M101M8 Series Quick Start Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152111K1054 Please read these instructions carefully before using this product, and save this manual for future use.
Getting Started Congratulations on purchasing Winmate® M101M8 Rugged Android Tablet Computer. The rugged design allows you to use it in harsh outdoor environments. This quick start guide tells you step by step how to get the Tablet Computer up and running. You will find instructions for the following procedures: •...
Description of Parts Front: Right: Item Description Item Description Front Micro Memory card reader 2 Megapixel Webcam Camera SD Card port for Micro SD Reader Card Show the current status of the Tablet Micro High speed USB Computer Red: port connects to PC Charging / Hot-swap or USB devices such Indicators:...
Page 4
Rear: Bottom: No Item Description Item Description Kensington Provide lock access for Battery Spring-loaded Lock Port Kensington Lock. Release slider that latches Barcode Scanner for Slider the battery in. Optional reading of 1D / 2D Touch Pen Pen holder slot to Barcode barcode.
First-Time Operation Inserting Battery Pack To insert the standard battery pack into the Tablet Computer: 1. Disconnect AC adapter and power cord from the tablet computer. 2. Turn the tablet computer over, back facing up. 3. Locate the Battery Lock Latch and push it to the “Unlocked” position. 4.
Page 6
Connecting to Power Supply The Tablet Computer operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the Tablet Computer for the first time. Use only the AC adapter included with your Tablet CAUTION Computer.
Turning On and Off the Device This section describes how to turn on/ off the device. Turning On To turn on the device: 1. Press and hold the power button for 3 seconds, located on the top side of the unit. 2.
Page 8
Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
