Installation
Click
Thread the vehicle seat belt through the child
seat base and secure the belt into the belt
buckle.
Ensure the lap portion of the vehicle seat belt
fits under the red hooks and the diagonal
portion of the vehicle seat belt runs directly
from the belt buckle diagonally upwards.
Push the child car seat firmly backwards into
the vehicle seat, pull the diagonal belt tight to
remove any slack in the belt, then place the
diagonal belt into the lock-off device and
fasten it. Return the seat shell backwards and
refit the lower shaft into the child seat back
and lock into position.
Then pull out a small section of the upper
metal shaft, feed the diagonal belt between
the shaft and the seat shell, and secure the
upper metal shaft again.
Ensure that there are no kinks or twists in the
vehicle seat belt.
Installation
Extend the floor support leg fully out and
adjust the height of the floor support leg by
rotating the end. Make sure that the leg is
firmly in contact with the floor of the vehicle.
Fit your child with the harness system.
Group1(9-18kg)
Loosen the shoulder belts by pressing the
release button(1) and pulling the shoulder
belts towards you
!
Note Do not pull on the belt pads
Then open the harness buckle press the
red release button
Draw the belts over the hooks on the shell.
Put your baby comfortably with his her back
against the shell and make sure that there
are no toys or other hard objects in the shell
Slide buckle tongue sections together and
insert them into the buckle until you hear a click.
2 2
Pull the remaining slack out of the belt
system (4)
strap (1)
.
(2)
.
(
) .
(3)
/
&
pull the belts tight with the harness
.
