Sparkfun Electronics LilyPad ProtoSnap Plus Hook-Up Manual page 3

1/22/2018
Sensor (S)
LilyPad
Buzzer (+)
LilyPad
Button
2x LilyPad Y
LEDs (+)
2x LilyPad
R LEDs (+)
2x LilyPad
G LEDs (+)
2x LilyPad B
LEDs (+)
LilyPad
Switch
Expansion
Port A9
Expansion
Port (+)
Expansion ~10/SCL
Port
~10/SCL
Expansion
Port 11/SDA
Expansion
Port (-)
All
components
(-)
Powering the LilyPad ProtoSnap Plus
The LilyPad ProtoSnap Plus can be powered in two ways:
https://learn.sparkfun.com/tutorials/lilypad-protosnap-plus-hookup-guide?_ga=2.234157401.659504291.1516640116-204410570.1509632255
LilyPad ProtoSnap Plus Hookup Guide - learn.sparkfun.com
A3 A buzzer that create tones controlled
A4 LilyPad USB Plus receives button
A5 A pair of yellow LEDs controlled by
~6 A pair of red LEDs controlled by
~A7 A pair of green LEDs controlled by
~A8 A pair of blue LEDs controlled by
A9 LilyPad USB Plus receives switch
state (on/off) input to change modes.
A9 Clippable pads to connect another
LilyPad piece to. Shares connection
with the LilyPad Switch.
(+) Clippable pads connected to LilyPad
USB Plus's power (+) sew tab.
Clippable pads connected to LilyPad
USB Plus's sew tab 10. This can be
used to connect to a I2C clock pin.
11/SDA Clippable pads connected to LilyPad
USB Plus's sew tab 11. This can be
used to connect to a I2C data pin.
(-) Clippable pads connected to LilyPad
USB Plus's ground (-) sew tab.
(-) All components share a common
ground connection back to the
by LilyPad USB Plus.
press input.
LilyPad USB Plus.
LilyPad USB Plus.
LilyPad USB Plus.
LilyPad USB Plus.
LilyPad USB Plus.
3/23
