VIGO VG06041 Installation Manual

Shower enclosure
Hide thumbs Also See for VG06041:

Advertisement

Quick Links

Download this manual See also: Installation Manual
VIGO INDUSTRIES INSTALLATION GUIDE FOR
SHOWER ENCLOSURE (MODEL VG06041)
!
SAFETY PRECAUTIONS
This Installation Guide uses the following symbols to indicate important information.
Always observe the instructions indicated by these symbols.
!
WARNING
Instructions that, if ignored, could result in death or serious personal injury caused by
incorrect handling or installation of the product. These instructions must be observed for
safe installation.
!
CAUTION
The instructions for the following unit is based off of the Vigo brand shower base. The
instructions can not be provided for any other installation other than that of the Vigo brand.
The warranty will be voided if the following was not performed properly.
IMPORTANT
Maintenance and other important non-personal injury and non-material damage instructions
or statements that should be observed.
It is highly advised to dry fit the unit prior to any installation.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VG06041 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VIGO VG06041

Summary of Contents for VIGO VG06041

  • Page 1 CAUTION The instructions for the following unit is based off of the Vigo brand shower base. The instructions can not be provided for any other installation other than that of the Vigo brand. The warranty will be voided if the following was not performed properly.
  • Page 2 15. Phillips screw 2" (2pc) 16. Plastic anchors green (4pc) 17. Plastic anchors white (2pc) 18. Phillips screw 1 1/8" (4pc) 19. Allen key pack (1 pack) GLASS THICKNESS 3/8" NOTE: INSTALLATION MUST BE DONE BY A QUALIFIED, LICENSED PROFESSIONAL. MODEL VG06041...
  • Page 3 68"-72" 72X74 A, B & C DIMENSIONS WERE MEASURED AFTER SHOWER ENCLOSURE WAS COMPLETELY INSTALLED THE CORRESPONDING VIGO BRAND BASES ARE AS FOLLOWS: MODEL VG06049WHT4832C - MODEL 48X74 MODEL VG06049WHT4836C - MODEL 48X74 MODEL VG06049WHT6030C - MODEL 60X74 MODEL VG06049WHT6032C - MODEL 60X74...

  • Page 4: Before Starting

    BEFORE STARTING Compare items on your invoice with what you have received. Carefully review the Packing List on page 2. If any items are missing, please call Vigo Industries at 1-866-591-7792. REQUIRED TOOLS: - Square and/or Phillips #1 and #2 screwdriver - Flat head screwdriver - Electric drill;...
  • Page 5 Position the fixed panel and the structural rail assembly correctly using a level. Mark the circumference location of the wall mount brackets on the wall. Mark the fixed panel bottom clip location and bottom door guide on the floor. MODEL VG06041...
  • Page 6 Place bracket body back on the rail. Place the fixed panel with the structural rail assembly in its proper position and thread the bracket body to the plates. Tighten the hex screws on the brackets with the hex key (supplied). MODEL VG06041...

  • Page 7: Installing The Door

    Verify that the bottom of the door aligns with the notch in the bottom door guide (SEE FIG. 10). Screw the two bottom rollers (#3) to the door panel. Adjust the stoppers' position on the structural rail and tighten the hex screws. MODEL VG06041...
  • Page 8 Remove the threshold. Apply silicone to the underside of the threshold. Place the threshold back to its shower base location. Align the threshold and press firmly down. Apply silicone to the threshold around the inside and outside of the shower base. Remove any excess silicone from the threshold. MODEL VG06041...

  • Page 9: Installing The Handle

    Place the seal strip (#13) to the door and to the fixed panel, respectively. [SEE FIG.13] Trim the flange on the seal strips so that there is enough clearance for the door to roll without the seal strips hitting against the rollers or door stopper. MODEL VG06041...
  • Page 10 FIG. 13 APPLYING THE SILICONE Apply clear silicone caulking along the wall and floor of the shower enclosure interior. [SEE FIG.14] Apply clear silicone caulking along the fixed panel and threshold of the shower enclosure interior. FIG. 14 MODEL VG06041...
  • Page 11 MODEL VG06041...
  • Page 12 - Make sure to regularly inspect your Vigo Brand shower enclosure and tighten any hardware that may have loosened during the use process. Vigo understands that your home is a moving entity and designs the Vigo Brand shower enclosure to adjust to your home needs.
  • Page 13 ROLLER (3) 3/8" VARIANCE HEX SCREW FIG. 1 Lowest position Normal position Highest position FIG. 1A IMPORTANT NOTE: These adjustments are approximate. You may need to adjust the direction of the small hex hole to meet your needs. MODEL VG06041...
  • Page 14 The small hex roller. hole on on the roller will be center right on this roller. ROLLER (3) WALL WALL STRAIGHT WALLS ROLLER "A" ROLLER "B" WALL DIRECTION SMALL HEX HOLE SMALL HEX HOLE DIRECTION DIRECTION STRAIGHT WALL FIG. 2 MODEL VG06041...
  • Page 15 TILTS IN AT TOP (EXAGGERATED FOR PURPOSE OF DEPICTION) WALL OUT OF PLUMB WALL TOP ANGLED WALL ROLLER "A" ROLLER "B" WALL DIRECTION SMALL HEX HOLE SMALL HEX HOLE DIRECTION DIRECTION TOP ANGLED ADJUST AS NEEDED FIG. 3 MODEL VG06041...
  • Page 16 WALL OUT OF WALL PLUMB TILTS IN AT BOTTOM (EXAGGERATED FOR PURPOSE OF DEPICTION) BOTTOM ANGLED WALL ROLLER "A" ROLLER "B" WALL DIRECTION SMALL HEX HOLE SMALL HEX HOLE DIRECTION DIRECTION BOTTOM ANGLED ADJUST AS NEEDED FIG. 4 MODEL VG06041...
  • Page 17 Subject to the Warranty Service provision below, any product reported to the authorized dealer or to VIGO as being defective within the warranty period will be repaired or replaced (with a product of equal value) at the option of VIGO. This warranty extends to the original owner or end-user and is not transferable to a subsequent owner.
