- Page 1 Indoor Unit Operation & Installation Manual AWSI-DCV048-N11 No. 0150513923 Please read this manual carefully before using Keep this operation manual for future reference...
-
Page 2: Table Of Contents
4.Now this indoor unit only has wired AWSI-DCV048-N11 DCV048 controller function,the indoor unit that has remote controller function need to set in The brief model is used in this manual for above models. -
Page 3: Parts And Functions
Parts and Functions indoor unit air outlet port flue flue Condensated water pan air inlet port... - Page 4 Parts and Functions Buttons of the wire controller Fan speed switch Swing switch Change wind speed Open and close air flap Mode switch Choose running mode TEMP switch Used for changing set temperature Health switch Used to control oxygen function and negative ion Time switch It is used to...
- Page 5 Parts and Functions Display of the wire controller Air volume display Centralized display Display the setting speed When controlled by centralized controller, and chosen by "centralize or lock" mode, this information is shown. Running mode display Running display Show the selected mode When the compressor runs, it displays.
- Page 6 Parts and Functions 5.HEALTH Button Remote controller Used to set health operation function. 6.CLOCK Button Used to set correct time. 7.TIMER Button Used to select TIMER mode:TIMER ON,TIMER OFF, TIMER ON-OFF. (Note: if the time of TIMER ON is the same as TIMER OFF, TIMER ON-OFF cannot be set) 8.
- Page 7 Parts and Functions 24.HIGN/SO Run Display When operating the remote controller in an area where electronically controlled lights are installed or wireless 25.Code A of controller's state handsets are used, please move closer to the indoor Code A is used for the units in this manual. unit as the function of the remote controller might be 26.SIGNAL SENDING Display affected by signals emitted by the above...
-
Page 8: Safety Considerations
Safety Considerations If the air conditioner is transferred to a new user, this manual shall be transferred to the user, together with the conditioner. Before installation, be sure to read Safety Considerations in this manual for proper installation. The safety considerations stated below is divided into “ Warning”... - Page 9 Safety Considerations Attention It is not allowed to put any heating 3-minute protection apparatus under the indoor units, for the To protect the unit, compressor can be heat may cause distortion of the units. actuated with at least 3-minute delay after stopping.
-
Page 10: Operation Instruction
Operation instruction ON/OFF operation Press ON/OFF switch on line controller directly The line controller displays the running state MODE SWING in the latest time (timing and swing state MODE may not be displayed). OPERATION HEALTH TEMP HIGH COOL 1. Press "ON/OFF" switch. The air conditioner starts operating, and the CLOCK TIME... - Page 11 Operation instruction Present time setting The timing is based on the real time. Thus, the real time should be regulated in advance. The clock regulation steps are as follows: 1.Press "CLOCK" switch "CLOCK" flickers, and the time displayed is MODE SWING the real time.
- Page 12 Operation instruction Timing setting OFF timing: when a set time has elapsed, the unit stops running. ON timing: when a set time has elapsed, the unit starts. Press “ON/OFF” switch firstly, and set up operation mode. MODE SWING Please regulate the clock in advance before using the MODE OPERATION...
- Page 13 Operation instruction Query indoor malfunction history: In the state of power on or power off, press [CHECK] button, enter the malfunction-querying mode of all indoor units in the group. Then [CHECK] and [UNIT NO.] will display, and the actual indoor numbers will be displayed in some sequence (unit number is in decimals). At the same time, in the time region, there will be the current malfunction and the latest time malfunction, the displaying format is [XX:YY], in which XX stands for the current malfunction, if normal, it will display "--";...
- Page 14 Operation instruction AUTO, COOL , HEAT and DRY Operation (1) Unit start Press ON/OFF button, the unit starts. Previous operation status appears on LCD (except for TIMER,SLEEP and SWING setting) (2) Select operation mode Press MODE button. Each press, the operation mode changes as follows: Code A TEMP...
- Page 15 Operation instruction Fan Operation (Only for Code A) (1) Unit start Press ON/OFF button to start your air conditioner. Previous operation status appears on LCD (except for TIMER, SLEEP, and SWING setting). (2) Select operation mode Press MODE button. Each press, the operation mode changes as follows: AUTO COOL DRY...
- Page 16 Operation instruction Adjusting Air Flow Directon Adjusting air flow direction Press SWING button. Up and down airflow varies upwards and downwards. Left and right airflow varies left and right sides. When the automatic swing louver moves to the proper angle, press SWING button to fix the airflow direction. After unit stops: Displays on the LCD disappear.
-
Page 17: Min. Db
Operation instruction Timer ON/OFF Function Set clock correctly before starting TIMER operation. (1) Unit start After unit start, select your desired operation mode (operation mode will be displayed on LCD). (2) TIMER mode selection Press TIMER button on the remote controller to change TIMER mode. - Page 18 Maintenance Only when the air cleaner is switched off and disconnected to the power supply can it be cleaned, or electric shock and injury may appear. Cleaning the air outlet port and the shell: Attention Don’t use gasoline, benzene, diluents, polishing powder or liquid insecticide to clean them. Do not clean them with hot water of above 50 to avoid fading or distorting.
- Page 19 Fault Checkup Please check the following when consigning repair service: Symptoms Reasons Water flow sound can be heard when starting operation, during operation or immediately after stopping operation. When it starts to work for 2-3 minutes, the sound may become louder, which is Water flow sound the flowing sound of refrigerant or the draining sound of condensed water.
-
Page 20: Min. Db
Installation Procedures The standard attached accessories of the units of this series refer to the packing; prepare other accessories according to the requirements of the local installation point of our company. 1. Before installation [before finishing the installation, don’t throw away the attached parts required for the installation] Determine the route to move the unit to the installation site;... - Page 21 Installation Procedures (2) If necessary, make a hole for installation and inspection on the ceiling. (used for the situation with a ceiling) For the size of the inspection hole on the ceiling, please refer to the above drawing. Before installation, finish all the preparations for all piping connected to indoor units (refrigerant, water drainage) and wiring (connection line of the line control, connection line between indoor units and outdoor unit) so that they can be connected with indoor units right after installation.
- Page 22 Installation Procedures Static Pressure Range standard blowing wind (at delivery) high-speed blowing wind unit: Pa white white white black Standard Max. blue blue blue white Static Static yellow yellow yellow blue Pressure Pressure 4. Drainpipes (a) Keep a gradient (1/50-1/100) of the drainpipes and avoid lobing or curving. Proper Piping Improper Piping hanging bolt...
-
Page 23: Max. Db
Airwell. Calculate the design (purchase special exhaust chart and exterior static pressure, exhaust pipe d at local port (purchased at... - Page 24 Installation Procedures The length difference between pipes should be limited to be less than 2:1; Make the piping as short as possible; incorrect incorrect correct Keep the min. elbow quantity; Wind the heat insulating material around the flange between the main unit and the exhaust pipe for heat insulation and sealing.
- Page 25 Installation Procedures 7. Cautions in Installation of Air Return Pipe & Exhaust Pipe It is recommended to use the blast pipes, which special exhaust port can be anti-condensation and absorb sound. positioning with bolt (purchased at local shops) Complete the installation of the blast pipes before fitting up the suspended ceiling.
- Page 26 Installation Procedures Tubing Materials & Specifications liquid pipe cabinet of electric appliance gas pipe upside Model DCV048 Gas pipe 15.88 Tubing Size (mm) Liquid pipe 9.52 Tubing Phosphor deoxybronze seamless Material pipe (TP ) for air conditioner downside water drainage joint VP25 PVC hose Refrigerant Filling Amount Add the refrigerant according to the installation instruction of outdoor unit.
- Page 27 Installation Procedures 1. Take down wire controller from the holder Wire controller 52!0.2 MODE SWING MODE CENTRAL AUTO AUTO OPERATION TEMP HEALTH FAN ONLY HIGH STANDBY COOL PRE-HEAT DEFROST HEAT FILTER CLOCK TIME HEALTH CHECK SWING UNIT NO. DEMAND MANUAL CEN.
- Page 28 Electrical Wiring Warning Electrical construction should be made with specific mains circuit by the qualified personnel according to the installation instruction. Electric shock and fire may be caused if the capacity of power supply is not sufficient. During arranging the wiring layout, specified cables should be used as the mains line, which accords with the local regulations on wiring.
-
Page 29: Max. Db
Electrical Wiring Signal Wiring Drawing outdoor 1 outdoor 3 outdoor 2 P Q A B C A B C A B C control wire for wired controller with polarity communication wire with polarity indoor 5 indoor 4 indoor 3 indoor 1 indoor 2 P Q A B C P Q A B C... - Page 30 Electrical Wiring The combination of multiple indoor units can be controlled by wired controller or remote controller. Switching Mode of Line-Controlled Main Unit/ Line-Controlled Sub Units/ Remote-Controlled Types can be used for switching over Setting Master Remote Wired 1# Remote Wired Wireless Remote Mode Socket/...
- Page 31 Electrical Wiring Dip switch setting Indoor PCB In the following table, 1 is ON, 0 is OFF. SW01 is used for indoor unit group control address setting and capacity selection. CN44,CN42,CN43 are used for indoor unit type selection. CN41 is used for addressing by wired controller. SW03 is used for indoor unit address setting (including physical address and central address).
- Page 32 Electrical Wiring (3) Description of SW03 Set the address with wired controller or Manner of automatism (default) SW03_1 address Set the address with dip switch Commu Central [6] [7] [8] nication control address address *Note Set the 1. The address must be set by Commun (default) (default)
- Page 33 Electrical Wiring (5) Description of jump wire:SW08(1:ON, 2:OFF) (6) Jumper explanation a) EEV operation manually Normal mode(default) (CN27, CN29) Fix air volume Air volume is fixed at high speed (for duct CN27: short circuit CN27 2 type) seconds continuously, EEV Run at Mid speed Normal mode(default) is openned fully.
-
Page 34: Max. Db
Functions of Wired Controller Operation of Wired/Remote Controllers & Initialization process of line control: During the initialization of line control after powered on, [8888]'[888]'[88]'[8] for the wired controllers and LED flash for about 30 seconds. At this time, all buttons are disabled. ( Descriptions of other components and operating methods refer to the related operating guide. -
Page 35: Test Run & Fault Code
Test Run & Fault Code Before Test Run Before switching it on, test the supply terminal tier (L, N terminals) and grounding points with 500V ". It can’t be operated if it is below 1 ". megaohm meter and check if the resistance is above 1 Connect it to the power supply of outdoor units to energize the heating belt of the compressor. - Page 36 Disposal DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal there are several possibilities: a) The municipality has established collection systems, where electronic waste can be disposed of ate least free of charge to the user.
