IMPORTANT : Please read this manual carefully before beginning assembly of this product Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts.
PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION SIDE SIDE DIVIDER QTY 1 QTY 1 PAIR QTY 1 PAIR CENTRE DIVIDER BOTTOM SHELF FRONT BAR QTY 1 PAIR QTY 1 QTY 2 SIDE SHELF DOOR CENTRE SHELF QTY 2 QTY 1 PAIR QTY 1 BOTTOM SUPPORT LEG BACK PANEL DRAWER FRONT...
PRE-ASSEMBLY INFORMATION HARDWARE DESCRIPTION ALLEN KEY SCREW WOOD DOWEL CAM LOCK PIN M6 X 30 mm 8 X 30 mm CAM LOCK QTY 46 QTY 24 QTY 22 SETS PHILLIPS SCREW ROUND HEAD M4 X 15 mm ALLEN KEY SHELF SUPPORT QTY 34 QTY 18 QTY 1...
Page 7
ASSEMBLY STEP 1 1. Attach 4 Cam Lock Pins 2 to back of Drawer Front L . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides M. 3. Insert 2 Cam Locks 2 into pre-drilled holes on each Drawer Side M. 4.
Page 8
ASSEMBLY STEP 3 1. Align Drawer Back N with Drawer Bottom O and press firmly into slot . 2. Attach back using 2 Allen Key Screws 1 through pre-drilled holes on each Side M . 3. Use Allen Key 4 to tighten screws. Do not over-tighten. STEP 4 NOTE: The screwdriver is not included in the hardware pack.
Page 9
ASSEMBLY STEP 5 1. Insert 4 Dowels 3 into pre-drilled holes on each Front Bar F . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed 3. Align pre-drilled holes on Side Dividers C and Centre Dividers D with Dowels 3 in Front Bars F .
Page 10
ASSEMBLY STEP 6 1. Insert 2 Dowels 3 into pre-drilled holes on each Side Divider C and Centre Divider D 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed 3.
Page 11
ASSEMBLY STEP 7 1. Insert 2 Dowels 3 into pre-drilled holes on each Side B . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed. 3. Attach 3 Cam Lock Pins 2 to each Side B into guide holes. 4.
Page 12
ASSEMBLY STEP 8 NOTE: The screwdriver is not included in the hardware pack. 1. Insert 2 Dowels 3 into top corners of each Side B . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed 3.
Page 13
ASSEMBLY STEP 9 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Hings on Doors I to Sides B using Phillips Screws 7 into pre-drilled guide holes. 2. Attach Magnet Plates 11 to bottom corner of Doors I using Phillips Screws 8 into guide holes on Doors I .
Page 14
ASSEMBLY STEP 10 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Back Panels J to Back of cabinet using Phillips Screws Round Head 5 into pre-drilled guide holes. 2. Use Phillips screwdriver to tighten screws. Do not over-tighten. 14/16...
Page 15
ASSEMBLY STEP 11 1. Use 4 Shelf Supports 6 for each Centre Shelf G and Side Shelf H in desired location. 2. 2 Shelf Supports 6 may be used on back top of each Centre Shelf G and Side Shelf H as a tipping restraint.
