Portbase User Guide
3010M Models
Front
PWR
RDY
SRL
Rear
PWR
PWR SW
Phone/Line
WAN
Reset
COM 1
Red light when power is on
Green light when firmware is ready (blinks with errors)
Modem Hook, Modem Data Tx/Rx
Socket for DC 5V power supply
Power Switch
Phone port /RJ-11 PSTN port
10/100 Mbps Ethernet RJ-45 (Primary LAN Port)
Hardware reset button (at the bottom of the device)
RJ-45 serial port for RS232
