HS2.4S Residue Kit

Installation Guide

The RESIDUE KIT provides a low water level pump down by

simply replacing the standard Strainer Stand of your Tsurumi

HS2.4S Sand/Trash Pump with this Residue Kit.

MAY2013

Residue Kit Installed on

Tsurumi HS2.4S Sand/Trash Pump

Table of Contents

Need help?

Do you have a question about the HS2.4S Residue Kit and is the answer not in the manual?

Page 1 MAY2013 Check out other Tsurumi Pumps designed fo low-level HS2.4S Residue Kit pumping and remove standing water from... Installation Guide The RESIDUE KIT provides a low water level pump down by simply replacing the standard Strainer Stand of your Tsurumi HS2.4S Sand/Trash Pump with this Residue Kit.
Page 2 Step 1: Step 2: Step 4: Replace the pump casing / discharge assembly to the pump assembly and place either set of (3) flat washers (for lowest pump down level), or (3) nylon spacers (to retain solids handling capability). <CAUTION> Use the nylon spacer option when the pump is used on a finished surface or flexible material such as a swimming pool or pond liner.
