9.2 Technical specifications for SREL2

Housing made of white plastic: Di-
mensions LxWxH Base plate semi-
transparent
Protection rating
Temperature
Humidity
Circuit board dimensions l x w x h
Mains voltage
Power limitation
Standby current
Max. current
Pulse duration programmable
Output relay type
Output relay continuous current
Output relay switch-on current
Output relay switching voltage
Output relay switching power
Multi-function connections F1, F2, F3 Max. 24 V DC, max. 50 mA
Vibrations
9. Technical specifications
About 78 x 78 x 19 mm
IP20, not tested for outside use
WP version: IP65
When operating: -22°C to 55°C
In storage: 0 °C to 40°C
< 95% without condensation
50 x 50 x 14 mm
9-24 V DC
Mains adapter must be limited to 15
VA
< 100 mA
< 300 mA
0.1 to 25.5 seconds
NO contact
Max. 1.0 A
Max. 2.0 A
Max. 24 V
10^6 activations at 30 VA
15 G for 11 ms,
6 shocks as per IEC 68-2-27
Not approved for use when subject
to permanent vibrations
