- Page 1 S IMP HOME ® LOWRY / MITCHELL / FULTON TV MEDIA STAND MODEL # AXCLRY-08GR...
- Page 2 S IMP HOME ® Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –4 pm EST or go to www.simpli-home.com/parts request In order to assist you in a timely manner, please have the following...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 4: Care And Maintenance
IMPORTANT : Keep this manual for future reference. CARE and MAINTENANCE Wood Furniture Care Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. -
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # AXCLRY-08GR PART DESCRIPTION LEFT SIDE BOTTOM SHELF QTY 1 QTY 1 QTY 1 RIGHT SIDE LEFT DIVIDER RIGHT DIVIDER QTY 1 QTY 1 QTY 1 DOOR (L&R Same) SIDE SHELF MIDDLE SHELF QTY 2 QTY 2 QTY 1 Warning Label BACK PANEL... -
Page 6: Hardware Description
PRE-ASSEMBLY INFORMATION MODEL # AXCLRY-08GR HARDWARE DESCRIPTION LOCK WASHER WASHER ALLEN KEY BOLT ALLEN KEY SCREW M8 x 20 mm M6 X 30mm Ø12 / Ø8 x 1.5 mm Ø19 / Ø8 x 1 mm QTY 12 QTY 24 QTY 12 QTY 12 PHILLIPS SCREW ALLEN KEY... - Page 7 COMPONENTS-KEY DIAGRAM MODEL # AXCLRY-08GR...
- Page 8 ASSEMBLY MODEL # AXCLRY-08GR STEP-1 & 1. Insert two Dowels 11 into drilled holes on each Left Divider DL and Right Divider DR . 2. Use rubber mallet to tap Dowels 11 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 9 ASSEMBLY MODEL # AXCLRY-08GR STEP-2 1. Attach Right Divider DR and Left Divider DL to Bottom Shelf B using six Allen Key Screws 4 . 2. Use Allen Key 5 to tighten screws. Do not over-tighten.
- Page 10 ASSEMBLY MODEL # AXCLRY-08GR STEP-3 & 1. Insert two Dowels 11 into drilled holes on each Left Side CL and Right Side CR . 2. Use rubber mallet to tap Dowels 11 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 11 ASSEMBLY MODEL # AXCLRY-08GR STEP-5 1. Repeat Step-4 for Right Side CR .
- Page 12 ASSEMBLY MODEL # AXCLRY-08GR STEP-6 1. Attach Top A to Sides CL , CR using six Allen Key Screws 4 ( three Screws / each Side ). 2. Attach Top A to Dividers DL , DR using six Allen Key Screws 4 ( three Screws / each Side ).
- Page 13 ASSEMBLY MODEL # AXCLRY-08GR STEP-7 1. Attach Legs I to Bottom Shelf B . 2. Use twelve Allen Key Bolts 1 , twelve Lock Washers 2 and twelve Washers 3 to secure part I and B (six Bolts, six Lock Washers and six Washers on each Leg). 3.
- Page 14 ASSEMBLY MODEL # AXCLRY-08GR STEP-8 NOTE: The screwdriver is not included in the hardware pack. Warning Label 1. Attach the Top Back Panel H to back frame by using Phillips Screws 6 .
- Page 15 ASSEMBLY MODEL # AXCLRY-08GR STEP-9 1. Attach Adjustable Hinges 12 to Doors E using Phillips Screws 10 into guide holes on Doors E .
- Page 16 ASSEMBLY MODEL # AXCLRY-08GR STEP-10 1. Attach Adjustable Hinges 12 on Doors E to Sides CL , CR using Phillips Screws 10 into guide holes on Sides CL , CR . 2. Attach Magnets 7 using Phillips Screws 9 into guide holes on Left Divider DL and Right Divider DR .
-
Page 17: Important Note
ASSEMBLY MODEL # AXCLRY-08GR IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1. Side adjustment 4 mm To move the door towards the side panel, loosen screw I and tighten screw II . - Page 18 ASSEMBLY MODEL # AXCLRY-08GR STEP-11 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 F & 1. Use four Shelf Supports 8 for each Shelf F , G in desired location . 2. Two Shelf Supports 8 may be used on back top of each Shelf F , G as a tipping restraint.
- Page 19 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP-12 NOTE: The screwdriver is not included in the hardware pack.
- Page 20 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 21: Warranty
S IMP HOME ® WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights.
