Summary of Contents for Simpli Home 3AXCCOS72
- Page 1 SIMP HOME L I F E B Y D E S I G N COSMOPOLITAN / CITY / ESSEX 72 INCH WIDE TV MEDIA STAND MODEL # 3AXCCOS7 1/21...
- Page 2 SIMP HOME L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. -
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # 3AXCCOS72 PARTS DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF TOP SHELF CENTRE SHELF QTY 1 QTY 1 QTY 1 TOP DIVIDER LEFT MIDDLE DIVIDER RIGHT MIDDLE DIVIDER QTY 1 QTY 1... - Page 6 PRE-ASSEMBLY INFORMATION MODEL # 3AXCCOS72 PARTS DESCRIPTION LEFT SHELF LEFT DIVIDER RIGHT DIVIDER QTY 1 QTY 1 QTY 1 RIGHT SHELF SMALL DOOR (L&R Same) LARGE DOOR (L&R Same) QTY 1 QTY 2 QTY 2 LEFT BACK PANEL RIGHT BACK PANEL...
- Page 7 PRE-ASSEMBLY INFORMATION MODEL # 3AXCCOS72 PARTS DESCRIPTION FLIP DOWN DOOR BOTTOM BACK PANEL BOTTOM SUPPORT LEG QTY 1 QTY 2 QTY 1 DRAWER FRONT LEFT DRAWER SIDE RIGHT DRAWER SIDE QTY 1 QTY 1 QTY 1 DRAWER BACK DRAWER BOTTOM...
-
Page 8: Hardware Description
PRE-ASSEMBLY INFORMATION MODEL # 3AXCCOS72 HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN ALLEN KEY M6 X 30 mm CAM LOCK QTY 1 QTY 34 QTY 22 SETS HANDLE PHILLIPS SCREW ROUND HEAD M4 X 25 mm M4 X 15 mm... - Page 9 COMPONENTS – KEY DIAGRAM MODEL # 3AXCCOS72 9/21...
- Page 10 ASSEMBLY MODEL # 3AXCCOS72 STEP 1 1. Attach 4 Cam Lock Pins 2 to back of Drawer Front O . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides PL , PR . 3. Insert 2 Cam Lock 2 into pre-drilled holes on each Drawer Side PL , PR .
- Page 11 ASSEMBLY MODEL # 3AXCCOS72 STEP 3 1. Align Drawer Back Q with Drawer Bottom R and press firmly into slot . 2. Attach back using 2 Allen Key Screws 1 through pre-drilled holes on each side. 3. Use Allen key 3 to tighten. Do not over tighten.
- Page 12 ASSEMBLY MODEL # 3AXCCOS72 STEP 5 1. Insert 6 Dowels 12 into Centre Shelf E . 2. Use rubber mallet to tap Dowels 12 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3. Align Dowels 12 with pre-drilled holes and attach Middle Divider GL , GR .
- Page 13 ASSEMBLY MODEL # 3AXCCOS72 STEP 7 1. Attach 3 Cam Lock Pins 2 to each Divider HL , HR . 2. Align Cam Lock Pins pre-drilled holes and attach Top Shelf D . 3. Insert 6 Cam Lock 2 into pre-drilled holes on Top Shelf D .
- Page 14 ASSEMBLY MODEL # 3AXCCOS72 STEP 9 1. Insert 4 Dowels 12 into Bottom Shelf C . 2. Use rubber mallet to tap Dowels 12 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3. Attach 3 Cam Lock Pins 2 to each Side BL , BR .
- Page 15 ASSEMBLY MODEL # 3AXCCOS72 STEP 10 1. Insert 2 Dowels 12 into top corners of each Side BL , BR . 2. Use rubber mallet to tap Dowels 12 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 16 ASSEMBLY MODEL # 3AXCCOS72 STEP 11 1. Attach Back Panels LL , LR , L1 , L2 to back of TV stand using Phillips Screws Round Head 5 into pre-drilled guide holes. 2. Use Phillips screwdriver to tighten screws. 16/21...
- Page 17 ASSEMBLY MODEL # 3AXCCOS72 STEP 12 1. Attach hinges on Large Doors J and Sides BL , BR using Phillips Screw 9 . 2. Attach hinges on Small Doors K and Dividers HL , HR using Phillips Screw 9 .
- Page 18 ASSEMBLY MODEL # 3AXCCOS72 STEP 13 1. Use 4 Shelf Supports 8 for each shelf IL , IR in desired location. 2. 2 Shelf Supports 8 may be used on back top of each shelf IL , IR as a tipping restraint.
- Page 19 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. NOTE: The screwdriver is not STEP 14 included in the hardware pack.
- Page 20 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 21: Warranty
L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
