O
WNER'S
Projection Television
51HX93
57HX93
65HX93
M
ANUAL
Owner's Record
The model number and serial number are on the back
of your TV. Record these numbers in the spaces below.
Refer to these numbers whenever you communicate
with your Toshiba dealer about this TV.
Model number:
Serial number:
For an overview of steps for
installing, setting up, and using
your new TV, see page 8.
23566005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 51HX93 and is the answer not in the manual?

Questions and answers

Related Manuals for Toshiba 51HX93

Summary of Contents for Toshiba 51HX93

  • Page 1 Owner’s Record The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV. Model number: Serial number: 23566005...

  • Page 2: Safety Precautions

    Dear Customer, Thank you for purchasing this Toshiba TV. This manual will help you use the many exciting features of your new TV. Before operating the TV, please read this manual completely, and keep it nearby for future reference. Safety Precautions...

  • Page 3: Important Safety Instructions

    Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings.
  • Page 4 Care For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions: 27) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture can appear dull if you sit too far to the left or right of the TV, or if sunlight or room lights reflect on the screen.

  • Page 5: Table Of Contents

    If you do not have the insert, you can download a copy of it from our Web site (www.toshiba.com/tacp in the U.S.A. or www.toshiba.ca in Canada). If you do not have access to the Internet, call 1-800-631-3811 in the U.S.A. or 1-800- 268-3404 in Canada.
  • Page 6 Theater Wide 3 picture size ... 65 Full picture size ... 65 Scrolling the Theater Wide picture ... 66 Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Using the auto aspect feature (480i signals only) ... 66 Selecting the cinema mode ... 67 Selecting the display format (480p signals only) ...

  • Page 7: Chapter 1: Introduction

    A recording device is required for recording. Over-the-air or cable access to stations carrying TV Guide On Screen data is required for the TV Guide On Screen system to operate. TV Guide On Screen data is not provided by Toshiba America Consumer Products, Inc. The provider of the data may elect to discontinue the service or it may cease to be (or never be) available in your area.

  • Page 8: Overview Of Steps For Installing, Setting Up, And Using Your New Tv

    (page 10). 7. Connect your other electronic device(s) to the TV (pages 12–25). Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 1: Introduction 8. Connect the G-LINK cable (either one of the enclosed IR blaster cables) from your VCR and/or Cable box to the G-LINK jack so you can use the TV Guide On Screen™...

  • Page 9: Chapter 2: Connecting Your Tv

    — Repeatedly press to change the source you are TV/VIDEO viewing (ANT 1, ANT 2, VIDEO 1, VIDEO 2, VIDEO 3, DVI/HDCP, ColorStream HD1, ColorStream HD2). Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. 6 7 8 9 MENU VOLUME...

  • Page 10: Tv Back Panel Connections

    ColorStream ® high-definition component video and standard stereo audio inputs for connecting devices with component video output, such as a Toshiba DVD player with ColorStream. ® See pages 14 and 16. Note: Component video cables carry only video information;...

  • Page 11: Overview Of Cable Types

    Never use other aftermarket IR blaster or G-LINK cables with this TV. Other cables may not function properly and could cause damage. THIS TYPE OF DAMAGE IS NOT COVERED BY YOUR TOSHIBA WARRANTY because it is a result of misuse. ●...

  • Page 12: About The Connection Illustrations

    The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV...

  • Page 13: Connecting A Vcr And Cable Box

    The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV...

  • Page 14: Connecting A Vcr And Satellite Receiver

    The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV...

  • Page 15: Connecting A Dvd Player S-Video Video And A Vcr

    The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV...

  • Page 16: Connecting A Dvd Player With Component Video And A Vcr

    To select the video input source, press INPUT on the remote control (see page 61). To program the TV remote control to operate other devices, see pages 30–33. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV From antenna or Cable...

  • Page 17: Connecting Two Vcrs

    To select the video input source, press INPUT on the remote control (see page 61). To program the TV remote control to operate other devices, see pages 30–33. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV...

  • Page 18: Connecting A Dvi/Hdcp Device

    To select the video input source, press INPUT on the remote control (see page 61). To program the TV remote control to operate other devices, see pages 30–33. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV DVI/HDCP = Digital Visual Interface/ High-bandwidth Digital Content Protection.

  • Page 19: Connecting A Digital Audio System

    Note: To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set to a reasonable listening level. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV Dolby Digital decoder or...

  • Page 20: Connecting An A/V Receiver

    Video Audio A/V receiver Left Right speaker speaker Surround Surround speaker L speaker R Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV A/V receiver Video Audio Center AUDIO ANT( 75 G-LINK ANT-1 ANT-2 REC OUT...

  • Page 21: Controlling Infrared Remote-Controlled Devices Through The Tv (Ir Pass-Through)

    4. If the device does not turn on, move the remote control slightly to the right and press POWER again. 5. Repeat step 4 until you locate the device’s infrared sensor. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV Front of IR-controlled DVD player (for example)

  • Page 22: Connecting Ieee-1394 (Firewire ™ ) Video Devices

    TheaterNet button. See page 45 for details on using the TheaterNet feature. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV ™...
  • Page 23 (see pages 30–33). If you have an IEEE-1394 Cable box or satellite receiver, you may need to use the remote control that came with the device. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV ™...

  • Page 24: Chain Connection

    • Read the “Important information” at right. • Devices in the middle of the chain will need two IEEE-1394 ports for this connection to work as illustrated. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV (continued)

  • Page 25: G-Link Connection

    4. If the device does not turn on, move the remote control slightly to the right and press POWER again. 5. Repeat step 4 until you locate the device’s infrared sensor. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 2: Connecting your TV ™...

  • Page 26: Chapter 3: Using The Remote Control

    POP pictures (page 69) SWAP allows access to the programmed channel search function (page 70) CH SCAN selects the POP picture source (page 68) SOURCE Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. – ACTION MENU THEATER ENTER...

  • Page 27: Installing The Remote Control Batteries

    Note: The TV remote control is preprogrammed to operate most Toshiba devices. If you own a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate, you will need to program the remote control. See “Programming the remote control to operate your other devices”...

  • Page 28: Remote Control Functional Key Chart

    INPUT TV/Video select MUTE Sound mute* Sound mute* Sound mute* Sound mute* Sound mute* Sound mute* Sound mute* Sound mute* RECALL On-screen display Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. DVD/LD Receiver CD/MD (AUDIO) (AUDIO) Power Power Power...
  • Page 29 3) Will punch thru to last active VCR or DVD. Active VCR/DVD is defined as the Mode that remains for a minimum of 5 Seconds, or if a key is pressed in that Mode. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. (continued)

  • Page 30: Programming The Remote Control To Operate Your Other Devices

    VCR brand, set the switch to the other position (“VCR1” or “VCR2”) and reprogram the remote control. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Searching and sampling the code of a device (8500)
  • Page 31 1. While holding down RECALL, press 8 – 0 – 0 – 0. 2. Press VOL z. The mode light will blink four times (unlocked). Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. (continued) Operational feature reset (8900) This feature clears all setup features not related to “Device code set up”...

  • Page 32: Multi-Brand Remote Control Device Codes

    0126, 0120, 0132 YAMAHA PANASONIC 0123, 0124, 0121, 0122 ZENITH PENNEY 0124, 0100, 0145, 0105, 0139, 0110, 0111 Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Cable boxes Code Brand Code 0100, 0111, 0145 1124 0131, 0124, 0127, ARCHER 1132, 1125...
  • Page 33 4148 SONY NAKAMICHI 4106, 4117 ONKYO 4109, 4114 TEAC OPTIMUS 4103, 4127, 4131, TOSHIBA 4130 YAMAHA Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. (continued) DVD players Code Brand Code 4119, 4118, 4121 AIWA 3123 4123 APEX 3120 4105, 4107, 4150...

  • Page 34: Chapter 4: Menu Layout And Navigation

    ➞ Digital Tuner Hold ➞ On / Off ➞ Slide Show Interval ➞ 2 sec / 5 sec / 10 sec / 15 sec / 20 sec ➞ Convergence ➞ [ Convergence adjustment windows ] Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. ➞ ]...

  • Page 35: Setup/Installation Menu Layout

    15 minutes, and the signal meter menu, which closes automatically after 30 minutes. • To close a menu instantly, press EXIT. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. (continued) Quick Connect ➞ Start ➞ [ Start Quick Connect Guide & TV Guide On Screen setup ] TV Guide On Screen Setup ➞...

  • Page 36: (Continued On Next Page)

    • • • • • • • Slide Show Interval 2 Sec • • • Convergence Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. ™ – Configuring the antenna input sources. (See page 41 for details on this feature.) – Automatically programming channels into the TV’s channel memory (See page 42 for details on this feature.)

  • Page 37: Setting Up The Tv Guide On Screen System

    Configuring the location of your TV 1. Select the TV location (USA or Canada). Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. 2. Enter the ZIP code (U.S.A.) or postal code (Canada) for your location (use the Number buttons on the remote control for numbers and the yz buttons for letters), and then press ENTER.
  • Page 38 Cable box you selected. Do not press any keys on the TV, remote control, or Cable box until the testing process is done. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. (continued) 2. When testing is done, if...
  • Page 39 TV Guide On Screen system to search for the correct code, select NO and press ENTER. Go to step 3. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. (continued) 3. If the correct code is not found, the following screens appear, with helpful hints for finding the code.

  • Page 40: Completing The Quick Setup Guide Assisted Setup

    • For details on channel programming, see page 44. Quick Connect Guide ANT 1 Cable Scanning channels, please wait... Your TOSHIBA TV can memorize all available TV channels automatically. Press ENTER to start Back Next Important final setup steps...

  • Page 41: Chapter 6: Setting Up Your Tv

    Menu Language English • • • • 4. Press EXIT to close the PREFERENCES menu. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Configuring the antenna input sources Note: If you already configured the antenna input sources during the Quick Connect Guide assisted setup, you can skip this step.

  • Page 42: Programming Channels Into The Tv's Channel Memory

    Convergence 4. Open the TERRESTRIAL menu, highlight CHANNEL PROGRAM, and press ENTER. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV 5. Highlight ANT 1 or ANT 2, depending on which antenna input you want to program channels for, and then press ENTER to start automatic channel programming.

  • Page 43: Manually Adding And Deleting Channels In The Channel Memory

    Clear All Digital Save Digital Cancel Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV (continued) To add a channel to the channel memory: Highlight the unchecked box next to the channel number you want to add, and then press ENTER to check the box.

  • Page 44: Programming Your Favorite Channels

    Edit Edit B:66 Done Done B:70 Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV If you try to add more than 14 favorite channels, the error message appears. You will need to deselect a channel before you can add another.

  • Page 45: Setting Up And Using Theaternet On-Screen

    • • • • • • • Slide Show Interval 2 Sec • • • Convergence Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV ™ on-screen device control 4. Open the DEVICES menu, highlight THEATER NET DEVICES, and then press ENTER.

  • Page 46: Using The Theaternet Control Icons

    To close the on-screen control icons: Press EXIT. To view another source: Press INPUT and select the input source you want to view. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV ™ on-screen device control The following are examples of the TheaterNet on-screen control icons for other types of devices.

  • Page 47: Theaternet Ir Device Codes

    Pioneer 0877, 0144, 0533, Philips 1877 Pioneer Pulsar 0000 Quasar 0000 Polk Audio Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV CD players (cont.) Code Brand 0015 Proton 0020, 0273, 0279 0011 Quasar 0000...
  • Page 48 1089, 1189, 1269, 0189, 0391, 1120 Pioneer 1023, 0014, 0080, 0150, 0244, 0531, Uniden 0630, 1384 Zenith Polk Audio 0189 Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV (continued) VCRs Code Brand 1254 Admiral 0039 Adventura...
  • Page 49 Sansui 0000, 0067, 0209, Gradiente 0041, 0479, 1479 Greenhill Sanyo 0047, 0240, 0104, Harman/Kardon 0046 Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV (continued) DVD players (cont.) Code Brand 0184, 0045, 0121, Hitachi 0043...

  • Page 50: Automatically Adjusting The Color Convergence Using Touchfocus

    If the error message “Touch Focus Error” appears, retry the TouchFocus adjustment or adjust the convergence manually, as described at right. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV Manually adjusting the color convergence To check and adjust the color convergence manually: 1.

  • Page 51: Setting The Time And Date

    16. When done adjusting the convergence, press EXIT to close the screen and return to normal TV viewing. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV Setting the time and date Note: If you already set up the TV Guide On Screen system, the time and date were set automatically and you can skip this step.

  • Page 52: Viewing The Digital Signal Meter

    To close the screen and return to the TERRESTRIAL menu: Highlight OK and press ENTER. To return to normal viewing: Press EXIT. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 6: Setting up your TV Checking system status To check the system status: 1.

  • Page 53: Using The Tv Guide On Screen Interactive Program Guide

    Note: Over-the-air or cable access to stations carrying TV Guide On Screen data is required for the TV Guide On Screen system to operate. TV Guide On Screen data is not provided by Toshiba America Consumer Products, Inc. The data provider may elect to discontinue the service or it may cease to be (or never be) available in your area.

  • Page 54: About The Tv Guide On Screen Menus

    BLUE and GREEN Panel ad listings ACTION buttons windows Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Note: • The TV Guide On Screen menus shown in this manual are for illustration purposes only. The channels, programs, and TV Guide On Screen information as illustrated may not be available in your area.

  • Page 55: Navigating The Tv Guide On Screen System

    Highlight a program listing and press ENTER to tune the TV to the selected program. or... Press GUIDE or EXIT to tune the TV to the program displayed in the Video Window. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Applications TV Guide On Screen Picture Viewer Demo Mode –...

  • Page 56: Listings Menu

    (for example, a headphones icon if the program is in stereo, or “CC” if the program is closed- captioned). Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Applications TV Guide On Screen...

  • Page 57: Direct Tuning

    Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. To view a list of programs you set as favorites, to cancel a favorite, or to change the frequency of a favorite: 1.

  • Page 58: Viewing Panel Ads And Channel Ads

    From the SORT menu, you can schedule programs as favorites or to record, or open INFO windows for a selected listing. (For details on the FAVORITE, RECORD, and INFO buttons, see pages 56–57). Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Panel ad windows Sort menu —...

  • Page 59: Schedule Menu

    GREEN button to change its frequency. SCHEDULE menu with RECORD sub-menu selected SETUP menu Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. SETUP menu The SETUP menu allows you to change your TV Guide On Screen system settings, change the channel display, and turn the auto display feature on and off.

  • Page 60: Promotions Menu

    See Chapter 10: Troubleshooting for a list of frequently asked questions about setup and operation of the TV Guide On Screen system and for general TV troubleshooting tips. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. PROMOTIONS menu Panel ad window...

  • Page 61: Chapter 8: Using The Tv's Features

    CHANNEL EXIT TV/VIDEO TouchFocus Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Using the digital tuner hold The digital tuner hold helps to protect the digital tuner’s signal when you record a digital signal. If you are recording to a D-VHS device, the digital tuner hold is automatically activated.

  • Page 62: Labeling The Video Input Sources

    Cancel Reset 5. To save the labels, highlight SAVE and press ENTER. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Input labeling example: If you connect a VCR to VIDEO 1, a DVD player to...

  • Page 63: Tuning Channels

    – (dash) button and then the sub-channel number. For example, to select digital channel 125-1, press 1, 2, 5, –, 1. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Switching between two channels using Channel Return The Channel Return feature allows you to switch between two channels without entering an actual channel number each time.

  • Page 64: Selecting The Picture Size

    Natural picture size examples: The way the image displays will vary depending on the format of the program you are currently watching. See “Notice of possible adverse effects on TV picture tube” at right. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Note:...

  • Page 65: Theater Wide 1 Picture Size

    • None of the picture is hidden. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features To select the picture size, press PIC SIZE on the remote control.

  • Page 66: Scrolling The Theater Wide Picture

    6. To save your scroll settings temporarily, highlight DONE and press ENTER. To save your scroll settings permanently, highlight SAVE and press ENTER. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Using the auto aspect ratio feature (480i signals only)

  • Page 67: Selecting The Cinema Mode

    Auto Aspect Ratio Save Done Reset Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Selecting the display format (480p signals only) You can use this feature to convert a 480p input signal to 540p or 1080i.

  • Page 68: Using The Pop Features

    (see “Using the Locks menu” on pages 84–87). BLOCKED To close the POP window: Press SPLIT or EXIT. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Note: • You cannot view digital programs in the POP •...

  • Page 69: Switching The Main And Pop Pictures

    You can adjust the size of the main and POP pictures in the double-window. Repeatedly press x or • to change the size. See notes at right. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Note: The FREEZE feature is not available when the POP window is already open.

  • Page 70: Pop Double-Window Aspect Ratio

    3. Press ENTER to display the channel you selected in step 2 as the main picture. To cancel the channel scan without changing the channel: Press EXIT. Moving picture Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Note: The AUTO ASPECT RATIO feature (page 66) does not operate in POP double-window mode.

  • Page 71: Using The Favorite Channel Search Feature

    (The main picture is always moving.) 3. Press ENTER to display the channel you selected in step 2 as the main picture. Moving picture Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Note: • Digital channels will not display in the POP •...

  • Page 72: Adjusting The Picture

    Settings menu. • Temporarily saved settings will apply until the TV is turned off or the input source is changed. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Adjusting the picture quality You can adjust the picture quality (contrast, brightness, color, tint, and sharpness) to your personal preferences.

  • Page 73: Using The Als (Ambient Light Sensor)

    ALS will not work properly. To deactivate the ALS: Select OFF in step 3 above. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Using the flesh tone feature This feature automatically adjusts the tint to display more natural flesh tones.

  • Page 74: Using Cableclear™ Dnr (Digital Noise Reduction)

    ENTER. To permanently save the new settings, highlight SAVE and press ENTER. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Selecting the color temperature You can change the quality of the picture by selecting from three preset color temperatures: cool, medium, and warm, as described below.

  • Page 75: Using The Closed Caption Mode

    • When a videotape has been dubbed • When the signal reception is weak • When the signal reception is non-standard Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Advanced closed captions You can customize the closed caption display characteristics by changing the background color and the text size, type, edge, and color.

  • Page 76: Adjusting The Audio

    Select OFF in step 3 above. Note: When SBS is set to OFF, if the SBS level is adjusted, the SBS is automatically set to ON. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Selecting stereo/SAP broadcasts The multi-channel TV sound (MTS) feature allows you to output high-fidelity stereo sound from your TV’s speakers.

  • Page 77: Adjusting The Audio Quality

    Balance SBS Level StableSound Save Done Reset Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Using the StableSound The StableSound ® feature limits the highest volume level to prevent extreme changes in volume when the signal source...

  • Page 78: Using The Srs Wow™ Surround Sound Feature

    SRS, WOW and the symbol are trademarks of SRS Labs, Inc. SRS WOW technology is incorporated under license from SRS Labs, Inc. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Using the Dolby Virtual SRS TruSurround sound feature ®...

  • Page 79: Turning Off The Built-In Speakers

    4. To temporarily save the new settings, highlight DONE and press ENTER. To permanently save the new settings, highlight SAVE and press ENTER. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Selecting the AUDIO OUT sound This feature allows you to select the audio source (MAIN or POP) that is output from the AUDIO OUT jacks.

  • Page 80: Using The Smartmedia ™ Memory Card Picture Viewer

    TV. SUCH DAMAGE IS NOT COVERED BY YOUR TOSHIBA WARRANTY because it is a result of misuse. Memory card specifications Following are the specifications for image files this TV can display.

  • Page 81: Memory Card Care And Handling

    2 Sec 20 Sec • • • Convergence Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features To close the picture viewer: Press EXIT to close the picture viewer and return to the regular TV screen.

  • Page 82: Setting The On/Off Timer

    Not Set Clear Save Cancel Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Setting the sleep timer You can set the sleep timer to turn off the TV at a set length of time, to a maximum of 3 hours.

  • Page 83: Displaying Tv Setting Information On-Screen

    Picture Viewer Demo Mode To stop the demo mode: Press EXIT, RECALL, or POWER. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 8: Using the TV’s features Understanding the auto power off feature The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day.

  • Page 84: Chapter 9: Using The Locks Menu

    Game Timer • • • • • • • • • • • • New PIN Code Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. If you cannot remember your PIN code While the PIN code entering screen is displayed, press RECALL four times within five seconds.

  • Page 85: Blocking Tv Programs And Movies By Rating (V-Chip)

    Set recommended rating limits for children. 8. When done selecting the ratings you want to block, highlight SAVE and press ENTER. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 9: Using the Locks menu Independent rating system for broadcasters...

  • Page 86: Blocking Channels

    B:6-1 B:6-2 B:10-1 B:10-2 Save B:10-3 B:10-4 B:10-5 A:11 Cancel Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 9: Using the Locks menu Unlocking programs temporarily If you try to watch a TV program that exceeds the rating limits you set, the TV enters program lock mode.

  • Page 87: Using The Game Timer

    NOT COVERED BY YOUR WARRANTY because it is the result of misuse. See item 33 on page 4. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 9: Using the Locks menu Using the front panel lock feature You can lock the front panel buttons to prevent your settings from being changed accidentally (by children, for example).

  • Page 88: Chapter 10: Troubleshooting

    • Make sure you have saved the picture files in the correct file format (page 80). • The card may be inserted improperly. Remove the card and reinsert it (page 80). • The memory card may be empty. • The memory card may be damaged. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved.
  • Page 89 • If your TV’s problem has not been addressed in this Troubleshooting section or the recommended solution has not worked, use the Restore Factory Defaults procedure as described on page 52. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 10: Troubleshooting...

  • Page 90: Tv Guide On Screen Faqs

    VCR to the television, the VCR must be tuned to the output channel and powered ON. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 10: Troubleshooting 7. Q: I had a power outage. Do I need to go through initial setup of the TV Guide On Screen system again? A: No.

  • Page 91: Operational Questions

    VCR and stereo connection from VCR to television, the VCR must be ON. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 10: Troubleshooting 4. Q: How do I add, delete, or change the assigned number of channels on the TV Guide On Screen system? A: See the “Change channel display”...
  • Page 92 Dirty or defective tape heads. Refer to your VCR owner’s manual for maintenance tips. Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Chapter 10: Troubleshooting 14. Q: Why won’t my VCR change channels and why does it...

  • Page 93: Chapter 11: Appendix

    AUDIO: 200 mV(rms) (–20 dBFS, 4.7 k ohm) (For ATSC, Digital Cable, IEEE-1394 sources only) _________ * E-EDID = Enhanced-Extended Display Identification Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. Video/Audio Terminals (cont.) AUDIO CENTER CHANNEL INPUT 300 mV(rms) (30% modulation equivalent, 10 k ohm)

  • Page 94: Limited United States Warranty

    (1) To find the nearest TACP/THI Authorized Service Station: For televisions purchased in the United States, except Hawaii, visit TACP’s web site at www.toshiba.com/tacp, or call toll free 1-800-631-3811. For televisions purchased in Hawaii, contact Toshiba Hawaii, Inc., 327 Kamakee Street, Honolulu, HI 96814, (808) 591-9281.

  • Page 95: Limited Canada Warranty

    THEREFORE, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCES. ® FST PURE is a registered trademark of Toshiba America Consumer Products, Inc. If you purchased your TV in Canada, register it online at www.toshiba.ca REV. MAR02...
  • Page 96 Notes Copyright © 2003 TOSHIBA CORPORATION. All rights reserved.
  • Page 97 Notes Copyright © 2003 TOSHIBA CORPORATION. All rights reserved.

  • Page 98: Index

    DTV receiver connection ... 14 DVD connection ... 15 DVHS A/VC ... 22 DVI/HDCP connection ... 18 Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. E F G I EIA-775 ... 22 FAV yz buttons ... 44 Favorite channels ... 44 Focus, SRS WOW ...
  • Page 99 ... 78 Stereo sound ... 76 Sub-bass system (SBS) ... 77 S-video cables ... 11 Copyright © 2003 TOSHIBA CORPORATION. All rights reserved. TheaterNet, button ... 46 Theaternet, connection ... 45 TheaterNet setup ... 45 Theater wide picture ... 64 TouchFocus™...
  • Page 100 22171 FRASERWOOD WAY, RICHMOND, B.C., V6W 1J5, CANADA – TEL: (604) 303-2500 MANUFACTURED BY ColorStream and StableSound are registered trademarks of Toshiba America Consumer Products, Inc. CableClear, TouchFocus, SurfLock, Theaterlink, and TheaterNet are trademarks of Toshiba America Consumer Products, Inc. PRINTED IN USA (03-08) RP...

This manual is also suitable for:

57hx9365hx93

Table of Contents
