Summary of Contents for Simpli Home 3AXCRIDTVS-60W
- Page 1 S IMP H O M E L I F E B Y D E S I G N KITCHENER / WATERLOO / PROVIDENCE 60 INCH WIDE TV MEDIA STAND MODEL # 3AXCRIDT VS-60W 1/20...
- Page 2 FOR REPLACEMENT PARTS OR HELP WITH ASSEMBLY PLEASE CONTACT US AT: simpli home.com/customer-support PLEASE ENSURE TO HAVE THE MODEL # FROM THE PACKAGING OR INSTRUCTION BOOKLET TO RETURN THE PRODUCT: PLEASE CONTACT THE RETAILER WHERE THE ITEM WAS PURCHASED FROM...
- Page 3 L I F E B Y D E S I G N ENTER TO WIN Upload an image of our furniture in your home with a short review to our facebook page for a chance to Win up to $3000 of Simpli Home furniture!!! www.facebook.com/simplihomefurnishings 3/20...
-
Page 4: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. - Page 5 Wood Furniture Care Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions.
- Page 6 PRE ASSEMBLY INFORMATION MODEL # 3AXCRIDTVS-60W PARTS DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 LEFT DIVIDER 1 RIGHT DIVIDER 1 BOTTOM SHELF QTY 1 QTY 1 QTY 1 CABINET SHELF CENTRE SHELF DIVIDER 2 QTY 1...
- Page 7 PRE ASSEMBLY INFORMATION MODEL # 3AXCRIDTVS-60W PARTS DESCRIPTION BOTTOM SUPPORT LEG CABINET SHELF DOOR QTY 1 QTY 2 QTY 2 LEFT DRAWER FRONT RIGHT DRAWER FRONT BACK PANEL QTY 1 QTY 1 QTY 1 SET LEFT DRAWER SIDE RIGHT DRAWER SIDE...
-
Page 8: Hardware Description
PRE ASSEMBLY INFORMATION MODEL # 3AXCRIDTVS-60W HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN ALLEN KEY M6 X 30 mm CAM LOCK QTY 1 QTY 28 QTY 22 SETS WOOD DOWEL PHILLIPS SCREW ROUND HEAD HANDLE Ø 8 X 30 mm... - Page 9 COMPONENTS – KEY DIAGRAM MODEL # 3AXCRIDTVS-60W 9/20...
- Page 10 ASSEMBLY MODEL # 3AXCRIDTVS-60W STEP 1 1. Attach 4 Cam Lock Pins 2 to back of Drawer Front L . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides ML , MR . 3. Insert 2 Cam Lock 2 into pre-drilled holes on each Drawer Side ML , MR .
- Page 11 ASSEMBLY MODEL # 3AXCRIDTVS-60W STEP 3 1. Align Drawer Back N with Drawer Bottom O and press firmly into slot . 2. Attach Back N using 2 Allen Key Screws 1 through pre-drilled holes on each side ML , MR .
- Page 12 ASSEMBLY MODEL # 3AXCRIDTVS-60W STEP 5 1. Attach 3 Cam Lock Pins 2 to each Divider 1 DL , DR . 2. Align Cam Lock Pins with pre-drilled holes and attach Centre Shelf E . 3. Insert 6 Cam Locks 2 into pre-drilled holes on Centre Shelf E .
- Page 13 ASSEMBLY MODEL # 3AXCRIDTVS-60W STEP 7 1. Insert 2 Dowels 5 into each Divider 1 DL , DR and Divider 2 F . 2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 14 ASSEMBLY MODEL # 3AXCRIDTVS-60W STEP 9 1. Insert 2 Dowels 5 into top corners of each Side B L , BR 2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 15 ASSEMBLY MODEL # 3AXCRIDTVS-60W STEP 11 1. Attach hinges on Doors I to Sides BL , BR using Phillips Screws 9 . 2. Attach Magnet Plates 7 to bottom corner of Doors I using Phillips Screws 8 into guide holes on Doors I .
- Page 16 ASSEMBLY MODEL # 3AXCRIDTVS-60W STEP 12 1. Use 4 Shelf Supports 11 for each Shelf Cabinet G and H in desired location. 2. 2 Shelf Supports 11 may be used on back top of each shelf cabinet G and H as a tipping restraint.
- Page 17 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP 13 NOTE: The screwdriver is not included in the hardware pack.
- Page 18 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 19: Warranty
L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. - Page 20 S IMP H O M E L I F E B Y D E S I G N Question, problems, missing parts? Before returning your product please email Customer Support at customerservice@simpli-home.com or call Customer Support at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
