- Page 1 Z-Wave Plus® Smart In-Wall On/Off Switch 36737 User’s Manual...
-
Page 2: Table Of Contents
CONTENTS SAFETY WARNINGS AND GUIDELINES ..............4 INTRODUCTION ..........................5 FEATURES ............................6 PACKAGE CONTENTS ......................6 PRODUCT OVERVIEW ......................7 WIRING DIAGRAMS ......................... 8 Single Switch ........................8 3-Way Switch ........................8 PHYSICAL INSTALLATION ....................9 OPERATION ........................... 10 Remote Operation .................... - Page 3 RF Exposure Statement for FCC ..............17 Notice for Industry Canada ................17 RF Exposure Statement for Industry Canada ........18...
-
Page 4: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... -
Page 5: Introduction
INTRODUCTION This Monoprice Z-Wave Plus® In-Wall On/Off Switch is a perfect replacement for a traditional wall switch, allowing for manual and remote control of incandescent, LED, and fluorescent lighting, as well as other electrical loads. It is fully compatible with other Z-Wave®... -
Page 6: Features
Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. 1x Z-Wave Plus® Smart In-Wall On/Off Switch 1x Wall Plate with Mount and Screws... -
Page 7: Product Overview
P P RODUCT OVERVIEW Switch Paddle To replace the face cover, just use a flat screwdriver to pry-off the LED Light interchangeable plate Yellow Traveler Load (to light fixture) Green Ground White Black Neutral Hot (from breaker) -
Page 8: Wiring Diagrams
WIRING DIAGRAMS Single Switch White (Neutral) (Load) Monoprice Z-Wave Switch Green (Ground) Black (Line/Hot) 3-Way Switch White (Neutral) Traveler(Yellow) (Load) Monoprice Switch Z-Wave Switch Green (Ground) Black (Hot) -
Page 9: Physical Installation
PHYSICAL INSTALLATION WARNING!!! Prior to physical installation, use your circuit breaker or fuse box to remove electric power from the room, then test the circuit to ensure that electric power is not present. Remove the old switch and faceplate from the electric box, then disconnect the wire leads. -
Page 10: Operation
OPERATION The connected light/device can be turned on in two ways: Using a Z-Wave® controller or remote Manually using the paddle on the switch Remote Operation Z-Wave remotes provide control of an individual device, groups of devices, and scenes. Some brands of Z-Wave certified remotes may not offer as much flexibility in how you can set up your lighting control network. -
Page 11: Advanced Operation
With the Z-Wave® controller in "adding" mode, press and • hold the top or bottom of the paddle for 3 seconds. The controller will verify the add ition and will assign a node ID to the switch. With the Z-Wave controller in "removing" mode, press •... -
Page 12: Association
AssGroupSet: Send Basic set command ALL-ON AND ALL-OFF COMMANDS Depending upon your primary controller, the Monoprice Z -Wave® Switch can be set to respond to All-On and All-Off commands in one of four different ways. Some controllers may not be able to change the response from its default setting. -
Page 13: Wireless Range
WIRELESS RANGE This device complies with the Z -Wave® standard of open line-of sight transmission distances of up to 131 feet. Actual performance in a home dep ends on the number of walls between the remote controller and the destination device, the type of construction, and the number of Z -Wave enabled devices installed in the contro l network. -
Page 14: Technical Support
Note: The distances shown in the table above are typical examples. Actual perf ormance in your home will vary. TECHNICAL SUPPORT Monoprice is pleased to pro vide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. -
Page 15: Specifications
SPECIFICATIONS Model 36737 Z-Wave® Frequency 908.42 MHz Voltage 120 VAC, 60Hz Incandescent 1000W Electronic Ballast Standard Ballast 1200VA Resistive 1800W (15A) Motor 1/2 HP Operating Temperature +32 ~ +104°F (0 ~ +40°C) Wire Strip Length 5/8" (16mm) 14AWG wires, suitable for Supply Connection at least +167°F (+75°C) -
Page 16: Regulatory Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. Modifying the equipment without Monoprice's authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right... - Page 17 off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit ...
- Page 18 RF Exposure Statement for Industry Canada Caution This equipment complies with radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must be at least 20 cm from the user and must not be collocated or operated in conjunction with any other antenna or transmitter.
