- Page 1 EXCELLENCE COOKER PX 906G Instruction for the use - Installation advice KEEP IN A SAFE PLACE...
-
Page 2: After Sales Service
Dear Customer, IMPORTANT INSTRUCTIONS AND ADVICE FOR THE USE OF Thank you for having purchased and ELECTRICAL APPLIANCES given your preference to our product. The safety precautions and The use of any electrical appliance recommendations reported below are requires the compliance with some basic for your own safety and that of others. -
Page 3: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS Fire risk! Do not store flammable material in the oven and in the AND RECOMMENDATIONS storage compartment. Make sure that electrical cables After having unpacked the appliance, connecting other appliances in the check to ensure that it is not damaged proximity of the cooker cannot come and that the oven door closes correctly. -
Page 4: Cooking Hob
1 - COOKING HOB Fig. 1.1 COOKING HOB 1. Double-ring burner (PB) 3,45 kW 2. Semi-rapid burner (SR) 1,90 kW 3. Rapid burner (R2) 2,95 kW 4. Auxiliary burner (A) 1,00 kW 5. Semi-rapid burner (SR) 1,90 kW 6. Auxiliary burner (A) 1,00 kW... -
Page 5: Control Panel
2 - CONTROL PANEL Fig. 2.1 CONTROL PANEL - Controls description 1. Gas oven control knob 2. Minute counter 3. Front left burner control knob 4. Rear left burner control knob 5. Front central burner control knob 6. Rear central burner control knob 7. -
Page 6: Use Of Cooking Hob
3 - USE OF COOKING HOB GAS BURNERS Other intermediate operating adjust- ments can be achieved by positioning Each burner is controlled by a gas tap the lever between the maximum and assuring the opening and the closing of minimum aperture positions, and never the gas supply. -
Page 7: Choice Of The Burner
CORRECT USE OF CHOICE OF THE BURNER DOUBLE-RING BURNER On the control panel, near every knob, there is a diagram that indicates which The flat-bottomed pans are to be placed burner is controlled by that knob. directly onto the pan-support. The suitable burner must be chosen according to the diameter and the When using a WOK you need to place... -
Page 8: General Features
4 - GAS OVEN IGNITION OF THE OVEN BURNER Attention: the oven door becomes The thermostat allows the automatic very hot during operation. control of the temperature. Keep children away. The gas delivery to the oven burner is controlled by a two way thermostatic tap (oven and grill burners) with flame-fail- ure device. -
Page 9: Oven Thermostat
OVEN THERMOSTAT The numbers 1 to 10 printed on the con- trol panel (fig. 4.2) indicate the increas- ing oven temperature value (see table below - THERMOSTAT GRADE TABLE To regulate the temperature, set the chosen number onto the knob indicator. Fig. -
Page 10: Oven Cooking
OVEN COOKING COOKING EXAMPLES Before introducing the food, preheat the Temperatures and times are approxi- oven to the desired temperature. mate as they vary depending on the For a correct preheating operation, it is quality and amount of food. advisable to remove the tray from the The times shown apply to the oven oven and introduce it together with the already heated to the required cooking... - Page 11 IGNITION OF THE GRILL BURNER The grill burner generates the infra-red rays for grilling. To light the grill burner operate as follow: 1) Open the oven door. Do not grill with oven door closed. Always fit the heat shield supplied 2) Lightly press and turn the thermostat with the cooker under the front knob clockwise to the...
-
Page 12: Oven Light
Notes: – The grill burner has only one setting, that is full-on – It is important that the heat shield is fitted the correct way up, as shown in the figure 4.6. Fig. 4.6 IMPORTANT WARNING For best results when using the grill, place the shelf on the second level and when using the grill pan handle avoid contact with the heat shield which will be HOT during use OVEN LIGHT... - Page 13 ROTISSERIE This is used for spit roasting under the grill and comprises: – an electric motor fitted to the rear of the oven – a stainless steel skewer provided with slide-out heatless handgrip and two sets of adjustable forks – a skewer support to be fitted in the mid- dle runner.
-
Page 14: Minute Counter
5 - MINUTE COUNTER MINUTE MINDER (Fig. 5.1) The minute counter is a timed acoustic warning device which can be set for a maximum of 60 minutes. The knob (Fig. 5.1) must be rotated clockwise as far as the 60 minute posi- tion and then set to the required time by rotating it anticlockwise. -
Page 15: Cleaning And Maintenance
6 - CLEANING AND MAINTENANCE IMPORTANT NOTES Installation, and any demonstration, information or adjustments are not included in the warranty. The cooker must be installed by a qualified person in accordance with the Gas Safety (Installation and Use) (Amendment) Regulations 1990 and the relevant building/l.E.E Regulations. -
Page 16: Assembling The Backguard
ASSEMBLING THE BACKGUARD 1. Insert the side supports S and D into the backguard B (see fig. 6.1) 2. Insert the backguard group into the support guides in the cooker 3. The backguard can be removed for cleaning or fixed with a screw through the hole Fig. -
Page 17: Replacing The Oven Light Bulb
BURNERS FLEXIBLE TUBE They can be removed and washed only From time to time, check the flexible with soapy water. tube connecting the gas supply to the cooker. Detergents can be used but must not be abrasive or corrosive. It must be always in perfect condition; in case of damage arrange for it to be Do not use abrasive sponges or pads. -
Page 18: Storage Compartment
Fig. 6.3 Fig. 6.4 OVEN DOOR STORAGE COMPARTMENT The storage compartment is accessible The internal glass panel can be easily through the pivoting panel (fig. 6.4). removed for cleaning by unscrewing the 4 retaining screws (Fig. 6.3) Do not store flammable material in oven storage compartment. -
Page 19: Oven Floor
ASSEMBLY AND DISMANTLING OF THE SIDE RUNNER FRAMES – Fit the side runner frames into the holes on the side walls inside the oven (Fig. 6.5). – Slide the tray and rack into the run- ners (Fig. 6.6). – To dismantle, operate in reverse order. -
Page 20: Removing The Oven Door
REMOVING THE OVEN DOOR The oven door can easily be removed as Fig. 6.8A follows: – Open the door to the full extent (fig. 6.8A). – Attach the retaining rings to the hooks on the left and right hinges (fig. 6.8B). –... - Page 21 Advice for installer IMPORTANT – Cooker installation, regulation and conversion to other gas types must only be carried out by QUALIFIED TECHNICIANS. Failure to observe this rule will invalidate the war- ranty. – The electrical mains outlet, if located behind the cooker, must not be higher than 18 cm above the floor level.
-
Page 22: Installation
7 - INSTALLATION This cookers has class “2/1” overheating protection so that it can be installed next to a cabinet. If the cooker is installed adjacent to furniture which is higher than the gas hob cooktop, a gap of at least 50 mm must be left between the side of the cooker and the furniture. The furniture walls adjacent to the cooker must be made of material resistant to heat. -
Page 23: Fitting The Adjustable Feet
FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of the feet. WARNING Fig. -
Page 24: Provision For Ventilation
PROVISION FOR VENTILATION The room containing the cooker should have an air supply in accordance with BS.5540: Part 2: 1989. All rooms require an openable window or equivalent while some rooms require a permanent vent in addition to the openable window. The cooker should not be installed in a bed-sitting room, of volume less than 21 m Where a DOMESTIC COOKER is installed in a room or internal space, that room or internal space shall be provided with a permanent opening which communicates directly... -
Page 25: Gas Section
8 - GAS SECTION GAS INSTALLATION GAS CONNECTION IMPORTANT NOTE The installation of the cooker to Natural Gas or LP Gas must be carried out by This appliance is supplied for use on a qualified gas engineer. Installers shall NATURAL GAS only and cannot be take due account of the provisions of the used on any other gas without relevant British Standards Code of... - Page 26 GAS CONNECTION The gas supply must be connected to the gas inlet which is located at the left or the right hand rear of the appliance (fig. 8.1). The pipe does not cross the cooker. When screwing the connecting tube operate with two spanners (fig.
-
Page 27: Conversion To Lpg
CONVERSION TO LPG 1 - Injectors replacement of top burners To replace the injectors it is necessary to lift the hobtop and proceed as follows: – Remove pan-supports and burners from the hobtop. – Remove the backguard “E”. – Unscrew the two screws “B” and remove the sockets (Fig. - Page 28 2 - Adjusting of primary air 3 - Adjusting of the minimum of the top burners of the top burners By releasing the screw “M”, reset the air In the minimum position the flame must adjuster “A” according to the instructions have a length of about 4 mm and must see “Table for the choice of the remain lit even with a quick turn from the...
- Page 29 TABLE FOR THE CHOICE OF THE INJECTORS Cat: 2H3+ G 30 - 28-30 mbar G 20 Nominal Reduced BURNERS G 31 - 37 mbar 20 mbar Power Power Ø injector By-pass Ø injector By-pass Ring opening Ring opening [kW] [kW] [mm] [1/100 mm] [1/100 mm]...
- Page 30 OVEN BURNER AND GRILL BURNER REPLACEMENT OF INJECTORS a) oven burner – Lift and remove the lower panel inside the oven. – Unscrew and remove the burner securing screw A (fig. 8.6). – Slacken screw B (fig. 8.6). – Withdraw the burner in the manner shown in figure 8.7, and rest it inside the oven.
- Page 31 b) grill burner – Unscrew and remove the burner securing screw ‘C’ (fig. 8.8). – Slacken screw ‘D’ (fig. 8.8). – Move the burner in the manner shown in figure 8.9. Take care not to damage the wire to the ignition electrode and the safety valve probe.
- Page 32 Fig. 8.10 REGULATION OF AIR SUPPLY TO OVEN AND GRILL BURNERS Using a cross-head screwdriver, slacken the screw securing the air flow regulation collar (fig. 8.10 and 8.11) and move the collar forward or backward to increase or reduce the air aperture in accordance with gas type and the indications in the “...
-
Page 33: Adjustment Of The Oven Burner Minimum
ADJUSTMENT OF THE OVEN Flame correct BURNER MINIMUM To be effected only for the oven burner (as the grill burner has an only fixed input) operating on the thermostat as fol- Flame faulty in lows: primary air – Light the oven taking the knob to Max. position. -
Page 34: Electrical Section
9 - ELECTRICAL SECTION For your safety please read the Warning! This appliance must following information: be earthed This appliance must be installed by a qualified technician according with the current local regulations compliance with the manufacturer instructions. This appliance is supplied with a moulded 13 amp three pin mains plug with a 3 amp fuse fitted. - Page 35 A properly earthed three pin plug (fused at 3 amps, to BS 1362 ASTA approved) must be used. As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows.
- Page 36 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appli- ances.
