Buzzer
Button
Yellow LED
Red LED
Green LED
Blue LED
Switch / Expansion Port
Expansion Port / SCL
Expansion Port / SDA
RGB LED - Red
RGB LED - Green
RGB LED - Blue
Bar Graph LED 0
Bar Graph LED 1
Bar Graph LED 2
Bar Graph LED 3
Bar Graph LED 4
Bar Graph LED 5
SCLK
MOSI
MISO
Expansion Port A9 Notes
If you look closely at the ProtoSnap board, you'll notice that sew tab A9 is shared between the switch and an
expansion port. Because of this, remember: if you're using the A9 expansion port, ensure that the switch is
turned OFF to keep the input or output signal from shorting to ground.
https://learn.sparkfun.com/tutorials/lilypad-protosnap-plus-hookup-guide?_ga=2.234157401.659504291.1516640116-204410570.1509632255
LilyPad ProtoSnap Plus Hookup Guide - learn.sparkfun.com
3
4
5
~6
~7
~8
9
~10
11
(~12)
(~13)
(~14)
(15)
(16)
(17)
(18)
(19)
(20)
[21]
[22]
[23]
A3
A4
A5
A7
A8
A9
