bolt holes. Make sure that you return the acoustic panel to its original position. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 28 Install guide pins (8 pcs) to the holes on the front of the pod. Note: Make sure that the flat side of the guide pin goes into the mounting hole. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 29 Lift the left-hand side frame into place. Note: Support the frame until securely fastened. Install the left-hand frame with M8x35 bolts (2 pcs) and M8 washers (2 pcs). Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 30 Lift the right-hand side frame into place. Note: Support the frame until securely fastened. Install the right-hand frame with M8x35 bolts (2 pcs) and M8 washers (2 pcs). Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 31: Install The Front Glasses

    If installing the optional booking system bracket, install the rubber lead-through to the groove at the bottom of the aluminum frame. If not installing the booking system bracket, continue to step 4. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 32 Note: Make sure that the USB A connector of the cord is at the bottom of the aluminum frame. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 33 Measure the straightness of the lock-side glass frame with a spirit level. Adjust if needed and install with M8x20 screws (2 pcs) and M8 washers (2 pcs). Use a hex key. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 34 Guide the hinge-side glass into the grooves and slide it into place. Tip: Push the roof up from the center joint at the front of the pod to make the installation easier. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 35: Install The Upper And Lower Frames

    Note: Make sure that the flat side of the guide pin goes into the mounting hole. Install the upper frame with M8x60 bolts (2 pcs) and M8 washers (2 pcs) at the small openings and with one M8x35 bolt and M8 washer at the center opening. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 36 Tighten the nylon screws (2 pcs each side) on the sides of the front of the pod with a flat-head screwdriver. Note: The glass adjustment screws are only for stiffening the glass structure. Tighten the screws until you feel resistance, then loosen half a turn. Do not overtighten. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 37: Install The Booking System Bracket (Optional)

    Use a hand tool. Note: Do not use power tools to remove the strike plate. Note: Set the screws aside for later use. The standard strike plate is not needed. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 38 Install the small rubber grommet onto the USB cord and insert the grommet into the hole in the lock-side glass. Note: Make sure that you leave enough cord on the out side to reach the customer supplied tablet. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 39 Install the large rubber grommet to the strike plate of the booking system bracket. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 40 Measure the correct place for the rubber spacer on the chosen wooden back plate and install with one 4x20 screw. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 41 Lead the USB cord through the grommet in the strike plate. Assemble the booking system bracket with one M6x30 screw and one M6 barrel nut. Hold the nut in the slot while tightening the screw. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 42 M5x25 Taptite screws (2 pcs) set aside earlier. Use a hand tool. Note: Do not use power tools to install the strike plate. Note: Make sure that the USB cord is not pinched or damaged during the installation. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 43 Tip: You may need to pull on the cord at the opening near the floor to be able to adjust the length. 11. Install the plastic cover to the slot in the strike plate. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 44 12. Guide the lower end of the USB cord into the groove at the side of the floor and along the top of the insulation board to the free space in the floor. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 45: Back Frames And Glasses

    8 Back frames and glasses 8.1 Install the side frames (back) Remove the back upper frame from the roof. Set the frame and bolts aside. Note: Leave the upper frame guide pins in place. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 46 Note: Leave the lower frame guide pins in place. Install guide pins (4 pcs) to the vacant holes on the back of the pod. Note: Make sure that the flat side of the guide pin goes into the mounting hole. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 47 Lift the left-hand side frame into place. Note: Support the frame until securely fastened. Install the left-hand frame with M8x35 bolts (2 pcs) and M8 washers (2 pcs). Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 48: Install The Lower Frame

    Install the lower frame to the floor with M8x60 bolts (2 pcs) and M8 washers (2 pcs) at the small openings and with one M8x35 bolt and M8 washer at the center opening. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 49: Install The Back Glasses

    Install the seal strip onto the straight side of both back side glasses. Note: Do not stretch the seal. Note: Make sure that the seal runs all the way from the top of the glass to the bottom. Cut off any excess. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 50 Lift one side glass into the groove in the lower frame and slide it into place. Lift the other side glass into the groove in the lower frame and slide it into place. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 51: Install The Upper Frame

    Turn the upper frame onto the edge of the glasses and push the frame into place against the roof. Note: Make sure that the glasses stay aligned while installing the upper frame. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 52 Tighten the nylon screws (2 pcs each side) on the sides of the back of the pod with a flat-head screwdriver. Note: The glass adjustment screws are only for stiffening the glass structure. Tighten the screws until you feel resistance, then loosen half a turn. Do not overtighten. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 53: Install The Cover Panels And Plates

    Note: Place the countersunk holes upwards. Use the existing screw holes. Install the floor cover plates (4 pcs) with 4x30 screws (1 pcs each). Note: Place the countersunk holes upwards. Use the existing screw holes. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 54 Note: If you install for the first time, you need two extra screws per panel, in addition to the ones removed at the beginning of the installation. Install the two additional screws to the two vacant countersunk holes in the cover panels. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 55: Install The Electrical Equipment

    Unscrew the 4x30 screw (1 pcs) and remove the cover plate at the foot of the right side wall. Set the screw and cover plate aside. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 56 Note: Make sure that only 4.5 m (15 ft) of the cord is left outside the pod, loop the excess into the floor. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 57: Install The Power Cord From The Roof

    At the opening, guide the DC extension cord into the electric pipe in the floor and feed it to the center of the floor. 10.2 Install the power cord from the roof If installing the power cord from the roof, follow these instructions. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 58 Note: Make sure that you feed the female end of the DC extension cord down to the floor module. Tip: Tape the ends of the power cord and DC extension cord together with electrical tape to make the installation easier. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 59: Install The Lan Cord (Optional)

    If the pod delivery includes the LAN data cartridge option, feed two LAN cords into the opening on the outside of the floor. Choose which side of the floor according to the most convenient location. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 60: Install The Power Unit

    10.4 Install the power unit Make sure that the ON/OFF switch of the power unit is in the "I" position. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 61 Connect the power cord to the power unit. Tip: The power unit AC connector has a locking mechanism. To bypass the locking mechanism, tilt the connector of the AC power cord first down and then Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 62 Connect the DC extension cord to DC connector of the converter. If installing the optional booking system bracket or the optional wireless charger, connect the USB-DC splitter cord between the DC extension cord and the DC connector of the converter. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 63 Note: If installing the wireless charger, make sure that the USB connector is placed so that it is accessible through the opening. Note: Make sure that the electrical cords are not damaged or pinched during the installation. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 64: Install The Control Unit

    10.5 Install the control unit Insert the control unit bracket into the back of the control unit. Turn the bracket into place. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 65 Install the bracket with control unit into the opening in the ceiling with 4x30 screws (2 pcs). Note: Make sure that you install the control unit to the right-hand side of center beam. Connect the DC extension cord to the PWR IN connector. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 66: Install The Motion Detector And Light

    Lead the second fan power cord through the groove in the center beam and connect it to the FAN 2 connector. 10.6 Install the motion detector and light Remove the cover from the motion detector. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 67 125 mm (4 15/16 in). Note: Use the ceiling felt center line as the midpoint reference. Connect the motion detector cord to the motion detector. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 68 Guide the motion detector cord through the opening to the control unit. Connect motion detector cord to the PIR connector of the control unit. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 69 Lift the motion detector to the bracket and slide the motion detector into place. Connect the light cord to the LED 1 connector of the control unit. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 70 The light attaches to the ceiling with magnets. Align the light to the center of the ceiling. Note: Make sure that the cords are not damaged or pinched during the installation. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 71: Install The Seals

    Seal the back of the pod with a wedged shaped seal between the glasses and frames. Note: Install the seal on the outside of the back of the pod and cut off any excess. Tip: Use glass washing liquid as a lubricant to help install the seal. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 72: Install The Carpet

    Install the carpet into place so that the edge slot is on the door side and the floor grid opening is on the glass wall side. Note: Press the edges under the wall felt. Note: Make sure that the carpet is firmly installed and there are no bumps. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 73: Install The Floor Threshold

    Neatly cut the side frame seal to the correct length, if needed. Note: Make sure that the protective plastic on the aluminum frames is not under the threshold. Peel back further, if needed. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 74 Install the floor threshold with 5x50 screws (2 pcs). Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 75: Install The Ceiling Threshold

    Lift the ceiling threshold up to the top of the doorway. Note: Slant the threshold and lift the right edge up first. Make sure that you do not scratch the door frames with the threshold. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 76 Neatly cut the side frame seal to the correct length, if needed. Note: Make sure that the protective plastic on the aluminum frames is not under the threshold. Peel back further, if needed. Install the ceiling threshold with black 5x30 screws (4 pcs). Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 77: Install The Door

    Note: Do not peel off the black tape from the hinges. The tape is needed to protect the glass parts from the metal hinges. Note: Make sure that the washers stay in place when detaching the halves of the hinges. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 78 Use a hand tool. Note: Do not use power tools to install the hinges. Note: Peel back enough of the protective plastic to install the hinges. Do not remove the protective plastic completely. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 79: Install The Door Handle

    Remove the protective plastic on the inside of the door. Push the handle with the spindle attached to it into place on the outside of the door. Pierce the plastic in the lock case with the spindle. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 80 Install an M5x46 screw in the hole at the center of the handle from the inside of the door. Note: Make sure that the cover plate is positioned straight. Note: Do not overtighten the screws. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 81 Note: In the final position, the head of the set screw is slightly above the handle surface. Note: Do not overtighten the screws. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 82: Install The Interior

    Install the coat hangers with black 5x50 screws (1 pcs each). Tip: If the coat hanger does not feel secure, remove it, move it slightly towards the glass wall and install it again. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 83: Assemble The Table

    LAN cords from the floor module up through the table leg. Lead the power outlet cord (and optional LAN cords) through the groove at the top of the table leg or the groove in the table top. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 84 Install the table leg to the table top with 4.25x25 wronic screws (4 pcs). Note: Make sure that the table leg is attached in the correct position and the cords are not damaged during the installation. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 85: Install The Lan Data Cartridge (Optional)

    If the delivery does not include the LAN data cartridge option, continue to the next section. Guide the ends of the LAN cords one at a time through the free opening at the side of the LAN data cartridge. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 86 Continue as instructed in the following section with the LAN data cartridge in place. Note: Make sure that the LAN cords and the power outlet cord are on the same side after attaching the LAN data cartridge to the power outlet. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 87: Install The Power Outlet

    16.4 Install the power outlet Place the power outlet onto the fixing plate at the bottom of the table top. Turn the power outlet counter-clockwise until it locks into place. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 88: Install The Table

    If the table is equipped with a wireless charger, also pull the excess cord of the wireless charger into the table leg. 16.5 Install the table Turn the carpet away from the opening in the floor. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 89 Connect the power outlet cord from the base of the table leg to the power unit in the floor. The connector locks into place with a "click" sound. If installing a table with the wireless charger option, connect the wireless charger cord to the USB connector in the floor. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 90 Note: Make sure the cords are not pinched or damaged during the installation. Turn the carpet down around the table leg. Note: Make sure that the carpet is firmly installed, it fits smoothly around the table leg and there are no bumps. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 91 Measure the distance at the center and the ends of the table top. Note: Make sure that the table top is level. Use a spirit level. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 92: Place The Seats In The Pod

    16.6 Place the seats in the pod The PAL seats do not require any assembly. Lift the seats into the pod. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 93: Install The Body Covers

    Note: If you installed the power cord to the roof, guide it through the roof cover panel hole and into the groove before setting the roof cover panel into place. Make sure that the power cord is not damaged during the installation. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 94: Install The Bottom Body Covers

    Note: You only have to do this when installing for the first time. Slide the left-hand bottom body cover under the pod. Guide the edge of the cover into the groove under the floor. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 95 Guide the edge of the cover into the groove under the floor. Note: If you installed the power cord to the floor, make sure that you install the bottom body cover with the rubber lead-through on the side of the power cord. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 96: Install The Roof Body Covers

    If you have installed the power cord to the roof module, cut the notch out of the body cover. This is not necessary if you have installed the power cord to the floor module. Note: You only have to do this when installing for the first time. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 97 Guide the other edge of the body cover into the groove at the upper part of the wall. Repeat steps 2 and 3 to install the other curved roof body cover to the other side of the roof. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 98 Note: Make sure that the round circle in the body cover corresponds to the one in the roof. Guide the other edge of the body cover into the groove at the edge of the roof. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 99 Note: Make sure that the round circle in the body cover corresponds to the one in the roof. Guide the other edge of the body cover into the groove at the edge of the roof. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 100: Install The Wall Body Covers

    Note: If installing the optional whiteboard wall body covers, make sure that the sticker is in the upper right corner. Press the body cover into the upper groove with one hand and let go of the cover with your other hand. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 101 Note: Make sure that the wall body covers are installed evenly and aligned correctly with the other body covers. Use a white rubber mallet to tap the wall covers into alignment if needed. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...

  • Page 102: Finish The Installation

    18 Finish the installation Clean the glasses with glass washing liquid and a lint-free cloth. Connect the main power cord to a power outlet. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 103 Fill out the warranty checklist and send it to Framery. Note: The warranty is only valid with the filled-out warranty checklist. Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
  • Page 104 Framery Q Working with PAL Installation instructions info@frameryacoustics.com...
