REVO TOUCH
Operating Manual

Advertisement

Table of Contents
loading

Summary of Contents for RIKA REVO TOUCH

  • Page 1 REVO TOUCH Operating Manual...
  • Page 2: Table Of Contents

    TABLE OF CONTENT 1. PREFACE Explanations to symbols ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������3 Spare part overview exploded diagram �����������������������������������������������������������������������������������������������������������������������������������������������������4 Spare part overview article numbers ���������������������������������������������������������������������������������������������������������������������������������������������������������6 Dimensions ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Technical data �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Amount of fuel �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Packaging �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Electrical connection ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 2. IMPORTANT INFORMATION General warning and safety information ��������������������������������������������������������������������������������������������������������������������������������������������������8 First heating����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������8 Safety distances ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������8 Prior to set up �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������9...
  • Page 3: Preface

    7. COMFORT OPTIONS Room sensor, Radio room sensor ������������������������������������������������������������������������������������������������������������������������������������������������������������14 GSM Control �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������14 Interface for various options �������������������������������������������������������������������������������������������������������������������������������������������������������������������14 External room thermostat ����������������������������������������������������������������������������������������������������������������������������������������������������������������������14 External connection cable bridge ������������������������������������������������������������������������������������������������������������������������������������������������������������14 Option firenet �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������14 8. MAINTENANCE Open the combustion chamber door ������������������������������������������������������������������������������������������������������������������������������������������������������15 Cleaning of the burn pot - daily �������������������������������������������������������������������������������������������������������������������������������������������������������������15 Cleaning the flame temperature sensor ��������������������������������������������������������������������������������������������������������������������������������������������������15 Empty the ash drawer �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������15 Cleaning the door glass ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������15...
  • Page 4: Spare Part Overview Exploded Diagram

    Spare part overview exploded diagram...
  • Page 6: Spare Part Overview Article Numbers

    Spare part overview article numbers Art.Nr. Description Art.Nr. Description Art.Nr. Description L01441 Pressure bracket Z33692 Fire trough holder B16030 Additional motherboard for motor, incl. cable L01447 Ash drawer B16320 Cleaning opening metallic B16058 Wiring harness for key display 3 *1 B15621 Key display B16352...
  • Page 7: Dimensions

    Dimensions Technical data Heating power range [kW] 2,5 - 9 Room heating capacity (depending on house [m³] 50 - 240 insulation) Fuel consumption [kg/h] up to 2,1 Pellet container capacity* [l/kg] 59/~38 Electric supply [V]/[Hz] 230/50 Average electrical input Fuse 2,5 AT Efficiency 91,1...
  • Page 8: Important Information

    First heating RIKA stoves should only be installed in rooms with normal humidity (dry The stove body, just as various steel parts, cast iron parts and the flue pipes areas according to VDE 0100 Part 200). The furnaces are not splash water are painted with a heat resistant paint.
  • Page 9: Prior To Set

    Prior to set up Stoves type 1 (BA 1): Suitable for multiple occupancy. (Note the different country regulations.) Floor bearing capacity Ensure that the substructure is capable of bearing the weight of the stove prior These may only be operated with the combustion chamber door closed. to set-up.
  • Page 10: Brief Information On Fuel - Pellets

    3. BRIEF INFORMATION ON FUEL - PELLETS Your pellet stove is only approved for the burning of pellets of tested quality. What are pellets? Please ask your pellet stove dealer for tested fuel and a list of monitored fuel manufacturers. Wood pellets are a standardised fuel.
  • Page 11: Technology And Safet Y Functions

    4. TECHNOLOGY AND SAFET Y FUNCTIONS The technological advances in your new combi stove are the result of years of Automatic cleaning cycle testing and practical experience. The practical advantages of your pellet stove are convincing: The speed of the flue gas fan is increased every hour for a short period to blow ash from the burn pot, increasing the operational safety.
  • Page 12: Installing The Stove

    Ø50mm (pellet stoves) and fix it with a hose clamp (not included!). We recommend original flue pipes from RIKA for proper connection. At pellet stoves with longer intake pipes than 1m the diameter should be increased to 100mm. (see RIKA range).
  • Page 13: Assembly/Dismantling Stone And Options

    6. ASSEMBLY/DISMANTLING STONE AND OPTIONS Disassembly of the rear side panel Note Only work on the unit when the mains plug has been disconnected and the Open the container lid. stove has cooled completely. Note During assembly / dismantling do not allow objects (screws etc.) to fall into the pellet container –...
  • Page 14: Comfort Options

    7. COMFORT OPTIONS Room sensor, Radio room sensor External room thermostat This option permits control of your stove via room temperature. You can set Your stove has an interface on the rear wall to which you can connect a both the room temperature and the heating times required. A room temperature customary room thermostat.
  • Page 15: Maintenance

    We recommend at least once a year to have all maintenance carried out by The viewing window becomes coated in the case of solid fuels, particularly with your RIKA dealer. the very fine ash of wood pellets, light or dark depending on the pellet quality (especially with low output).
  • Page 16: Cleaning

    9. CLEANING Cleaning flue gas channels Your RIKA dealer will gladly advise you about their service and maintenance The flue gas channels are situated on the side of the combustion chamber. offers. Remove the convection fins by lifting slightly. The convection fins are only suspended.
  • Page 17: Clean Flue Gas Collecting Channel

    Clean flue gas collecting channel Cleaning the flue pipes Open the firebox door. (annually) Loosen the two hex head screws and remove the lower front panel. Remove the flue pipes. Inspect and clean the chimney connection. Brush off any soot and dust deposits in the fire and in the flue pipes and vacuum. Note Accumulated fly ash in the flue gas channels may impair the performance of the stove and pose a safety risk.
  • Page 18: Problems - Possible Solutions

    10. PROBLEMS - POSSIBLE SOLUTIONS Problem 1 Problem 3 Fire burns with weak, orange flame. Pellets heap up in fire trough, window Flue gas discharge when wood is added and during heating phase. soots up. Cause(s) Cause(s) Leaking cleaning openings Insufficient combustion air Chimney draught too low Poor chimney draught...
  • Page 19: Instructions For Commissioning Protocol

    Note points, is a document. Please return 1 completed protocol for putting into service to RIKA Innovative Ofentechnik GmbH, Müllerviertel 20, 4563 Micheldorf, Austria. Warranty terms Difference between warranty (statutory) and guarantee (voluntary), terms of guarantee, determination of wearing parts, reference to pellet quality to be Electrical periphery used and the consequences of poor quality.
  • Page 20 Please contact your warranty partner for any warranty questions or claims. This is your dealer or installation company. No warranty claims can be accepted without proper putting into operation, proper operation according to the operating instructions and the supplements in this information sheet. Protocol for putting into operation for RIKA pellet and combi stoves Date:____________________...
  • Page 21: Warrant Y

    In case of doubt as well as missing or incorrect translations, the German version is the only valid one. For the purpose of timely damage limitation the claimant is required to file the warranty claim with the RIKA dealer in writing, submitting the invoice and stating the purchase date, model name, serial number and reason for complaint.
  • Page 24 German version is the only valid one. 4563 Micheldorf / AUSTRIA Technical and design changes, as well as typesetting Tel.: +43 (0)7582/686 - 41, Fax: -43 and printing errors reserved. E-Mail: verkauf@rika.at www.rika.at © 2019 | RIKA Innovative Ofentechnik GmbH...
