Features:
USB port for connecting to a computer.
Two sets of power (+) and ground (-) sew tabs.
Built-in RGB LED attached to pins 12 (R), 13 (G), and 14 (B).
A row of six white LEDs attached to pins 15-20.
Charging circuit for single-cell (3.7V) Lithium-Polymer batteries.
Some of the sew tabs on the LilyPad USB Plus have special functionality:
An 'A' in front of the number denotes a tab that can function as an
sensors that output a varying voltage like the light sensor built into the ProtoSnap Plus.
A '~' symbol in front of the number indicates that tab supports
These tabs can output an "analog" signal that can be used to vary the brightness on LEDs, etc.
Note: The "A" in front of analog sew tab numbers in your code is optional. However, do not include the "~"
symbol for PWM outputs. It is only provided to make it easy for you to check which pins can produce PWM
(analog) output and is not used in programming.
Below is a table that lists the components connected to the LilyPad USB Plus sew tabs.
LilyPad Connected
Component to LilyPad
USB Plus
Sew Tab
LilyPad
Light
https://learn.sparkfun.com/tutorials/lilypad-protosnap-plus-hookup-guide?_ga=2.234157401.659504291.1516640116-204410570.1509632255
LilyPad ProtoSnap Plus Hookup Guide - learn.sparkfun.com
A2 LilyPad USB Plus receives ambient
light level input from light sensor.
analog
PWM (Pulse Width Modulation)
Description
input. These sew tabs can read
output.
