ASSEMBLY
MODEL # AXCHOL005-72-NAB
STEP 10
1. Attach 3 Cam Lock Pins 2 into pre-drilled holes on bottom of Top A ( at center ).
2. Align Cam Lock Pins with pre-drilled holes on Top Divider H .
3. Insert 3 Cam Locks 2 into pre-drilled holes on Top Divider H .
4. Use flathead screwdriver to secure Cam Lock .
5. Attach 2 Sides E and 2 Dividers F to bottom of Top A using 12 Allen Key Screws 1
( 3 Allen Key Screws/ each part ).
16/22
