Tridonic modularDIM SC Manual

Control module for PCA/TE one4all/PCD
For DIN rail
modularDIM BASIC
Control module with 3 channels/single, twin push to make switches/
presence detector/modularDIM power supply
The modularDIM BASIC control module is the
basis of the modularDIM product range. The three
output channels can be controlled individually or
together. Simple installation since no programming
is required.
Parallel connection of several switches enables
user-friendly dimming and "ON/OFF" switching
from several points. The modularDIM BASIC
contains the central power supply for all modular-
DIM components.
5-year guarantee
type
article number
electrical supply voltage
frequency
max. load
input push to make switches *
PIR sensor
control line iX (intelligent extension)
output digital DSI control signal
signal
voltage
data rate
max. number of
max. cable length
iX (intelligent extension)
temperature permitted ambient temperature
* Switch inputs are safety low voltage (SELV).
Any standard push to make switch may be used
Data sheet 08/14-CO061-3 We reserve the right to make technical changes without prior notice.
Glow-wire test
according to EN 60598-1 passed.
V
Hz
VA
–
–
–
–
–
V
Bd
PCA/TE one4all/PCD
m
–
°C
modularDIM BASIC
86454539
120–277
50/60
< 10
single/twin
3
1
3
digital/serial
12 ±10 %
1 200
100
250
1
0 → +50
luxCONTROL
modularDIM
Packaging carton:
10 pc(s).
