- Page 1 FILO FILO RAO Operating Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENT 1. PREFACE Explanations to symbols ...................................3 Spare part overview exploded diagram ..............................4 Spare part overview article numbers .................................6 Dimensions ......................................7 Amount of Fuel ......................................7 Technical data ......................................7 Packaging .........................................7 Electrical connection ....................................7 2. IMPORTANT INFORMATION General warning and safety information ..............................8 First heating......................................8 Safety distances ......................................8 Prior to set up ......................................9... -
Page 3: Preface
7. CLEANING AND MAINTENANCE Basic information ....................................15 Open the combustion chamber door ..............................15 Cleaning the convection air openings ..............................15 Combustion air - intake ..................................15 Cleaning the door glass ..................................15 Cleaning of painted surfaces ...................................15 Cleaning of the burn pot - daily ................................15 Empty the ash drawer .....................................15 Cleaning the flame temperature sensor ..............................15 Cleaning flue gas paths ...................................16... -
Page 4: Spare Part Overview Exploded Diagram
Spare part overview exploded diagram 1 0 0 1 0 1 1 2 3 1 2 2 1 2 0 1 2 1 1 2 6 1 2 6 1 2 4 1 2 5... - Page 5 1 0 9 1 0 5 1 0 2 1 0 4 1 0 3 1 0 6 1 1 0 1 0 7 1 0 8...
-
Page 6: Spare Part Overview Article Numbers
Spare part overview article numbers Art.Nr.: Description Art.Nr.: Description Art.Nr.: Description Combustion chamber N110461 Double ball catch Side panel rust effect Z35730 B17612 door black right L01502 Lock washer Sealing cord black Side panel glass black N111459 Allen screw N100476 B17619 Ø10mm right... -
Page 7: Dimensions
Dimensions Technical data RO-T3 Technical data Heating power range [kW] 2,4 - 8 2,4 - 8 Room heating capacity [m³] 50 - 220 50 - 220 (depending on house insulation) Fuel consumption [kg/h] 0,6 - 1,8 0,6 - 1,8 Pellet container capacity [kg] ca. -
Page 8: Important Information
First heating RIKA stoves should only be installed in rooms with normal humidity (dry The stove body, just as various steel parts, cast iron parts and the flue pipes areas according to VDE 0100 Part 200). The furnaces are not splash water are painted with a heat resistant paint. -
Page 9: Prior To Set Up
Prior to set up Stoves type 1 (BA 1): Floor bearing capacity Suitable for multiple occupancy. (Note the different country regulations.) Ensure that the substructure is capable of bearing the weight of the stove prior to set-up. These may only be operated with the combustion chamber door closed. Note The combustion chamber door is to be kept closed when the stove is not No modifications may be made to the firing installation. -
Page 10: Brief Information On Fuel Pellets
3. BRIEF INFORMATION ON FUEL PELLETS Your pellet stove is only approved for the burning of pellets of tested quality. What are pellets? Please ask your pellet stove dealer for tested fuel and a list of monitored fuel manufacturers. Wood pellets are a standardised fuel. Every manufacturer must adhere to certain conditions in order to enable flawless, energy-efficient heating. -
Page 11: Technology And Safet Y Functions
4. TECHNOLOGY AND SAFET Y FUNCTIONS The technological advances in your new combi stove are the result of years of Automatic cleaning cycle testing and practical experience. The practical advantages of your pellet stove are convincing: The speed of the flue gas fan is increased every hour for a short period to blow ash from the burn pot, increasing the operational safety. -
Page 12: Installing The Stove
The stove can also be pushed on this cardboard or carpet. Feeding in external combustion air We recommend original flue pipes from RIKA for proper connection. only for devices which are able to run in room-air independent operation. Connection to the chimney Combustion air must be fed to the stove from outside via a sealed pipe for operation independent of the room air. -
Page 13: Changing The Connection To The Left Side
Select soft bases to prevent scratches to your living space furniture and stove panels. Place the 90 degree elbow with cleaning lid (not included, RIKA standard flue pipe) on the flue outlet. Make sure that everything is tight! Open the pellet hopper lid. -
Page 14: Comfort Options
6. COMFORT OPTIONS Room sensor, Radio room sensor External connection cable bridge This option permits control of your stove via room temperature. You can set (condition as delivered) both the room temperature and the heating times required. A room temperature selected by you is observed during the heating times. -
Page 15: Cleaning And Maintenance
7. CLEANING AND MAINTENANCE Basic information Cleaning of the burn pot - daily Make sure that the air vents are not blocked with ash or clinker. Remove the Note clinker using the supplied wire brush and vacuum the burn pot. The burn pot can Your stove must be switched off and cooled before any maintenance work is be easily cleaned inside the stove. -
Page 16: Cleaning Flue Gas Paths
Cleaning flue gas paths Open the combustion chamber door. The flue pipes should be cleaned at least 2 x a year or after approx. 700 kg pellets. The flues are situated under and behind the combustion chamber. Note Only work on the unit when the mains plug has been disconnected and the stove has cooled down completely. -
Page 17: Cleaning The Flue Gas Channels
Cleaning the pellet container Remove the cleaning lid and vacuum the combustion residues with a vacuum cleaner. Do not refill the completely empty container immediately; remove the residues (dust, chippings etc.) from the empty container. The unit must be disconnected from the mains! Bearings (annually) -
Page 18: Problems Possible Solutions
8. PROBLEMS POSSIBLE SOLUTIONS Problem 1 Problem 3 Fire burns with weak, orange flame. Pellets heap up in fire trough, window Flue gas discharge when wood is added and during heating phase. sooted up. Cause(s) Cause(s) Inspection openings leak Insufficient combustion air Chimney draught too low Poor chimney draught Flue pipe connection leaks... -
Page 19: Instructions For Commissioning Protocol
Note points, is a document. Please return 1 completed protocol for putting into service to RIKA Innovative Ofentechnik GmbH, Müllerviertel 20, 4563 Micheldorf, Austria. Warranty terms Difference between warranty (statutory) and guarantee (voluntary), terms of guarantee, determination of wearing parts, reference to pellet quality to be Electrical periphery used and the consequences of poor quality. - Page 20 Please contact your warranty partner for any warranty questions or claims. This is your dealer or installation company. No warranty claims can be accepted without proper putting into operation, proper operation according to the operating instructions and the supplements in this information sheet. Protocol for putting into operation for RIKA pellet and combi stoves Date:____________________...
-
Page 21: Guarantee
In case of doubt as well as missing or incorrect translations, the German version is the only valid one. For the purpose of timely damage limitation, the warranty claim on the part of the claimant is to be enforced at the RIKA dealer in writing using the invoice and stating the purchase date, model name, serial number and reason for complaint. - Page 24 Technical and design changes, as well as typesetting and printing errors reserved © 2016 | RIKA Innovative Ofentechnik GmbH RIKA Innovative Ofentechnik GmbH 4563 Micheldorf / Austria, Müllerviertel 20 Telefon: +43 7582 686 - 41, Fax-DW: 43 E-Mail: verkauf@rika.at RIKA.AT...
