Sencore OmniHub CMP201 User Manual

Media platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

OmniHub CMP201
Media Platform
User Manual
January 2020
www.sencore.com | 1.605.978.4600
Revision 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniHub CMP201 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sencore OmniHub CMP201

Summary of Contents for Sencore OmniHub CMP201

  • Page 1 OmniHub CMP201 Media Platform User Manual January 2020 www.sencore.com | 1.605.978.4600 Revision 1.2...

  • Page 2: Copyright

    Inquiries should be made directly to those companies. This document may also have links to third-party web pages that are beyond the control of Sencore. The presence of such links does not imply that Sencore endorses or recommends the content on those pages. Sencore acknowledges the use of third-party open source software and licenses in some Sencore products.

  • Page 3: Revision History

    OmniHub CMP201– User Manual Revision History Date Version Description Author 06/27/19 Initial Release 12/06/19 Add New Modules This guide contains some symbols to call your attention. The DANGER symbol calls your attention to a situation that, if ignored, may cause physical harm to the user.
  • Page 4 Replacement Parts: When replacement parts are required, be sure the service • technician uses replacement parts specified by Sencore, or parts having the same operating characteristics as the original parts. Unauthorized part substitutions made may result in fire, electric shock or other hazards.
  • Page 5 OmniHub CMP201– User Manual SAFETY PRECAUTIONS There is always a danger present when using electronic equipment. Unexpected high voltages can be present at unusual locations in defective equipment and signal distribution systems. Become familiar with the equipment that you are working with and observe the following safety precautions.
  • Page 6 1. OmniHub CMP201 chassis 2. OmniHub CMP201 Quick Start Guide 3. AC power cables 4. Breakout or adapter cables depending on option modules If any of these items were omitted from the packaging please email ProCare@Sencore.comto obtain a replacement. Page 6 of 103...

  • Page 7: Table Of Contents

    OmniHub CMP201– User Manual Table of Contents COPYRIGHT ................................2 ABOUT SENCORE ..............................2 REVISION HISTORY ..............................3 TABLE OF CONTENTS .............................. 7 SECTION 1 OVERVIEW ............................9 ............................10 RODUCT VERVIEW ..........................10 RONT ANEL VERVIEW ........................... 11 ANEL VERVIEW ..........................
  • Page 8 OmniHub CMP201– User Manual 3.3.20 CP2-EAS-00 ............................78 3.3.21 CP2-CAM-00 ............................81 SECTION 4 APPENDICES ............................83 APPENDIX A - A ........................84 CRONYMS AND LOSSARY APPENDIX B - A M SE C ................85 ONROE ONFIGURATION AND ESTING APPENDIX C - S ............................

  • Page 9: Section 1 Overview

    OmniHub CMP201– User Manual Section 1 Overview SECTION 1 OVERVIEW ............................9 ............................10 RODUCT VERVIEW ..........................10 RONT ANEL VERVIEW ........................... 11 ANEL VERVIEW ..........................11 PTION ODULE VERVIEW Page 9 of 103...

  • Page 10: Product Overview

    OmniHub CMP201– User Manual Product Overview OmniHub CMP201 is a new generation of Compact Media Platform in Modular design which focuses on cost-effective commercial TV market and traditional DTV market. This is a 1RU chassis with single or dual power supply unit and six hot modules at the back of the unit. Thanks...

  • Page 11: Rear Panel Overview

    OmniHub CMP201– User Manual Rear Panel Overview The OmniHub CMP201 has multiple options for the backplane configuration. Device can be ordered with Single Power Supply (order number - CMP201) or Dual Power Supply (order number - CMP201D). Rear panel of the device with single power supply 1.
  • Page 12 OmniHub CMP201– User Manual Receiver Modules Description CR2-DVBC-00 4 channel DVB-C Annex A/C/DTMB receiving module, 1 RF input connector with 4 tuners and 2 CI slots CR2-DVBC-01 4 channel DVB-C Annex B/ISDBT receiving module, 1 RF input connected with 4 tuners and 2 CI slots...
  • Page 13 OmniHub CMP201– User Manual MPEG1L2, AC3 and AAC and supports CC and analog audio input. CE2-HDMI-05 4 channel HDMI encoding module, supports H.264/H.265 HD/SD, MPEG-2 SD, MPEG1L2, AC3 and AAC, and support OSD subtitle, logo picture and QR code overlay.
  • Page 14 OmniHub CMP201– User Manual CM2-QAMB-R01A 8 channel QAM modulation module, Annex B, adjacent output, and 1 RF female port for output CM2-OFDM-R01 4 channel OFDM modulation module, adjacent output, and 1 RF female port for output CM2-OFDM-R01A 8 channel OFDM modulation module, adjacent output, and 1 RF female port for output.

  • Page 15: Section 2 Installation

    OmniHub CMP201– User Manual Section 2 Installation SECTION 2 INSTALLATION ............................ 15 ............................16 NSTALLATION AC P ..........................16 OWER ONNECTION Page 15 of 103...

  • Page 16: Rack Installation

    OmniHub CMP201– User Manual Rack Installation The OmniHub CMP201 is designed to be mounted in a standard 19” rack. It takes 1RU of rack space. To install it into a rack, please use the following steps: • Determine the desired position in the rack for the CMP201. Make sure that the air intake on the front of the unit and the exhausts on the back of the unit will not be blocked.

  • Page 17: Section 3 Web Interface Operation

    OmniHub CMP201– User Manual Section 3 Web Interface Operation SECTION 3 WEB INTERFACE OPERATION ......................17 CMP201 W ....................18 NTERFACE VERVIEW 3.1.1 Connecting to the Management Port ....................18 3.1.2 CMP201 W ..................... 18 OGGING INTO THE NTERFACE ............................18...

  • Page 18: Omnihub Cmp201 Web Interface Overview

    OmniHub CMP201– User Manual OmniHub CMP201 Web Interface Overview 3.1.1 Connecting to the Management Port CMP201 has an embedded gigabit switch inside the chassis. The four network ports are respectively used for managing and data reception/streaming over IP network. From left to right, port 1 and port 2 are used for management purposes and, port 3 and port 4 are used for IP reception/streaming.

  • Page 19: Status

    OmniHub CMP201– User Manual 3.2.1 Status This Menu allow the user to access the following: Device Status • Device Information • Device Status will show once you login on the CMP201 management GUI as shown in the picture above. It also shows the front and rear-view image of CMP201 with friendly label that show the status of each module connected in the 6 slots.
  • Page 20 OmniHub CMP201– User Manual Click the Apply button on the right side to make the change takes effect. Time page allows user to check current system time, change Time Zone, choose system time Mode (Manual or Automatic), enable/disable Auto Sync and modify NTP Server Address in Automatic mode, change current system Time in Manual mode.

  • Page 21: Ip Input

    OmniHub CMP201– User Manual Click the Apply button on the right side to make the change takes effect. Password page user can reset login password. Click the Apply button on the right side to make the change takes effect SNMP page is for user to Disable or enable the SNMP function.
  • Page 22 OmniHub CMP201– User Manual Clicking on the icon button under Service List will display information on the services included in the transport stream. Click the service name to check the detail info of the service. Clicking on the eye icon under the TS Analysis button to display the information on the structure of the transport stream.
  • Page 23 OmniHub CMP201– User Manual Fill the key words of PID, Bit rate, bandwidth, table type or service name using the search box to check the info you want to find. Click Reset Counter button to clear continuity count error and restart counting.
  • Page 24 OmniHub CMP201– User Manual Click the Apply button on the right side to make the change takes effect. Service Configuration is used to route a whole stream or service/s from the IP input towards the output channel (stream). Two types of routing are possible: 1.

  • Page 25: Ip Output

    OmniHub CMP201– User Manual To use Multiplexing mode on service level click on pencil icon on the right side in the line with the proper servicename. In the next step, select the output stream (channel) where service will be multiplexed.
  • Page 26 OmniHub CMP201– User Manual Status tab shows Total Bit Rate, Effect Bit Rate, Bitrate Status (Normal/Overload), TS Analysis and Service List for each IP output stream. Clicking on the button will display information on the services included in the transport stream.
  • Page 27 OmniHub CMP201– User Manual Fill the key words of PID, Bit rate, bandwidth, table type or service name using the search box to check the info you want to find. Click button to clear continuity count error and restart counting.
  • Page 28 OmniHub CMP201– User Manual In order to create or edit a larger number of IP outputs, use the button. Batch configuration allows to auto assign IP address or UDP/RTP port. Click the Apply button on the right side to make the change takes effect.

  • Page 29: Module Configuration

    OmniHub CMP201– User Manual *As you notice, the Status on IP input and IP output are similar in comes on TS analysis and Service List. These 2 tab are all available in All modules status page. Same goes to Service Configuration when we output service to other output modules like QAMA, QAMB, OFDM, IP, etc.,...
  • Page 30 OmniHub CMP201– User Manual 3.3.1.1 Module Status By selecting the CR2-DVBC-00 on the module list, you will be automatically redirect to the Status page. There will be a table with seven columns on the status page. It shows the Channel from 1.1 to 1.4 that correspond for the 4 channel input of the module.
  • Page 31 OmniHub CMP201– User Manual 3.3.1.2 Module CI For the encrypted services on DVBC receiver, CI slot is needed to decrypt the services and to be able to re-broadcast the services. The CR2-DVBC-00 have 2 CAM slot and can decrypt services depending on the capability of the Smart Card. You can select the CAM Max Bit Rate from 48 Mbps to 108 Mbps which you can choose in pull-down list.
  • Page 32 OmniHub CMP201– User Manual Name Range Frequency (KHz) 48000~862000 Symbol Rate (KBaud) 3000~7000 3.3.1.4 Module Service Configurations Service Configuration page is where you manage the received service and output them to their designated interface. The configuration for all module in CMP201 is mostly same. First, you need to scan the port on each TS with LOCKED status.
  • Page 33 OmniHub CMP201– User Manual To use Bypass OR Multiplexing mode on stream level click the (cog) icon. There will have always a BaseBoard selection for the IP output and other Output option depending on the module inserted. Select the correct Output and Channel you want to output the Stream. Put a tick on Multiplex or Bypass on the Channel you want to output.

  • Page 34: Cr2-Dvbc-01

    OmniHub CMP201– User Manual 3.3.1.5 Module System Operation In System Operation page you can change into DVBC Mode or DTMB Mode, reboot the module, Factory Reset, and Log Export. System Tab also allows to perform the following tasks: Import / Export License •...

  • Page 35: Cr2-Dvbs2Fta-00/00A

    OmniHub CMP201– User Manual 3.3.3.1 Module Settings Parameter Setting of DVBS2CI show where you input the information of the source signal. The table below show the parameter range on each field. For the LNB power, channel 1.1 and 1.2 both via LNB-1 share power with each other, channel 2.1 and 2.2 both via LNB-2 share power with each other.

  • Page 36: Cr2-8Vsb-00

    OmniHub CMP201– User Manual The parameters for each port in Module Settings are also same with the CR2-DVBS2CI and Service Configuration is same with CR2-DVBC-00. Please refer to page 34 to 36 for the configuration manual. 3.3.5 CR2-8VSB-00 CR2-8VSB-00 is a 4-channel 8VSB receiving module with 4 RF connectors. Picture below shows front plate of 8VSB module.
  • Page 37 OmniHub CMP201– User Manual Table below presents supported channel plans. Channel Plan Frequency of RF Channels Off-Air CH2 57MHz, CH3 63MHz, CH4 69MHz~CH67 791MHz, CH68797MHz, CH69 803MHz CH2 57MHz, CH363MHz, CH4 69MHz~ CH133 849MHz, CH134855MHz, CH135 861MHz CH2 57MHz, CH3 63MHz, CH4 69MHz ~ CH133 849MHz, CH134, 855MHz, CH135 861MHz CH2 55.75MHz, CH3 61.75MHz, CH4 67.75MHz~ CH133847.75MHz,...
  • Page 38 OmniHub CMP201– User Manual 3.3.5.3 Modules Service Configuration To route a whole stream or service/s from the 8VSB towards the output channel (stream), use the Service Configuration tab. Two types of routing are possible: 1. Bypass mode routes whole input transport stream towards IP or RF output. Bypass mode activation cause output channel will be occupied only by this stream.
  • Page 39 OmniHub CMP201– User Manual To use Multiplexing mode on service level click on (pencil) icon. There will have always a BaseBoard selection for the IP output and other Output option depending on the module inserted. Select the correct Output and Channel you want to output the Service. Put a tick on Multiplex on the Channel you want to output, you can output multiple service in same channel or output same service in multiple channel.

  • Page 40: Cr2-Dvbt2Ci-00

    OmniHub CMP201– User Manual After login is enabled, additional control buttons will be displayed: - clean log, clean screen, export logs, filter dialog box 3.3.6 CR2-DVBT2CI-00 CR2-DVBT2CI-00 is a 4-channel DVBT/T2 receiving and descrambling module with 1 RF female connector and 2 CI slots. It can receive 4 RF channels signal simultaneously and support 2 CAM cards descrambling.
  • Page 41 OmniHub CMP201– User Manual 3.3.6.1 Module Status CR2-DVBT2CI-00 status will show if each port has signal by showing GREEN lock status on each corresponding channel. The page also shows the total bitrate (Mbps) and Effective bitrate on each port. For more details on the received signal. You can check the TS analysis and Service List with the same features as other status of CMP modules.

  • Page 42: Encoder Modules

    OmniHub CMP201– User Manual 3.3.6.3 Module Service Configuration Service Configuration and System Operation please refer to CR2-DVBC-00 module at page 34 to 35. In Descrambling Settings there are CAM1, CAM2 and No Descrambling options. Select the correct CAM to decrypt the service and click Apply to make the change take effect or Clear Config button in the right side to clear all configurations.
  • Page 43 OmniHub CMP201– User Manual 3.3.7.1 Module Status Module Status for HDMI encoder show the Bitrate on each port when HDMI source is connected. Video resolution of the source video will appear also on the status. The TS Analysis is same for Baseboard IP input Status and All modules Status. This can show you the details like PID, of the received channel, and last is Service List that show the list of services on the received Channel.
  • Page 44 OmniHub CMP201– User Manual 3.3.7.2 Module Settings Click All Configurable Parameters to see all parameters you can modify and check what specific parameters you want to set and see. Click the Apply button in the right side to make the change take effect.
  • Page 45 OmniHub CMP201– User Manual Video Resolution VLC Mode Auto, CABAC 1920×1080_60i, CAVLC 1920×1080_50i, 1920×1080_30p, 1920×1080_25p, 1080×720_60p, 1080×720_50p, 720×480_60i, 720×576_50i Video Frame Bitrate Auto Profile HIGH 59.94/29.97 MAIN Video PID 32~8190 Level 3.0,3.1,3.2 4.0,4.1,4.2 GOP Structure IPPB, IPPP, IBP Video Aspect...
  • Page 46 OmniHub CMP201– User Manual Audio Encoder Range Audio Encoder Range Details Details Audio Type MPEG1_Layer2 Audio PID 32~8190 Audio Bit rate (Kbps) 32~192 Volume(dB) -20~20 Delays (ms) -2000~2000 Shelter Range Shelter Range Parameters Parameters Shelter Enable/Disable 0~1920 (Dual) Width 0~1080 (Dual)
  • Page 47 OmniHub CMP201– User Manual 3.3.7.4 OSD Settings (only available in the CE2-HDMI-R01 module) You should choose channel first before you set OSD. • LOGO setting: you can upload several pictures at the same time, and pick one to show on the screen, when you click the one you want to show that picture field will turn to green.
  • Page 48 OmniHub CMP201– User Manual • Subtitle setting: Subtitle Parameter Range LOGO Parameter Range Position Bottom/Top/Middle Size width 0~1920 (Dual) Size Height 0~1080 (Dual) Front 0~100 QR Code setting: QR Code picture picking method is same to LOGO setting. • LOGO Parameter...
  • Page 49 OmniHub CMP201– User Manual 3.3.7.5 Service Configuration and System Operation Service Configuration and System Operation please refer to CR2-DVBC-00 module at page 34 to 35. 3.3.7.6 EAS Settings Settings for the EAS feature need to be made on the encoder module so that when the EAS source is triggered, the Audio and Video from the encoder will be replace by the Audio and Video from AES module.

  • Page 50: Ce2-Hdmi-02

    OmniHub CMP201– User Manual 3.3.8 CE2-HDMI-02 CE2-HDMI-02 is a 2-channel HDMI encoder which supports H.264 HD/SD or MPEG-2 HD/SD encoding with 2-channel RCA for CC input. The module supports MPEG1-L2, AAC and AC3 audio encoding. 3.3.8.1 Module Status Module Status for HDMI encoder show the Bitrate on each port when HDMI source is connected.
  • Page 51 OmniHub CMP201– User Manual Click All Configurable parameters in the line to set encoding parameters. Video Encoder Range Name Range Details Video Type H.264, MPEG2 GOP Size 18~48 Video Bitrate (Kbps) 2000~18000 PCR PID 32~8190 Video Mode PMT PID 32~8190...
  • Page 52 OmniHub CMP201– User Manual Advanced Parameters The CE-HDMI-02module support total two sets of audio and video input. Each set includes 1 HDMI port/1 component portand1 analog port. It supports dual audio encoding per channel. Dual audio all come from HDMI input with the same content and the encoding format can be the same or different;...

  • Page 53: Ce2-Hdmi-02C

    OmniHub CMP201– User Manual Settings for the EAS feature need to be made on the encoder module so that when the EAS source is triggered, the Audio and Video from the encoder will be replace by the Audio and Video from AES module.
  • Page 54 OmniHub CMP201– User Manual 3.3.9.1 Module Status Module Status for HDMI-02C encoder show the Bitrate on each port when HDMI source is connected. Video resolution of the source video will appear also on the status. Clicking on the button will display information on the structure of the transport stream. This will show more detail about the Service in the channel depending on the parameter you set on the Module Setting.
  • Page 55 OmniHub CMP201– User Manual Advanced Parameters Click All Configurable Parameters in the line to set encoding parameters. Video Encoder Range Name Range Details Input TS Source HDMI, Component Video Type H264 , MPEG2 GOP Size 18~48 Video Bitrate (Kbps) 2000~18000...
  • Page 56 OmniHub CMP201– User Manual Audio Encoder Details Range Audio Encoder Range Details Audio Type Audio Source HDMI MPEG1_Layer2 Analog MPEG2_AAC None MPEG4_AAC Volume Audio PID 32~8190 Audio Bit Rate(Kbps) 128~384 (AC3) 64~384(MPEG1_Layer2/ MPEG2_AAC/ MPEG4_A The CE2-HDMI-02C module support total two sets of audio and video input. Each set includes 1 HDMI port/1 component port and1 analog port.

  • Page 57: Ce2-Hdmi-05/05A

    OmniHub CMP201– User Manual EAS module settings 3.3.9.5 Service Configuration and System Operation Please see CR2-DVBC-00 module at page 34 to 36 for the reference. 3.3.10 CE2-HDMI-05/05A CE2-HDMI-05/05A module is a 4/8 channel HDMI encoding mdoule that support H.264. Module support s Mpeg1L2, AC3 and AAC audio and supports OSD Subtitle, logo picture and QR code overlay.
  • Page 58 OmniHub CMP201– User Manual 3.3.10.1 Module Status Like the other Hdmi encoder module. The Status of CE2-HDMI-05/05A show the Bitrate, input and output Resolution, TS analysis and Service list in each channel as shown in the image below. Page 58 of 103...
  • Page 59 OmniHub CMP201– User Manual 3.3.10.2 Module Settings For the Module Setting, please refer to CE2-HDMI-01 at page 46 for reference. See below screenshot of the module Setting page. Page 59 of 103...
  • Page 60 OmniHub CMP201– User Manual 3.3.10.3 Module OSD Settings For the Module OSD, Please refer to CE2-HDMI-01 at page 4. See below screenshot for the Module OSD page. 3.3.10.4 Module IP Output Please see CE2-HDMI-00/R01 IP Output at page 48 for reference 3.3.10.5...

  • Page 61: Ce2-Sdi-00

    OmniHub CMP201– User Manual 3.3.11 CE2-SDI-00 CE2-SDI-00 module supports 2 CH H.264/AVC HD/SD (up to 1080p60) or MPEG-2 HD/SD (up to 1080i60) encoding via SDI/CVBS input. MPEG1-L2, AAC and AC3 audio encoding, 2×BNC, 2×6-pins interfaces for analog audio inputs 3.3.11.1...
  • Page 62 OmniHub CMP201– User Manual Video Encoder Details Range Name Range Input Source Type CVBS, SDI GOP Size 18~48 Video Type H.264, MPEG2 PCR PID 32~8190 Video Bit Rate (Kbps) 2000~18000 PMT PID 32~8190 Video Mode Program Name Length is 1~31...
  • Page 63 OmniHub CMP201– User Manual Here showed the parameter for the Stream, MPEG2, and MPEG4 Output. 3.3.11.3 IP Output Please see CE2-HDMI-00/R01 IP Output at page 48 for reference 3.3.11.4 EAS Settings Settings for the EAS feature need to be made on the encoder module so that when the EAS source is triggered, the Audio and Video from the encoder will be replace by the Audio and Video from AES module.

  • Page 64: Ce2-Cvbs-00/R01/R01A

    OmniHub CMP201– User Manual SDI Encoder EAS setting EAS Module settings 3.3.11.5 Service Configuration and System Operation Please see CR2-DVBC-00 module at page 34 to 35 for the reference. 3.3.12 CE2-CVBS-00/R01/R01A CE2-CVBS-00/R01/R01A is the 6/8/16-channel CVBS encoder with 2/2/4 DB15 connectors each for 3/4/4 channels.
  • Page 65 OmniHub CMP201– User Manual CE2-CVBS-R01A (16 CH) Just like all modules. CE2-CVBS Status show the bitrate on each channel and can be check the TS Analysis and Service List. See picture below 3.3.12.1 Module Settings Click All Configurable Parameters to see all parameters you can modify and check what specific parameters you want to set and see.
  • Page 66 OmniHub CMP201– User Manual Click All Configurable Parameters in the line to set encoding parameters. Name Range Name Range Video Type H264, MPEG2 Service Name Length is 1~16 Video Bitrate (Kbps) 600~20000 Service Provider Length is 1~16 Name Video Mode...

  • Page 67: Modulation Modules

    OmniHub CMP201– User Manual Name Range Name Range Video Type H.264 Service Name Length is 1~16 Video Bitrate (Kbps) 600~6000 Service Provider Length is 1~16 Name Video Mode Brightness 0~255 GOP Size 1~99 Contrast 0~255 Profile Main/High Saturation 0~255 Video PID...
  • Page 68 OmniHub CMP201– User Manual 3.3.13.2 Module Settings This page is where we can modify or SET the frequency, we will use for the RF modulation. CM2-QAMA-R00 have 16 non-adjacent channels while CM2-QAMA-R01 have 4 adjacent channel both at single port.
  • Page 69 OmniHub CMP201– User Manual On the Left side, you will see the list of TS where there are output service. If the TS or Channel are enabled but no Service Output. It will not be listed here. You will also see the Original Network ID and TS ID where you can modify the details and below will be the list of the service in the Selected TS.
  • Page 70 OmniHub CMP201– User Manual For NIT Stream, there is an option here to create Cable Descriptor and Logical Channel Number LCN. You need to Add and Input first the correct Original Network ID and TS ID. Once done, click on the plus icon “+” under Operation and select the Descriptor you want to add For Cable Descriptor, this is use for the STB to scan all configured frequency on the network given that the STB triggering Frequency is set where the NIT frequency is created.
  • Page 71 OmniHub CMP201– User Manual For the LCN or Logical Channel number. This created the same way with Cable Descriptor. On 1 frequency, you will Add NIT Stream and create multiple TSID. Here you will add the LCN on each TSID.

  • Page 72: Cm2-Qama-R01/R01A

    OmniHub CMP201– User Manual 3.3.14 CM2-QAMA-R01/R01A CM2-QAMA-R01 and CM2-QAMA-R01A are 4 channel and 8 channel modulators respectively. The module shares the same hardware but different software. For the Status, Settings, Service Configuration and System Operation. Please refer to previous module CM2-QAMA-00/R00 3.3.15...

  • Page 73: Cm2-Qamb-R01/R01A

    OmniHub CMP201– User Manual Name Range Name Range Bandwidth (MHz) Channel Standard US cable/STD/IRC/ Symbol Rate 5056.941 (QAM 64) RF level 15~48 (dBmV) (KBaud) 5360.537 (QAM 256) PSI/SI Interval 50~10000 Constellation QAM 64/256 (ms) Channel No. Up to Channel Standard 3.3.15.3...

  • Page 74: 3.3.18 Cm2-Ofdm-R01/R01A

    OmniHub CMP201– User Manual 3.3.17.1 Settings Click the Apply button in the right side to make the change take effect. Name Range Name Range RF level (dBmV) 28~48 PSI/SI Interval (ms) 50~10000 Channel - Frequency Channel Standard OFF-AIR, STD, IRC, CH2 - 57MHz ~ CH69 –...
  • Page 75 OmniHub CMP201– User Manual 3.3.18.1 Module Settings For the Settings of CM2-OFDM-R01 Module Settings is where we input the source parameters. Once done, click on apply for the changes to take effect and check on the status in the channel signal is Locked.

  • Page 76: Cm2-Isdbt-R01/R01A

    OmniHub CMP201– User Manual 3.3.18.2 Service Configuration For the Configuration of the OFDM module. This is like the configuration of CM2-QAMA-00/R00. You can also change the Original Network ID, TSID, Service Name, PID and create LCN Descriptor and Cable Descriptor. For more details, please check CM2QAMA-00 for reference.
  • Page 77 OmniHub CMP201– User Manual 3.3.19.2 Service Configuration • TS setting: Please refer to IP output service configuration. • LCN setting: You need to add NIT stream of all frequencies in the base TS (frequency) which is used for your STB auto search and identifies all the TS (frequencies) LCN information.

  • Page 78: Function Modules

    OmniHub CMP201– User Manual Function Modules 3.3.20 CP2-EAS-00 The CP2-EAS-00 module provides the ability to interrupt Encoder playback and switch to an external transport stream. This feature is for the US market and requires the CMP chassis to be set for ATSC standard.
  • Page 79 OmniHub CMP201– User Manual 3.3.20.1 Module Settings Below is an example of the EAS module configuration settings with some additional des criptions. Click the Apply button in the right side of the EAS settings page to make the change take effect.
  • Page 80 OmniHub CMP201– User Manual Encoder Settings section is for the RCA / Analog-AV inputs. When the takeover content is provided in this fashion it must be encoded to MPEG “.TS” Transport Stream data. The Video, Audio, and Bitrate settings are used to configure the format.

  • Page 81: Cp2-Cam-00

    OmniHub CMP201– User Manual 3.3.21 CP2-CAM-00 CP2-CAM-00 is used to decrypt and encrypt service. It has 2 independent CI card slots, compatible with mainstream CAM cards, support only Xcrypt CAM CAS for encryption and support mainstream CAS decryption. 3.3.21.1 Module Status Click the name of CP2-CAM-00 under the module list to view the STATUS page of the module.
  • Page 82 OmniHub CMP201– User Manual 3.3.21.2 For the received encrypted service in DVBS2, DVBC, ISDT, etc. They can output the services to CP2-CAM-00 to decrypt the service and rebroadcast it to QAM, OFDM, IP, etc. The CI page will show you the list of the successful service decrypted in the channel.

  • Page 83: Section 4 Appendices

    OmniHub CMP201– User Manual Section 4 Appendices SECTION 4 APPENDICES ............................83 APPENDIX A - A ........................84 CRONYMS AND LOSSARY APPENDIX B - A M SE C ................85 ONROE ONFIGURATION AND ESTING APPENDIX C - S ............................89...

  • Page 84: Appendix A - Acronyms And Glossary

    OmniHub CMP201– User Manual APPENDIX A - Acronyms and Glossary Advanced Audio Coding AC-3 Also known as Dolby Digital Audio Engineering Society ATSC Advanced Television Systems Committee Audio Video Bouquet Association Table Bit Error Ratio Bit Rate The rate at which the compressed bit stream is delivered...

  • Page 85: Appendix B - A Monroe One Net Se Configuration And Testing

    OmniHub CMP201– User Manual Signal Noise Ration SPTS Single Program Transport Stream Time and Date Table Transport Stream Variable Bitrate APPENDIX B - A Monroe OneNetSE Configuration and Testing For development and testing purposes, the Monroe OneNetSE will be used to supply the SCTE18 messages and the EAS substitution audio and video.
  • Page 86 OmniHub CMP201– User Manual Webpage Configuration 1. The webpage for the Monroe box requires login. The Monroe box has been configured with this login information (The capital “A” in the username is required): User: Admin Password: sencore12 2. Once logged into the unit, browse to the Setup tab and select Net Alerts.
  • Page 87 OmniHub CMP201– User Manual 5. Make sure Client 0 is enabled and then input the unicast of multicast address into the “Remote Host Unicast or Multicast IP Address” text box. It is suggested the unicast normally be used, so what should be put in this box is the management IP address of the CMP201.
  • Page 88 OmniHub CMP201– User Manual DVS644-SCTE18 Page (Monroe R189SE) 9. Click the Accept Changes button and that should be the last of the configuration. EAS Testing with Monroe Box 1. To force the Monroe box to do a test and send an SCTE18 message, press the Select button on the front panel of the unit TW0 TIMES.

  • Page 89: Appendix C - Specification

    OmniHub CMP201– User Manual APPENDIX C - Specification CMP201- Base unit Includes - 1RU chassis/case, power supply/line cord Systems - Chassis Dimension 445mm x 44mm x 428mm (HxWxD), 1RU Front Panel Single Power Supplies 4 Gigabit Ethernet port Rear Panel...
  • Page 90 OmniHub CMP201– User Manual Receiver Module Specification DVB-C Receiver Input 4 channels via 1 RF Female connector 2 x PCMCIA CI slots Descrambled channel quantity depends on CAM capability, 2 CAMs could be different QAM mode Annex A/C Frequency Range...
  • Page 91 OmniHub CMP201– User Manual Symbol Rate 5.057Ms/s (64QAM) 5.360Ms/s (256QAM) Signal Level 40~80dBuV CA system Supports mainstream CAS ISDB-T Receiver Input 4 channels via 1 RF Female connector 2 x PCMCIA CI slots Descrambled channel quantity depends on CAM capability, 2 CAMs could be different Frequency Range 177.143~863.143 MHz...
  • Page 92 OmniHub CMP201– User Manual Descrambled channel quantity depends on CAM capability, 2 CAMs could be different Frequency Range 47 ~ 862MHz Bandwidth 6/7/8MHz Constellation DVB-T: QPSK / 16QAM / 64QAM DVB-T2: QPSK / 16QAM / 64QAM / 256QAM Guard Interval...
  • Page 93 OmniHub CMP201– User Manual Input C/Ku Band, 8 channels via 8 RF female connectors LNB Power Independent power supplies for LNB-1 & 3, LNB-5 & LNB-7 LNB Current 13V / 18V LNB Current Max. 400mA Constellation QPSK, 8PSK Frequency Range...
  • Page 94 OmniHub CMP201– User Manual 8VSB Modulation Output 4/8 frequencies via 1 RF female connector 75Ω Standard ATSC A/35 Frequency Range 50 ~ 860MHz Bandwidth 6MHz Constellation 8VSB Output Level Max. 105dBµV ≥40dB DTMB Modulation Output 4/8 frequencies via 1 RF female connector 75Ω...
  • Page 95 OmniHub CMP201– User Manual Output Level Max. 105dBµV ≥32dB QAMB Modulation Output 4/8 frequencies via 1 RF female connector 75Ω Standard ITU-T J.83 Annex B Frequency Range 47 ~ 862MHz Bandwidth 6/7/8MHz Constellation 64QAM / 256QAM Symbol Rate 3.6~6.9Ms/s Output Level Max.
  • Page 96 OmniHub CMP201– User Manual Bandwidth 6MHz Constellation QPSK, 16QAM / 64QAM Transmission Mode RS Code RS (204.188) 1/2, 2/3, 3/4, 5/6, 7/8 Guard Interval 1/4, 1/8, 1/16, 1/32 Hierarchy Mode Layer A Segment Mode Full Seg Output Level Max. 104dBµV ≥40dB...
  • Page 97 OmniHub CMP201– User Manual HDMI Encoder (Professional) Input 4 channels via 4 HDMI female connectors (HDMI 1.4) Video H.264 / AVC HD: MP/HP@L4.0 SD: MP/HP@L3.0 MPEG-2 SD: MP@ML Resolution SD: 576i50, 480i59.94 HD: 1080p@25/30/50/59.94/60, 1080i@50/59.94/60, 720p@50/60 Bitrate Control CBR / VBR...
  • Page 98 OmniHub CMP201– User Manual HDMI Encoder with CC Input 2 channels via 2 HDMI female connectors (HDMI 1.4) CC via RCA connector Video H.264/AVC HD: MP/HP@L4.0 SD: MP/HP@L3.0 MPEG-2 SD: MP@ML HD: MP@HL Resolution SD: 576i50, 480i59.94 HD: 1080p@25/30/50/59.94/60, 1080i@50/60,...
  • Page 99 OmniHub CMP201– User Manual Bitrate Control Video Bitrate 1000 ~ 18,000Kbps GOP Structure IBBP, IPPP, IBP GOP Size 6~63 Audio MPEG-1 Layer II, AAC , AC3 . Support AC3 pass-through and dual encoding Audio Mode Stereo (2.0, including downmix) Audio Sampling Rate...
  • Page 100 OmniHub CMP201– User Manual Input 4 channels via 4 HDMI female connectors (HDMI 1.4) Video H.264 / AVC MP/HP@L4.2 H.265 / HEVC MP@L4.1 Resolution HD: 1080p-29.97 / 30 / 50 / 59.94 / 60 1080i-29.97 / 30 / 50 / 59.94 / 60 720p-50 /59.94 / 60...
  • Page 101 OmniHub CMP201– User Manual CVBS Encoder (Professional) Input 6 channels via 2 DB15 connector, each DB15 for 3 channels 2 x RCA-DB15 adaptor cables come along with the module. Video H.264/AVC SD: MP/HP@L3 MPEG-2 SD: MP@ML Resolution SD: 576i50, 480i59.94...
  • Page 102 OmniHub CMP201– User Manual Audio Volume Leveling -20dB~20dB Function Module Specification EAS Processing Module Input Digital EAS input (SCTE-18) via 1*RJ45 port Analogue EAS input via 3pin contact closure CVBS input via 1*RCA connector Audio L/R input via 2*RCA connector...

  • Page 103: Appendix D - Warranty

    Once an RMA number has been issued, the unit needs to be packaged and shipped back to Sencore. It’s best to use the original box and packaging for the product but if this not available, check with the customer service representative for the proper packaging instructions.
