- Page 1 Comfort Range Split Ducted systems 16/18/24 RCG 16 RCC & 18/24 RCC-S DS 16 RCG DS 18 RCG DS 24 RCG GC 16 RCC GC 18 RCC-S GC 24 RCC-S INSTALLATION INSTRUCTIONS DS / CAT. NO. 000000 / ENG REV. 02 09/2003...
-
Page 2: Ds Man. Menu
DISCONNECTION OF THE MAIN POWER SUPPL Y IS MANDATORY BEFORE OPERATING IN THE ELECTRIC BOX GENERAL RECOMMENDATIONS SAFETY ADVICES ❒ When you are operating on your equipment, follow the safety measures in force. ❒ Installation and maintenance of the units should be carried out exclusively by qualified personnel. -
Page 3: Table Of Contents
SUMMARY CONTENTS OF THE PARCEL ELECTRICAL CONNECTION SPECIFICATIONS GENERAL POINTS INSTALLATION INSTALLATION OF THE OUTDOOR UNIT COOLING LINKING PIPES BETWEEN INDOOR UNIT AND OUTDOOR UNIT LAY-OUT OF THE PIPES VACUUM OF THE COOLING PIPES AND INDOOR UNIT ACCESSORIES AVAILABLE ELECTRIC CONNECTIONS AIR SUCTION AND DISTRIBUTION CHECKING BEFORE STARTING OPERATION MAINTENANCE... - Page 4 CONTENTS OF THE PARCEL 1 DS bag with reference material warranty certificate sheet metal angle brackets bag with screws : 4 screws headed H M6 4 flat washers 8 x 30 4 flat washers 6 x 18 4 silentblocs 1 Infrared remote control 1 Remote infrared receiver 2 Configuration plugs REFRIGERANT PIPE CONNECTIONS...
-
Page 5: Electrical Connection Specifications
ELECTRICAL CONNECTION SPECIFICATIONS STANDARD / HEATPUMP INDOOR DS 16 RCG DS 18 RCG DS 24 RCG OUTDOOR GC 16 RCC GC 18 RCC-S GC 24 RCC-S Power supply 1/230V/50Hz COOLING+VENTILATION Main power supply cable section* 3CORES 3CORES 5CORES 3CORES 5CORES... -
Page 6: General Points
GENERAL POINTS LOCATION - Do not install the indoor unit in rooms where inflammable gas or acid or alkaline substances are stocked. The aluminum and copper evaporator and/or the internal plastic components could be damaged. - Do not install the indoor unit in workshops or kitchens where oil vapours attracted by treated air could set down on the evaporator of the indoor unit and change the performance or damage the internal plastic parts of the... -
Page 7: Installation Of The Outdoor Unit
- The drain pipe should be heat insulated with insulation PREPARATION OF THE PIPES material mm thick, such as polyurethane, - Use copper pipes of cooling quality and of a ∅ adapted propylane or neoprene, avoiding condensation. - If several units are placed in the room, the drain system to each model (see table on page 4). -
Page 8: Accessories Available
ELECTRIC CONNECTIONS The values of the tightening torque are shown in the table below. POWER SUPPLY The power supply is connected with the outdoor unit (except DS 16). Ø This appliance is meant to be permanently connected " 4 with a fixed cable. "... -
Page 9: Maintenance
ELECTRIC WIRES MAINTENANCE The appliances are meant to be permanently connected Before any action, SWITCH OFF the power switch. with a fixed electric cable. Do not use a socket, nor a flexible cable to supply power or to link the indoor unit with the The air filter is made of acrylic fibers and can be cleaned outdoor unit. - Page 10 FIG. 1a, 1b DS MAN. MENU...
- Page 11 FIG. 2 FIG. 3 FIG. 4 FIG. 5 A = 30 max. A = max. 30 FIG. 6 A = 30 máx. Silent bloc Slope of 1 cm/m Heat insulated drainpipe Large washer Counter-nut DS MAN. MENU...
- Page 12 FIG. 7 FIG. 8: GC18 & 24RCG WIRING CONNECTIONS 151.5 151.5 Connection on the top of the pipe AIR INTAKE AIR OUTLET FIG. 9: GC16RCG WIRING CONNECTIONS SUCTION TUBE (FLARED) LIQUID TUBE FIG. 11 (FLARED) VALVE CONNECTIONS R ≥ 3,5 ∅ 88.5 R ≥3,5 AIR INTAKE...
- Page 13 FIG. 13 FIG. 15 Linking > 9 meters A "GAS" pipe B "LIQUID" pipe FIG. 14 FIG. 16 DS MAN. MENU...
- Page 14 FIG. 17 A "GAS" pipe B "LIQUID" pipe C Flare nut D Pipe insulation E Insulating sleeve FIG. 18 Grille of decompression DS MAN. MENU...
- Page 15 FIG. 19 Table of high speed pressure S 16 RCG 200 Pa 400 Pa 667 Pa S 18 RCG 133 Pa 333 Pa 533 Pa Õ 4 RCG 266 Pa 400 Pa 933 Pa 1466 Pa h / . Correspondance of connection DS 16/18 RCG SPEED SELECTION TERMINAL BOARD 4 RCG...
- Page 16 FIG. 20 45 mm avec les 2 vis fournies. Fasten the bracket of the remote control on the wall. For connection and "How to Use", see MURC 715 supplied with the appliance - A 7m shielded cable with connectors at both ends is provided with the equipment for interconnecting the control panel and infrared receiver.
- Page 17 FIG. 21a DS 16 RCG GC 16 RCC GTW) Sensor wire coming from the DS *1 N ~ 230 V 50 Hz DS MAN. MENU...
- Page 18 FIG. 21b DS 18 RCG GC 18 RCC-S GTW) Sensor wire coming from the DS * 1 N ~ 230 V 50 Hz DS MAN. MENU...
- Page 19 FIG. 21c DS 24 RCG GC 24 RCC-S ensor wire co ing fro 1 N ~ 230 V - - - - With electric heating. DS MAN. MENU...
- Page 20 Single Phase units Power to Indoor Unit Model Interconnecting Cable Circuit Breaker Maximum Current Wires (mm (without Heating Element) GC16RCC 5 x 2.5 20 A 10.7 GC18RCC-S 5 x 2.5 20 A 11.4 Use power supply wire sizes as per local electrical codes and regulations. Figure 22a.
- Page 21 TEL: (09) 820 0333 517A Rosebank Road Avondale, Auckland NZ NZ Tech Support Freecall TEL: 0800 180 094 www.airwell.com.au WITH A CONCERN FOR A CONSTANT IMPROVEMENT, OUR PRODUCTS CAN BE MODIFIED WITHOUT NOTICE. PHOTOS NON CONTRACTUAL. © Copyright 2003 DS MAN. MENU...
