Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Published by Philips Consumer Lifestyle
12/11
TECHNICAL INFORMATION
- Voltage
- Power consumption
- Power standby
- Dimensions (w x d x h)
- Length power cable
- Colour setting
- SAP coding
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Before you start dismantling!
!
Printed in the Netherlands
Bread Maker
: 220 - 240 V, 50 - 60 Hz
: 650 W
: 0.5 W
: 300 x 340 x 310 mm
: 1.10 Meter
: White / Lavender
: HD9020
For your safety be sure the plug is
disconnected from the mains!
© Copyright reserved
HD9020
Subject to modification
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Philips HD9020
Summary of Contents for Philips HD9020
- Page 1 - SAP coding : HD9020 DISASSEMBLY- AND RE-ASSEMBLY ADVISE - Before you start dismantling! For your safety be sure the plug is disconnected from the mains! Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification 12/11...
