Five Positions Of The Child Car Seat; Group 1(9-18Kg) - Safeway SMART SPORT Isofix User Manual

Installation
Five positions of the car seat
The car seat can be used in five recline positions
Lift the handle, under the front of the seat, up
and pull or push the shell forwards or
backwards Release the handle in the
required position and push until you hear a
distinct click
Installing the child car seat using the ISOFIX system.

Group 1(9-18kg)

Place the seat forward facing in your vehicle.
Pull the lever to extend the ISOFIX
connectors.
Lock the two ISOFIX connectors into the
ISOFIX anchorage fixtures of the vehicle
The ISOFIX indicator will turn to green when
!
the connectors are locked to the anchorages.
Click
Pull and hold the ISOFIX adjusting lever, and
push the child seat backwards into the vehicle
seat. Release the lever when there is no space
between the child seat back and vehicle seat.
.
.
.
Installation
:
Installing the child car seat using the 3 point safety belt
with the floor support leg.
( -
Group 1 9 18kg
This child seat can also be installed with a 3-point safety belt,
however always in combination with the adjusted floor
support leg.
Extend the floor support leg fully out Adjust
the height of the floor support leg by rotating
the end,to ensure that the leg is touching
.
the floor of the vehicle firmly
-
)
Place the child seat on to the vehicle seat.
Pull the lower shaft out of the seat.
Adjust the child car seat into the most-reclined
,
position(1) then tilt the seat shell forward
,
.
(2)
