Portbase User Guide
3020 Models
Front
PWR
RDY
SRL
Rear
PWR
LAN
WAN
Reset
COM 1, 2
Red light when power is on
Green light when firmware is ready (blinks with errors)
Green light blinking when serial data is transmitted
Socket for DC 5V power supply
10/100 Mbps Ethernet RJ-45 (Secondary LAN Port)
10/100 Mbps Ethernet RJ-45 (Primary LAN Port)
Hardware reset button (at the bottom of the device)
RJ-45 serial port for RS232/422/485
9
