7 . 1 8 Building layout – Add a layout
3
4
1
7 . 1 9 Building layout – lift of building layouts
1
7 .20 Building layout – basic view
Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com
2
2
3
7 Common operation of the web screens
The import of the external
generated building layouts
is possible in the folder „Add
a building layout"
menu „Building layout"
The size must be less than 1
Mbyte / picture. Maximum
30 picture are possible.
To import, please click on
„add layout"
the picture in .xml format on
the source drive.
To load the picture to the
CGLine+ Web-Controller,
please click „add"
The building layouts can
displayed now by the folder
„List of building layouts"
1
of the layout, which is dis-
played as hyperlink with
.xml extension
out can load from the con-
troller. A new task will open.
See example of a building
layout below. A click on the
hyperlink (blue) opens the
building layout picure
After click on the link, the
embedded layout picture
appears. The status of the
luminaires will be displayed
with colours:
n
n
n
Via menu "Building layouts"
it is possible to go back to
the building layout menu.
2 in the
1 .
, and select
3
4 .
. With click on the name
2 , the lay-
3 .
green = normal operation
yellow = FT or DT active
red = failure
25
